Operating Manual
MELAnet Box
For networking of MELAG autoclaves
from software version 1.011a
EN
Dear doctor,
We thank you for your confidence demonstrated by the purchase of this MELAG product.
As an owner-run and operated family concern founded in 1951, we have a long history of successful specialization in
hygiene products for practice-based use. Our focus on innovation, quality and the highest standards of operational
reliability has established MELAG as the world's leading manufacturer in the instrument treatment and hygiene field.
You, our customer are justified in your demand for the best products, quality and reliability. Providing "competence in
hygiene" and "Quality – made in Germany", we guarantee that these demands will be met. Our certified quality
management system is subject to close monitoring: one instrument to this end is our annual multi-day audit conducted in
accordance with ISO 13485. This guarantees that all MELAG products are manufactured and tested in accordance with
strict quality criteria.
The MELAG management and team.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MELAnet box and is the answer not in the manual?

Questions and answers

Related Manuals for MELAG MELAnet box

Summary of Contents for MELAG MELAnet box

  • Page 1 "Quality – made in Germany", we guarantee that these demands will be met. Our certified quality management system is subject to close monitoring: one instrument to this end is our annual multi-day audit conducted in accordance with ISO 13485. This guarantees that all MELAG products are manufactured and tested in accordance with strict quality criteria.
  • Page 2 Formatting rules Symbol Explanation Log output Words or phrases appearing on the web browser window of the MELAnet Box configurator are marked as menu text. Log output Words or phrases appearing on the display of the autoclave are marked as software citations.

  • Page 3: Table Of Contents

    Log output via TCP not possible ............................ 20 Log output via TCP not possible ............................ 20 Hints when using a notebook ............................21 Chapter 5 – Technical Data ......................22 Factory settings of the MELAnet Box ..........................22 Appendix – Accessories ........................ 23 Glossary ............................24...
  • Page 4 MELAG-authorized technical customer service. Application  Do not place the MELAnet Box directly on the autoclave. The autoclave will become hot upon operation. Non-observance could result in restricted function and damage to the MELAnet Box.

  • Page 5: Chapter 1 - Device Description

    Chapter 1 – Device description Chapter 1 – Device description Intended Use The MELAnet Box enables the connection of a MELAG autoclave to the computer network of the practice or clinic via an Ethernet interface. Compatibility to different MELAG device types...

  • Page 6: Views Of The Device

    LED lights State Meaning Power Device is switched on / live Device is switched off / not live MELAnet Box start configuration was successful flashes quickly Data flashing Data is being exchanged over the Ethernet interface between the (Daten) computer and the MELAnet Box.

  • Page 7: System Requirements

    Chapter 1 – Device description System requirements Hardware  Windows 8.1, Windows 8, Windows 7 (32/64 bit), Windows Vista (32/64 bit), Windows XP  COM-connection (RS232 interface)  If no COM-connection is available: USB/Serial Adapter PLEASE NOTE The USB/Serial Adapter not included in the scope of delivery. The majority of adaptors will be recognized by the operating system.

  • Page 8: Chapter 2 - Installation Instructions

    IT specialists to undertake all work in your practice network. In order for the MELAnet Box to be operated in your practice network, the first three digit blocks of the IP address of the MELAnet Box should conform to that of the IP address of the practice network. The last digit block is assigned to the device connected in the practice network.
  • Page 9 Use the covered network cable to prevent the emission values from being exceeded. We recommend the type SF/UTP network cable in accordance with ISO/IEC 11801 Cat.5e. Connect the serial cable to the middle socket of the MELAnet Box and plug it into the COM socket* on the computer.
  • Page 10 Chapter 2 – Installation instructions Enter the free IP address of the MELAnet Box and click on Send. NOTE The first three number blocks of the IP address must match those of the practice network, the last block of numbers indicates the device number and must not have been assigned.
  • Page 11 Chapter 2 – Installation instructions Plug the ethernet cable (1:1) into the left socket of the MELAnet Box and connect it to the practice network. connect Practice network Power The lower LED (LAN) then lights up green and the data LED flashes yellow.

  • Page 12: Settings On The Autoclave

    Settings on the autoclave In order to be able to issue the sterilization logs via the MELAnet Box and to be able to view information regarding the program sequence or selected measured values from the autoclave on the MELAnet Box, you need to set the MELAnet Box as an output medium on the autoclave as follows: For all device types from software version v 4.06:...

  • Page 13: Chapter 3 - Melanetbox Configurator

    (A) shows Autoclave offline. The display (B) remains empty. No measurement values (C) will be shown either. Configuration menu The "Configuration" window presents an overview of all MELAnet Box settings. Here you can also change the logging settings. After the initial installation the program switches automatically to the "Configuration" window.
  • Page 14 Logging settings PLEASE NOTE As all log output settings can be made via the MELAnet Box configurator, the corresponding options for log output at the autoclave will be disabled in the Setup menu Function. Immediate log output after program end For the sterilization logs to be saved automatically on the computer after the end of a program, you must put a tick next to log output.

  • Page 15: Logs Menu

    Select the desired option in the field Storage of logs via and tick the option FTP. Fill out the fields under FTP settings. Enter your password and click on Apply, to apply the changes. (The password is "MELAG" by default.) Logs menu In the "logs"...
  • Page 16 Chapter 3 – MELAnetBox configurator The connection is closed automatically when the MELAnet Box configurator is shut down. But you can also close it down manually by clicking on Disconnect . Log output via FTP The following requirements must be fulfilled for log storage via FTP: ...

  • Page 17: Update Menu

    Chapter 3 – MELAnetBox configurator Update menu In the "Update" window you can very easily update the software on the MELAnet Box and the web server that is available to use optionally. The update files can be obtained from your service technician.

  • Page 18: Reset User-Defined Settings

    Chapter 3 – MELAnetBox configurator Reset user-defined settings Here you can learn how the user-defined settings of the MELAnet Box can be re-set to the work settings. NOTICE The IP address of the MELAnet Box and the user-defined password will also be reset to the work setting standard values.

  • Page 19: Chapter 4 - Troubleshooting

    Deselect the MELAnet Box as the MELAnet Box configurator output medium on the autoclave. The following error message will Power supply to the MELAnet Box Check whether the power be shown: "Error while cut off supply cable is properly loading/sending data."...

  • Page 20: Log Output Via Tcp Not Possible

    Check whether the MELAnet Box is registered as user in the FTP server.  If yes, compare the user name and the FTP password of the MELAnet Box against the user settings in the FTP server. These need to match.

  • Page 21: Hints When Using A Notebook

    Chapter 4 – Troubleshooting Hints when using a notebook With operation without a power adaptor and network card the laptop switches into energy saving mode. Change the settings under Control panel  System  Hardware  Device manager  Network adapter by deactivating the option Allow computer to turn off this device to save power in the Properties window in the register energy management.

  • Page 22: Chapter 5 - Technical Data

    100 – 250 V, 47 – 63 Hz, 1,6 A Electrical connection Power supply Electrical power max. 6 W Length of the power cable ca. 1,4 m Factory settings of the MELAnet Box Parameter Standard value Language German IP address 192.168.40,100 Gateway 192.168.40.1...

  • Page 23: Appendix - Accessories

    Appendix – Accessories Article Article number Power supply unit for MELAnet Box 30403 Power supply unit for MELAnet Box (UK/AUS/US/CHN) 30402 Serial cable for MELAnet Box, RS232 <-> Western-Plug, 1.5 m 15819 Ethernet connection cable (RJ45), 2 m 15812...

  • Page 24: Glossary

    MELAnet Box in a network. MELAnetBox configurator a software developed by MELAG which enables the configuration of the MELAnet Box and the output of the sterilization logs. MELAtrace/MELAview a software developed by MELAG for displaying and sorting sterilization logs and with the opportunity to display graphic logs.
  • Page 26 MELAG Medizintechnik oHG Geneststraße 6-10 10829 Berlin Germany E-Mail: info@melag.de Web: www.melag.com Responsible for content: MELAG Medizintechnik oHG We reserve the right to technical alterations...
