aquilar AquiTron AT-ZAP Installation & Operation Manual

Zone alarm panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
I N STA L L AT I O N
& O PE R ATI ON
I N S T R U C -
AquiTron
AT-ZAP
Zone Alarm Panel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AquiTron AT-ZAP and is the answer not in the manual?

Questions and answers

Related Manuals for aquilar AquiTron AT-ZAP

Summary of Contents for aquilar AquiTron AT-ZAP

  • Page 1 AquiTron AT-ZAP Zone Alarm Panel I N STA L L AT I O N & O PE R ATI ON I N S T R U C -...

  • Page 2: General Information

    Operating: 0°C to 50°C (32°F to 122°F) in this limitation. ENCLOSURE NEMA 12; IP54 Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 3 Z5/6 6Vdc latching solenoid output DOOR BOARD CR 2032 Battery Display Connector Main PCB Connector Serial Expansion Port USB Connector for History dump. Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...

  • Page 4: Mount The Module

    Fig 2. To seal around the mounting screw (necessary to maintain the IP54 rating), use a rubber or elastomeric washer. Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...

  • Page 5: Make Connections

    (Z1-Z12) • Connect the four colour-coded wires to the Sensor Interface plug for the required zone 1-12 (see Fig 3). Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...

  • Page 6: Battery Backup

    Positionon the left hand side of the negative) battery leads (leads not supplied) motherboard as shown on the Layout (fig 6). Diagram number 7-12. Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...

  • Page 7: Fault Relay

    F. SETUP Zone Enabled/Zone Names Info Button Zone Status Settings Button Date and Time Mute / Reset Button System Status Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 8 To enter the Setup and installer menus passwords are required for access. Use the on screen keyboard to enter the relevant password and press the ‘Enter’ button. Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 9 LEAK DETECTION SOLUTIONS AT-ZAP Zone Alarm Panel PASSWORD Set up Menu: aquitron30 Installer Menu: aquitron12 F 1. SETUP MENU Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 10 The name will be changed. If a mistake is made, or to rename, repeat the process. Press back to exit. F 1.2 TIME & DATE Settings>>Setup>>Password>>Date/Time Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 11 This will be displayed on the zone button, and home screen as long as the zone is enabled. Note: If a named zone is disabled it retains its name. Press back to return to settings menu. Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 12 Relay operates on Break alarms only Both Relay operates on Leak and Break alarms Assignment 1,2,3,4,5,6,7,8,9, Selects what zone number the solenoid reacts to 10,11,12 Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 13 Solenoid operates on Break alarms only Both Solenoid operates on Leak and Break alarms Assignment 1,2,3,4,5,6,7,8,9, Selects what zone number the solenoid reacts to 10,11,12 Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 14 For further control by the panel these feeds can be routed through the volt free relay outputs. Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 15 NOTE: The Mute/Re-alarm cycle will not affect relay operation unless set to ‘Sound’ function. Re-Alarm has no effect on solenoid outputs. Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 16 Override function off. Solenoid will operate as normal Override Solenoid override will function for one hour before returning to previous state Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 17 If you wish to clear the events history press the ‘Clear Events History’ button. It will ask you to confirm. To carry out the clear press confirm. To abort press the back button. Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 18 After clearing, an entry showing time and date of this action will now be the first history entry. F 3. Installer Menu F 3.1 COMPANY DETAILS Settings>>Installer>>Password>>Company Details Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 19 AT-ZAP Zone Alarm Panel By default the AT-ZAP contains contact details for Aquilar Ltd. This can be changed on this screen to show the details of the installation/Service company. Select the entry you wish to update, Company name or company contact details, enter the new details within the ‘Enter Text’...
  • Page 20 ‘Yes’ selected above Trigger Fault Relay Common fault relay will not be triggered in conjunction with the ‘No’ message selected above Unit 30, Lawson Hunt Industrial Park, Broadbridge Heath, Horsham, West Sussex, RH12 3JR +44 (0) 1403 216100 info@aquilar.co.uk www.aquilar.co.uk...
  • Page 21 The only obligations of Aquilar Limited are those in the Aquilar Standard Terms and Conditions of Sale for this product, and in no case will Aquilar Limited be liable for any incidental, indirect, or consequential damages arising from the sale, resale, use or misuse of the product.
