Liquid Propane Conversion Kit
For the following Coleman® Gas Barbecue Grills:
Note: These instructions apply to
grill Model 8350 Series. The parts
included are designed for your
specific grill. The illustrations may
differ slightly from model to
model.
IMPORTANT
Read this document carefully before attempting installation
of this conversion kit. These instructions should be left with
the consumer for future reference.
WARNING
• This Liquid Propane conversion Kit must be installed only by a quali-
fied service technician.
• Gas supply system must be installed in accordance with the U.S.
National Fuel Gas Code.
• This appliance and its individual shut off valve must be disconnected
from the gas supply piping system during any system pressure test in
excess of 1/2 PSI (3.5 KPA).
• Use a system manual shut off valve to shut off the gas supply to this
gas appliance before continuing with installation procedures.
8350 Series (M/N 9992-648)
• If the information in this document is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss
of life. Read the Coleman® Gas Barbecue Use, Care & Assembly
Manual With Grill Lighting Instructions, before attempting installation
of this conversion kit.
DO NOT attempt to install this Natural Gas Conversion Kit
A liquid propane tank, not connected for use with this gas barbecue,
shall not be stored in the vicinity of this or any other appliance.
Installation and provision for combustion and ventilation air
must conform with the National Fuel Gas Code, ANSI Z223.1 ,
or CAN/CGA-B149.1, Natural Gas Installation Code , or
CAN/CGA-B149.2, Propane Installation Code .
Turn off and disconnect from Natural Gas
service line prior to servicing grill.
WARNING
WARNING
• TURN OFF THE GAS SUPPLY!
while the barbecue is in operation or is hot.
WARNING
Advertisement
Related Manuals for Coleman 9992-449
Summary of Contents for Coleman 9992-449
- Page 1 • If the information in this document is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Read the Coleman® Gas Barbecue Use, Care & Assembly Manual With Grill Lighting Instructions, before attempting installation of this conversion kit.
- Page 2 Liquid Propane Gas Conversion Instructions Item No. 9992-4421 47310103 08006001 08138381 49900004 9992-462 Description Main Burner Valve & Manifold Assembly (L.P.) 8350 Main Regulator Hose Assembly (L.P.) Rear IR L.P. Orifice (8350) Connector 3/8" FNPT x 3/8" MFLR Pipe Sealant LP Conversion Sticker...
-
Page 3: Tools Needed
Liquid Propane Gas Conversion Instructions Tools Needed: Phillips head screwdriver 1/4" nut driver * 9/16" wrench Adjustable wrench * socket set with extension can also be used. Be sure gas supply is off, the knobs are in the off position and the grill is cool. 1. - Page 4 Liquid Propane Gas Conversion Instructions 5. Remove the screws from the bottom of the heat shield, holding the front heat shield in place. The screws are located under the bottom lip of the shield (Fig. 5). 6. Remove the side heat shield screws located under the bottom lip of the heat shield.
- Page 5 Liquid Propane Gas Conversion Instructions 10. Disconnect the right side flexline from the manifold using the adjustable wrench. This will free up the right side of the manifold (Fig. 9). 11. Disconnect the left side flexline from the back infrared valve using an adjustable wrench. This will free up the left side of the manifold (Fig.
- Page 6 Liquid Propane Gas Conversion Instructions You are now ready to install the new LP manifold. 16. NOTE: New screws for the bezels are inserted into the new LP manifold at the factory. Remove them before proceeding with Step 17. 17. Place the new manifold into the grill body with the control knob stems going outward through control panel front (Fig.
- Page 7 Liquid Propane Gas Conversion Instructions Installing the L.P. regulator 28. Remove the NG regulator from the main gas pipe using an adjustable wrench. The NG regulator is located on bottom of grill head (Fig. 17). Note: For the following steps, the supplied pipe dope needs to be applied to all fittings before the fittings are attached.
- Page 8 Liquid Propane Gas Conversion Instructions Converting the Rear Infrared Burner to LP 31. Remove the four screws on the inside of the grill that hold the rear infrared cover in place (Fig. 20). 32. Close the grill hood slowly. 33. Remove the two screws from the back infrared cover, located on the back of the grill (Fig.
- Page 9 Liquid Propane Gas Conversion Instructions Label the Grill 44. Apply conversion label 9992-462 on the grill, next to the lighting instruction label (Fig. 25). Note: At the completion of the conversion, a leak test should be performed on all fittings. See Use and Care manual for leak testing procedure.
- Page 10 Liquid Propane Gas Conversion Instructions NOTES __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ ____________________________________________________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________...
- Page 11 Liquid Propane Gas Conversion Instructions NOTES __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ ____________________________________________________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________ __________________________________________...
- Page 12 The Coleman Company, Inc. • 3600 North Hydraulic Wichita, KS 67219 U.S.A. 1-800-356-3612 • TDD: 316-832-8707 www.coleman.com ©2006 The Coleman Company, Inc. All rights reserved. Coleman® and are registered trademarks of The Coleman Company, Inc. 9992-449 (8/14/06)
