270-258.fm Page 1 Monday, August 9, 1999 9:25 AM
Outdoor Connection Box

Preparation for Mounting

1. Slide the cover off the back plate,
then thread a drop cable through the cen-
ter hole and attach it to the splitter's in-
port.
2. If you have a two- or four-way
splitter, attach the splitter's in-
port to the bracket marked
WAY or 4-WAY
If you have a three-way
splitter, attach the splitter's
in-port
to
the
bracket
marked
.
3-WAY
Note: If you have a four-way splitter
with a center-port to center-port clear-
ance of less than 1inch, cut off the left
arm of the bracket marked
fore you attach the splitter.
Three-Way
Cat. No. 270-258
2-
.
y
Four-Way
Two-Way
be-
3-WAY
