- Page 1 Multi-media player User Manual △ △ △ △ Before you use the LED controller, please read this file first and save it for future BX-YQ3AE...
- Page 2 Statement Any companies or privates cannot copy, transcribe or translate part or whole content of this file without our written permission. And cannot use it on any business or benefit filed with any forms. The specifications and information which are mentioned on the file is for reference only, if there’s update, we will not inform you.
-
Page 3: Table Of Contents
CATALOG ..............................1 B r i e f I n t r o d u c t i o n ..............................1 A b o u t S o f t w a r e ..............................1 C h a r a c t e r i s t i c s . -
Page 4: Brief Introduction
Brief Introduction Thanks for ordering LED control card. The design of the control card is according to the international and industrial standard, but if the operations are incorrect, it will probably bring you personal injury and financial harm. As to avoid these and win more from your equipment, please obey the specifications of this file. -
Page 5: Guiding
Easy to upgrade the software , you can use pc software or cloud platform to remote upgrade it , no need to the pot. Support temprature, humity, brightness sensor Support remote controller, can use the remote to request program and adjust the brightness, volume, screen test etc.. -
Page 6: Safety Notes
Safety Notes Input voltage is 5V, voltage range is from 4.75V-5.25V, please make sure the quality of the power supply of YQ series. Please make sure that all the power supply cables are plugged off when you want to connect or plug off any signal or controlling cables. -
Page 7: Function Instruction
Function instruction Control area There are two gigabit output ports, in YQ2A, Each gigabit port can support 1280× 1024 pixels, the maximum width ≤1920, the maximum height ≤1024. When the user screen parameter is ≤ 1280* 1024, refresh rate =60, video, stunt picture will be very smooth. Two gigabit output is consistent, you can connect dual-screen, synchronization display the same contents. - Page 8 module, also supports USB interface, external WIFI module. Built-in WIFI both as a hot spot (AP), but also as a terminal. Supports external 4G routers. For the general network topology, users can use the network cable directly access the router or switch, and management PC communication.
- Page 9 If the use of small users need to cross the public network, you can access iLEDCloud cloud platform, through the web browser to manage. Large group users can be managed from the deployment cloud platform iLEDsys system. If you need to cross the public network, you can create VPDN, to achieve across the public network of virtual intranet, to manage.
- Page 10 Text areas can be pictures or text, supporting a wealth of special effects, including curtain, pan, laser, mosaic, shutter and other common effects. Controller processor built-in GPU (graphics processing unit), you can achieve brilliant 3D effects. The controller supports a variety of time zones, you can set the font of analog dial, dial point, select the style, the color set.
-
Page 11: Technical Specifications
Support datebase The controller supports the database area, supports multi-page display, supports mySQL, sqlserver and other format database. Support Android App,easy operator It can be controlled with Android APP ledshow , managed easily. APP support search screen, support multi-language, support dynamic preview, video transcoding function. Support gesture zoom in and out of partition function. -
Page 12: Shape And Parameter Specification
Shape and parameter specification Physial dimension Physical dimension 194mm 118mm 46mm Back panel diagram... -
Page 13: Front Panel Diagram
Video input / output port DVI-IN 1080P@30HZ ， 1 HDMI CVBS P AL/NTSC ， DVI -OUT 1 HDMI Audio input / output port AUDIO-IN 1 3.5 mm stereo AUDIO -OUT 1 3.5 mm stereo Gigabit Ethernet interface OUT1 Scan data output port , connect with full color receiving card OUT2 Front panel diagram... - Page 14 Button description DC5V 5V Power interface, DC voltage input,rated voltage 5V, support4.5V ~ 6.5V XH254-3P Infrared receiver interface Indicator light , it will blink twice per minute when controller works good , Net work and fault indicating lamp MODE Video input mode switch button,Used to switch asynchronous programs quickly,CVBS A/SYNC input, and HDMI input OK button,confirmation button for the interactive menu;...
- Page 15 Contact Us Shanghai ONBON Technology Co.,ltd (Headquarters) Address: 7 Floor, Tower 88, 1199#, North Qinzhou Road, Xuhui District, Shanghai City, China Tel Phone: 086-21-64955136 Fax: 086-21-64955136 Website: www.onbonbx.com ONBON (Jiangsu) Optoelectronic Industrial Co.,LTD Address: 1299#, Fuchun Jiang Road, Kunshan City, Jiangsu Province, China...
