User Manual
MELAnet Box
For networking of MELAG steam sterilizers
from software version 1.013a
EN
Dear customer,
We thank you for your confidence demonstrated by the purchase of this MELAG product.
As an owner-run and operated family concern founded in 1951, we have a long history of successful specialization in
hygiene products for practice-based use. Our focus on innovation, quality and the highest standards of operational
reliability has established MELAG as the world's leading manufacturer in the instrument treatment and hygiene field.
You, our customer are justified in your demand for the best products, quality and reliability. Providing "competence in
hygiene" and "Quality – made in Germany", we guarantee that these demands will be met. Our certified quality
management system is subject to close monitoring: one instrument to this end is our annual multi-day audit conducted in
accordance with ISO 13485. This guarantees that all MELAG products are manufactured and tested in accordance with
strict quality criteria.
The MELAG management and team.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MELAnet Box and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MELAG MELAnet Box

Summary of Contents for MELAG MELAnet Box

  • Page 1 "Quality – made in Germany", we guarantee that these demands will be met. Our certified quality management system is subject to close monitoring: one instrument to this end is our annual multi-day audit conducted in accordance with ISO 13485. This guarantees that all MELAG products are manufactured and tested in accordance with strict quality criteria.
  • Page 2 The device type is specified on the type plate on the lower side of the device. Should the manual no longer be legible, is damaged or has been lost, you can download a new copy from MELAG download centre at www.melag.com.
  • Page 3 Returning the packaging to the material flow reduces the amount of waste and saves raw materials. MELAG draws the operator’s attention to the fact that they are responsible for deleting personal data on the device to be disposed of.

  • Page 4: Table Of Contents

    Device info menu ................................14 Configuration menu ............................... 14 Protocols menu ................................16 Update menu ................................. 17 Password for the MELAnet Box configurator ......................... 18 Reset user-defined settings ............................18 Chapter 4 – Troubleshooting ......................19 Log output via TCP not possible ............................ 20 Log output via TCP not possible ............................
  • Page 5 MELAG-authorized technical customer service. Application  Do not place the MELAnet Box directly on the steam sterilizer. The steam sterilizer will become hot upon operation. Non-observance could result in restricted function and damage to the MELAnet Box.

  • Page 6: Chapter 1 - Device Description

    Chapter 1 – Device description Intended Use The MELAnet Box enables the connection of a MELAG steam sterilizer with RS232 interface for transfer of protocols to the computer network (Ethernet) of the practice or clinic. Compatibility to different MELAG device types...

  • Page 7: Views Of The Device

    State Meaning Device is switched on / live Power Device is switched off / not live MELAnet Box start configuration was successful flashes quickly Data is being exchanged over the Ethernet interface between the Data flashing computer and the MELAnet Box.

  • Page 8: System Requirements

    Chapter 1 – Device description System requirements Hardware  min. 500 MB free memory for the installation of the program  min. 2 GB RAM  COM-connection (RS232 interface)  if no COM-connection is available: USB/Serial Adapter PLEASE NOTE The USB/Serial Adapter not included in the scope of delivery. The majority of adaptors will be recognized by the operating system.

  • Page 9: Chapter 2 - Installation Instructions

    IT specialists to undertake all work in your practice network. In order for the MELAnet Box to be operated in your practice network, the first three digit blocks of the IP address of the MELAnet Box should conform to that of the IP address of the practice network. The last digit block is assigned to the device connected in the practice network.
  • Page 10 Use the covered network cable to prevent the emission values from being exceeded. We recommend the type SF/UTP network cable in accordance with ISO/IEC 11801 Cat.5e. Connect the serial cable to the middle connection of the MELAnet Box and plug it into the computer.
  • Page 11 Power To be able to change the settings of the MELAnet Box later on, note down the IP address that was assigned to the MELAnet Box. Press Stop and then Next. The dialogue changes to the menu item Connection.
  • Page 12 The lower LED (LAN) then lights up green and the data LED flashes yellow. lights up Test the connection to the MELAnet Box by entering the configured IP address in the address bar of your Internet browser (Microsoft Edge, Firefox, Chrome etc.).

  • Page 13: Settings On The Steam Sterilizer

    Settings on the steam sterilizer In order to be able to issue the sterilization logs via the MELAnet Box and to be able to view information regarding the program sequence or selected measured values from the steam sterilizer on the MELAnet Box, you need to set the MELAnet Box as an output medium on the steam sterilizer as follows: For all device types from software version v 4.06:...

  • Page 14: Chapter 3 - Melanetbox Configurator

    (A) shows Autoklav offline. The display (B) remains empty. No measurement values (C) will be shown either. Configuration menu The Configuration window presents an overview of all MELAnet Box settings. Here you can also change the logging settings. After the initial installation the program switches automatically to the Configuration window.
  • Page 15 Logging settings PLEASE NOTE As all log output settings can be made via the MELAnet Box configurator, the corresponding options for log output at the steam sterilizer will be disabled in the Setup menu Function. Immediate log output after program end For the sterilization logs to be saved automatically on the computer after the end of a program, you must select to log output.

  • Page 16: Protocols Menu

    Chapter 3 – MELAnetBox configurator Enter your password and click on Apply, to apply the changes. (The password is "MELAG" by default.) Log storage via FTP If you want to store the text and graphic logs via an FTP server, an FTP server must be installed on the computer in a folder of your choice or installed later.

  • Page 17: Update Menu

    But you can also close it down manually by clicking on Disconnect . Update menu In the "Update" window you can very easily update the software on the MELAnet Box and the web server that is available to use optionally. The update files can be obtained from your service technician.

  • Page 18: Password For The Melanet Box Configurator

    To save the new password, click on Apply. Reset user-defined settings Here you can learn how the user-defined settings of the MELAnet Box can be re-set to the work settings. NOTICE The IP address of the MELAnet Box and the user-defined password will also be reset to the work setting standard values.

  • Page 19: Chapter 4 - Troubleshooting

    Deselect the MELAnet Box as sterilizer via the MELAnet Box output medium on the steam configurator sterilizer. The following error message will Power supply to the MELAnet Box Check whether the power be shown: "Error while cut off supply cable is properly loading/sending data."...

  • Page 20: Log Output Via Tcp Not Possible

    Check whether the MELAnet Box is registered as user in the FTP server.  If yes, compare the user name and the FTP password of the MELAnet Box against the user settings in the FTP server. These need to match.

  • Page 21: Hints When Using A Notebook

    Chapter 4 – Troubleshooting Hints when using a notebook With operation without a power adaptor and network card the laptop switches into energy saving mode. Change the settings under Control panel  System  Hardware  Device manager  Network adapter by deactivating the option Allow computer to turn off this device to save power in the Properties window in the register energy management.

  • Page 22: Chapter 5 - Technical Data

    100 – 250 V, 47 – 63 Hz, 1,6 A Electrical connection Power supply Electrical power max. 6 W Length of the power cable ca. 1,4 m Factory settings of the MELAnet Box Parameter Standard value Language German IP address 192.168.40,100 Gateway 192.168.40.1...

  • Page 23: Appendix - Accessories

    Appendix – Accessories Article Art. no Power supply unit for MELAnet Box ME30403 Power supply unit for MELAnet Box (UK/AUS/US/CHN) ME30402 Serial cable for MELAnet Box (RS232 to Western), 1.5 m ME15819 Network cable for printer / MELAnet Box, 2 m ME15812...

  • Page 24: Glossary

    MELAnet Box in a network. MELAnetBox configurator a software developed by MELAG which enables the configuration of the MELAnet Box and the output of the sterilization logs. MELAtrace/MELAview a software developed by MELAG for displaying and sorting sterilization logs and with the opportunity to display graphic logs.
  • Page 26 MELAG Medizintechnik GmbH & Co. KG Geneststraße 6-10 10829 Berlin Germany E-Mail: info@melag.de Web: www.melag.com Original instructions Responsible for content: MELAG Medizintechnik GmbH & Co. KG We reserve the right to technical alterations...
