Summary of Contents for Coaster EASTERN 300684KE
- Page 1 300684KE EASTERN KING SIZE BED ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE 1 OF 4...
- Page 2 ITEM: 300684KEB1 ASSEMBLY INSTRUCTION ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast &...
- Page 3 ASSEMBLY INSTRUCTION ITEM: 300684KEB2 PARTS IDENTIFICATION BED RAIL 2 PCS FOOTBOARD 1 PC SLAT 5 PCS SUPPORT LEG 10 PCS 2 PCS Z HARDWARE PACKAGE DESCRIPTION FIGURE Q'TY Bolt 8*70MM 2 PCS 3 Flat washer Ø6.5 * Ø19 * Ø2 MM 18 PCS Flat washer 5/16*16*1.5MM 2 PCS...
- Page 4 STEP 1 STEP 2 STEP 3 STEP 4 4 of 4...
