- Page 3 TABLE OF CONTENTS Important Safety Parts Description Instructions Tools Needed Installation Warranty Information...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS • Check if all the parts are complete before installation. • Your computer desk is very heavy. Two people are recommended to assemble it. • Read through the instructions before installing the computer desk. • Do not tighten all the screws until the entire unit has been assembled and set up well. •...
- Page 5 PARTS DESCRIPTION x1 PC x1 PC x1 PC x2PCS x1 PC x4PCS x4PCS x1 PCS M6x12 M6x30 M6x35 M7x50 M6x55 M4x12 x4PCS x4PCS x8PCS x4PCS x4PCS x12PCS Grommet Foot pad Cable clip Wrench Keyboard tray slider x1 PC x8PCS x2PCS x4PCS x1 SET TOOLS NEEDED...
- Page 6 INSTALLATION Step 1: Attach the foot pads to the desk legs. IMPORTANT NOTE: Do not tighten all the screws until the entire unit has been assembled and set up well. Hx8pcs COMPUTER DESK | 6...
- Page 7 INSTALLATION Step 2: Insert screw E through 8 , 6 , and 7 in turn and tighten them securely. Use screw C to assemble 6 to 7 . Top View Cx4pcs Ex4pcs M6x35 M6x55 COMPUTER DESK | 7...
- Page 8 INSTALLATION Step 3: Install the boards 4 . Dx8pcs M7x50 COMPUTER DESK | 8...
- Page 9 INSTALLATION Step 4: Install the desk boards onto the metal frame. The positions of 1 and 2 can be interchanged. You can select an installation option according to the cable entry holes locations. Bx12pcs M6x30 COMPUTER DESK | 9...
- Page 10 INSTALLATION Step 5a: Install the keyboard tray sliders. You can select to install the keyboard tray at left side or right side. (right) (left) Ax4pcs Kx1set M6x12 COMPUTER DESK | 10...
- Page 11 INSTALLATION Step 5b: (left) (right) Ax4pcs Kx1set M6x12 COMPUTER DESK | 11...
- Page 12 INSTALLATION Step 6: Install the keyboard tray 5 . Press the grommet (I) to the cable hole and cover it. Screwdriver Backside Fx4pcs Ix2pcs M4x12 COMPUTER DESK | 12...
- Page 13 INSTALLATION Step 7: Check all the parts and tighten all the screws. If needed, adjust the foot pads to make sure the desk is stable. Stick the cable clip (J) in place to fix the wires if necessary. 3. Fasten 2.
- Page 14 (c) exposure to liquid or infiltration of foreign particles; (d) servicing or modification of the product other than by RIF6. These are our general terms for the warranty service, but we always urge our customers to reach out to us with any issue, regardless of warranty terms. If you experience an issue with a RIF6 product, please contact us at support@RIF6.
- Page 16 COMPUTER DESK | 16...
