CONTROL AB323A5221 > > KL2334a LIST OF PARAMETERS CONNECTION DIAGRAM TIMING DIAGRAMS No. 402309 English FRANKL & KIRCHNER EFKA OF AMERICA INC. EFKA ELECTRONIC MOTORS GMBH & CO KG SINGAPORE PTE. LTD.
EFKA AB323A5221 CONTENTS Page 1 Putting into Service 2 Operating Elements and Socket Connectors Position of Operating Elements and Displays Position of the Socket Connectors Connection Diagram Connection of a Sewing Light with Transformer 3 Timing Diagrams 4 List of Parameters...
EFKA AB323A5221 1 Putting into Service Before putting the control into service, the following must be ensured, checked and/or adjusted: § The correct installation of the drive, position transmitter and accompanying devices, if necessary § If necessary, the correct adjustment of the direction of motor rotation by means of parameter 161 §...
EFKA AB323A5221 2 Operating Elements and Socket Connectors 2.1 Position of Operating Elements and Displays P key § Call or exit programming mode E key § Foot lifting pressure or puller in StartCycle On / Off § Enter key for modifications in the programming mode + key §...
EFKA AB323A5221 2.3 Connection Diagram Parameter 290 = 1 Inputs switched to 0V ATTENTION! When connecting the outputs, ensure that a total power of 96VA constant load will not be exceeded! in1 - Input 1 (JointSystem) i10 - Input 10...
Page 6
EFKA AB323A5221 Parameter 290 = 2 Inputs switched to 0V ATTENTION! When connecting the outputs, ensure that a total power of 96VA constant load will not be exceeded! in1 - Input 1 (sensor 1) i10 - Input 10 - Output 9...
Page 7
EFKA AB323A5221 Inputs switched to +24V ATTENTION! When connecting the outputs, ensure that a total power of 96VA constant load will not be exceeded! Nominal voltage 24V, no-load voltage max. 30V momentarily after power on Transistor output with open collector max. 40V, 10mA...
Page 8
EFKA AB323A5221 Connection of a HSM001 Hall sensor module Connection of a LSM002 light barrier module or an IPG001 pulse encoder Adapter cord 1113229 in case of multiple assignment of socket B18! POS2 OUT - Output for position 2 POS IN...
EFKA AB323A5221 EB.. Actuator Pedal step è è è è ½ Input A Input B Input C Input D 2.4 Connection of a Sewing Light with Transformer ATTENTION! efore opening the cover, turn power off! § Switch off the control and remove mains plug from outlet §...
EFKA AB323A5221 4 List of Parameters 4.1 Preset Values Depending on Mode All preset values of the different modes are listed in the table below. The parameters marked with “---“ are not available and cannot be called up. When switching the mode by means of parameter 290, all values change automatically.
Page 15
EFKA AB323A5221 Supplier Level Setting the functional sequence using parameter 290 Parameter Letter symbol Mode 1 Mode 2 2000 1600 1600 When programming the 3-digit or 4-digit control parameter values (without control panel), the 2-digit or 3-digit value displayed must be multiplied by 10.
EFKA AB323A5221 4.2 Operator Level Parameter Designation Unit Preset Ind. Pa. 290 = 1, 2 StL Stitch length by means of external puller motor mm 50.0 Pa. 290 = 1 dS1 Activation of sewing foot pressure signal at the mm 50.0...
EFKA AB323A5221 4.3 Technician Level Code no. 190 with control operation Code no. 1907 with control panel operation Parameter Designation Unit Preset Ind. SSc Number of softstart stitches stitches n1 Positioning speed n2- Upper limit setting range of the maximum speed RPM...
Page 18
EFKA AB323A5221 Technician Level Code no. 190 with control operation Code no. 1907 with control panel operation Parameter Designation Unit Preset Ind. Sr4 Checking of the signal outputs and inputs using the incorporated control panel or the V810/V820 control panels...
EFKA AB323A5221 4.4 Supplier Level Code no. 311 with control operation Code no. 3112 with control panel operation Parameter Designation Unit Preset Ind. t2 Sewing foot lift switch-on delay with half heelback t3 Start delay after disabling the sewing foot...
Page 20
EFKA AB323A5221 Supplier Level Code no. 311 with control operation Code no. 3112 with control panel operation Parameter Designation Unit Preset Ind. in1 Selection of the input functions on socket ST2/7 for input 1 = No function = Needle up/down...
Page 21
EFKA AB323A5221 Supplier Level Code no. 311 with control operation Code no. 3112 with control panel operation Parameter Designation Unit Preset Ind. in8 Selection of input function on socket ST2/10 for input 8 No function All other functions of the keys as with parameter 240...
Page 22
EFKA AB323A5221 Supplier Level Code no. 311 with control operation Code no. 3112 with control panel operation Parameter Designation Unit Preset Ind. PGm Connection of a sensor e. g. light barrier sensor to light barrier socket B18/7. Selection of the desired...
Page 23
EFKA AB323A5221 Supplier Level Code no. 311 with control operation Code no. 3112 with control panel operation Parameter Designation Unit Preset Ind. 810 Select slide-in strip number for the V810 control panel (corresponds to slide-in strip no. 11) 820 Select slide-in strip number for the V820 control...
EFKA AB323A5221 5 Error Displays General Information On the control On the V810 On the V820 Signification InF A1 InFo A1 Pedal not in neutral position, when turning the machine on -StoP- blinking -StoP- blinking + Machine run blockage symbol display...
EFKA AB323A5221 6 Operating Elements of the V810 Control Panel variocontrol 810 KL2527 Function Assignment to the Keys P key = Call or exit of programming mode E key = Enter key for modifications in the programming mode + key = Increase of the value indicated in the programming mode...
