Onbon BX-Y04 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

USER MANUAL
BX-Y04 Media Player
Version: V1.2
Release date: 2020.05.21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BX-Y04 and is the answer not in the manual?

Questions and answers

Related Manuals for Onbon BX-Y04

Summary of Contents for Onbon BX-Y04

  • Page 1 USER MANUAL BX-Y04 Media Player Version: V1.2 Release date: 2020.05.21...
  • Page 2 Statement Any companies or privates cannot copy, transcribe or translate part or whole content of this file without our written permission. And cannot use it on any business or benefit filed with any forms. The specifications and information which are mentioned on the file is for reference only, if there’s update, we will not inform you.

  • Page 3: Table Of Contents

    CATALOG Brief Introduction ............................4 Overview ..............................4 Interface Specification ..........................5 Hardware Connecting Sketch Map ......................6 Using Steps ..............................7 Add Screen ............................. 7 IP Configuration ..........................10 Set Screen Parameters ........................11 WIFI configuration ..........................14 Scan Configuration ........................... 17 Connect Configuration ........................

  • Page 4: Brief Introduction

    Overview BX-Y04, on-board four hub75 ports, one card for one screen, it’s used on all kinds of small size full color screen and cluster controlling; Support LAN (100M Ethernet port), USB or WIFI communication modes;...

  • Page 5: Interface Specification

    Interface Specification Interface specification 5V power supply port, DC voltage input, support 3.3V-6V Power supply wide working voltage 100M 100M Ethernet port Antenna Connect with WIFI antenna USB port USB port, send programs by U disk AUDIO Audio output PROG Switch button for programs TEST Testing button...

  • Page 6: Hardware Connecting Sketch Map

    Hardware Connecting Sketch Map LED Screen Computer Row cable BX-Y04 controller LAN cable LAN cable Router www.onbonbx.com 第6 页...

  • Page 7: Using Steps

    Using Steps This user manual is just for fast understanding, if you want to know more functions, please check our User Manual for LedshowYQ 2018. Add Screen Open “LedshowYQ 2018”, click “setup”, select “set screen parameters”, as below. Input password “168”, enter into “set screen parameters”, click , enter into “add screen”, as below.
  • Page 8 Picture 2 Click behind “online card list”, then select the controller which is online, screen will be added in, click “add” as to finish this setting, as below: www.onbonbx.com 第8 页...
  • Page 9 Picture 3 Choose “add all screen”, as to add screen for all online controller, as below: Picture 4 www.onbonbx.com 第9 页...

  • Page 10: Ip Configuration

    IP Configuration Step 1 Click “controller IP configuration” in “setup”, as below: Picture 5 Step 2 Input password “168”, click “OK”, as below: Picture6 Step 3 Users can see all online controllers in “online card list”, click the controller you need to do IP modification, and then select IP obtain method, click “set”...

  • Page 11: Set Screen Parameters

    Picture7 Set Screen Parameters Step 1 Click “set screen parameters” in “setup”, as below: www.onbonbx.com 第11 页...
  • Page 12 Picture8 Step 2 Input password 168, and click OK, as below: Picture9 Step 3 Set width and height pixels according to LED screen size, as below: www.onbonbx.com 第12 页...
  • Page 13 Picture10 Step 4 Click “set parameters”, as below: Picture11 www.onbonbx.com 第13 页...

  • Page 14: Wifi Configuration

    WIFI configuration There are two WIFI modes for Y series controller: AP mode and STA mode. (If there no wireless card, please prepare one USB wireless card.) AP mode (controller is hotspot, as to connect controller’s WIFI by PC) Step 1 Open network connection on PC, the hotspot name of controller is the barcode of controller, as below: Picture12...
  • Page 15 Picture14 STA mode( controller connect with outside WIFI network) Step 1 Selet “Wifi”icon—click “refresh” button—choose the WIFI name you want—input WIFI passwords—select “obtain IP address automatically” or input IP method manually—click “connect” button, then you can connect with this WIFI. www.onbonbx.com 第15 页...
  • Page 16 Picture15 Step 2 After connect successfully, plug off LAN cable of controller. And PC joins up same wireless router, by LAN cable or WIFI. Then, LedshowYQ 2018 software can communicate with controller normally. www.onbonbx.com 第16 页...

  • Page 17: Scan Configuration

    Scan Configuration Click “scan configuration” in “set scan parameters”, as below. Users can set “module parameters”, “receiver card load”, “performance settings”, “Gamma”, “white balance adjustment”, “smart scan”. Picture16 Write Scan Method Firstly, click “scan configuration”—click “select modules”, as below: www.onbonbx.com 第17 页...
  • Page 18 Picture17 Select module on “module brand/scan list ” and “module list”-- click “OK”, click “lock specified receiver card” on “connection configuration”. Note: Support download configuration file from Cloud. If the module is saved configuration file, users can click “Synchronize module list from network”. www.onbonbx.com 第18 页...
  • Page 19 Picture18 www.onbonbx.com 第19 页...
  • Page 20 ◆ Full color module: There are several scan mode: scan 32/16/8/4/2 and static. Usually indoor single and dual color is scan 16, indoor full color is scan 8, outdoor single and dual color is scan 4, outdoor full color is static. ◆...
  • Page 21 Step 2 Enter into “smart setup wizard-2”. Picture20 Firstly click “1”, check the LED screen (is black or white”, then click “2”, check the LED screen (is black or white), and if users want to check carefully the changes of screen, you can choose “status automatically changes …”...
  • Page 22 Step 4 Click “Display status 1”, check the color of LED screen, and select the correct color; Click “Display status 2”, check the color of LED screen, and select the correct color (same with 3 and 4). If users want to check the changes of screen carefully, please choose “status automatically changes…”...
  • Page 23 Picture24 Step 7 Click the corresponding grid according to the lights of LED screen, until all the lights are lighting on LED screen, as below. Click “OK”, software will show you a scan mode, you can save this file. Picture25 Receiver card load Set the width and height of receiving card, users can refer to the recommended width and height of our software.
  • Page 24 Picture26 Performance setting Performance setting: set display mode, brightness mode, gray scale, visual refresh rate, shift clock, duty ratio, row blanking time, accelerate rate, no signal, clock phase, data group, gamma, white balance adjustment Picture27 Display mode: default is refresh rate priority. Users can get a better effect by camera, ⚫...
  • Page 25 No signal: if receiving card cannot get signal, you can choose “last frame” or ⚫ “black screen”. Clock phase: sometimes there’s malposition or flash points, you can adjust this ⚫ parameter. Data group: default is normal, if choose 20 data groups, need to use special ⚫...

  • Page 26: Connect Configuration

    Picture29 Connect Configuration Click “connect configuration” in “parameters setting”, as below. You can set the receiving cards number of horizontal and vertical direction. Also receiving card’s number, width and height. Lastly click “Load specified receiver card”. Picture30 One receiving card support width 384 and height 356. So, if the width of LED screen is 512, height is 96, you can see one receiving card is not enough for width, but more rest for height, so, as to get a full use of one receiving card, we can use “data group expansion”...
  • Page 27 Picture31 If customers installed many receiving cards, need to configurate cascade direction of receiving cards, as below. Click “custom”, you can choose www.onbonbx.com 第27 页...
  • Page 28 Picture32 If users want to adjust the offset, you can click “output offset”, as below Picture 57. Choose “according to group editing”, and input offset data. Also, users can choose “according to line editing”, and input data. If there’s a little mistake for setting, please click “reset”.
  • Page 29 Picture33 www.onbonbx.com 第29 页...
  • Page 30 Picture34 Usually, the horizontal value and vertical value is 0 in program position, users can choose “custom network port output”, click “custom”, as below. www.onbonbx.com 第30 页...
  • Page 31 Picture35 Picture36 www.onbonbx.com 第31 页...

  • Page 32: Server Configuration

    Server Configuration Set server IP information Step 1 Connect 5V power supply for controller, and connect controller with PC by LAN cable. Step 2 Click “IP configuration”, as below: Picture37 Step 3 Input passwords “168”, as below. Picture38 www.onbonbx.com 第32 页...
  • Page 33 Step 4 Enter into “IP configuration” page, choose “server mode”- “local server”- input “server IP address” and “server port”- click “set”. It will be succeed after 10 seconds. Picture39 Step 5 Click “server configuration”, as below. Input passwords “168”, input “server port” number (this server port number is the “server port”...
  • Page 34 Picture40 Picture41 www.onbonbx.com 第34 页...

  • Page 35: Web Server Communication

    WEB Server Communication Y series products support WEB server communication mode by iLEDCloud. Only if you are in the area which has network, then, can operate all the screens in real time remotely. 1. Set WEB server Open “LedshowYQ 2018”- click “IP configuration” in “setup”- input passwords 168, choose “iLEDCloud”...
  • Page 36 Picture43 If the controller is online and equipment is connecting with network, users can check the bound controllers in “screen ” of “resource”, also check the equipment ID/name/width/height and online status of each control card. If you want to modify screen name or screen parameters, please click means online.
  • Page 37 Picture45 3. Add Program Users can add many areas, graphic, video, text, etc. After edit, click “save” button. Picture46 4. Edit Program Click edit button in right side, example, add a subtitle zone, as below: www.onbonbx.com 第37 页...
  • Page 38 Picture47 5. Program Release After add program, you can release it by Picture48 You need to give a name to this program, then release. www.onbonbx.com 第38 页...
  • Page 39 Picture49 www.onbonbx.com 第39 页...

  • Page 40: Steps For Making Program

    Steps for Making Program 1. Add Program You can add Notice area/ Video area/ Image/text area/ Subtitle area/ Time area/ Weather area/ Database and Sensor area, as below: Picture50 Notice area: you can add a notice text. ⚫ Video area: you can add and play video file with all kinds of format, also support high ⚫...

  • Page 41: Add Image/Text

    Picture 51 Program name: Edit the name of this program. ⚫ Order play: after display all the contents in this program, will switch to another program. ⚫ Play time: This program is displayed in this given time, will switch to another program. ⚫...

  • Page 42: Finish Making Program

    ：Click here as to delete selected areas. ：Click here to set added content as present status. ：Transparent bakcground: choose this, there will be no background color. ：For mongolian language. ：For Arabic, Hebrew language. ：Display method is list displaying. ：Display method is preview displaying. 2.

  • Page 43: Display Program

    Display program If you want to display the present program file, please click , preview window and screen will display the same program at the same time. If need to display different program file, click “open” button, open program file and display. Sensor Display Y04 controller connection Picture54...
  • Page 44 Click icon as to check the connection method of temperature sensor. Picture55 2. Humidity display Choose sensor type, sensor interface, unit, precision, correction, need custom text or not, font, font number, bold, italic, underline, threshold and normal color. Click icon as to check the connection method of temperature sensor. Picture56 3.
  • Page 45 Picture57 ⚫ Manual brightness: as below: Picture58 www.onbonbx.com 第45 页...
  • Page 46 ⚫ Automatic brightness: choose “BX-VMF”, as below, brightness value can be default or custom, click “setup”, brightness of screen will be adjusted according to the sensor. Picture59 www.onbonbx.com 第46 页...
  • Page 47 Shanghai ONBON Technology Inc. Address: 7 Floor, Tower 88, 1199#, North Qinzhou Road, Xuhui District, Shanghai City, China Website: www.onbonbx.com 仰邦微信公众号 ONBON (Jiangsu) Optoelectronic Industrial Co.,LTD Address: 1299#, Fuchun Jiang Road, Kunshan City, Jiangsu Province, China www.onbonbx.com 第47 页...
