AS22252
FOLDING MITER SAW STAND
MFG Date
Purchase Date
1
ITEM #5091193
MODEL #ST0702LW
Español p. 21
Advertisement
Table of Contents
Related Manuals for Kobalt ST0702LW
Summary of Contents for Kobalt ST0702LW
- Page 1 ITEM #5091193 FOLDING MITER SAW STAND MODEL #ST0702LW Español p. 21 KOBALT and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved. ATTACH YOUR RECEIPT HERE Serial Number MFG Date Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 888-3KOBALT (888-356-2258), 8 a.m.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Specifications ...................... Package Contents ......................General Safety ......................... Miter Saw Stand Safety ....................Preparation........................Assembly Instructions ....................... Adjustment Instructions ..................... Operating Instructions ....................... Maintenance ........................ Replacement Parts List ..................... Warranty ..........................PRODUCT SPECIFICATIONS Stand height 34-3/14 in. (869 mm) (ground to saw mounting brackets) Stand bed size 44-7/8 in. -
Page 3: Package Contents
PACKAGE CONTENTS UNPACKING YOUR STAND This product requires assembly. 1. Remove the stand and all parts from the carton. 2. Place the stand on the ground. 3. Separate all parts from the packing material. Check each one with the list and illustration below to make certain all items are accounted before discarding any packing material. - Page 4 KNOW YOUR STAND Front of Stand PART DESCRIPTION QUANTITY Extension support arm assembly Power cord wrap Stop plate Stop plate adjustment knob Height adjustment knob of extension arm support Stand leg Rail bed Miter saw mounting brackets lock knob Stand leg lock lever Extension support lock knob...
-
Page 5: General Safety
GENERAL SAFETY GENERAL SAFETY INFORMATION WARNING Read and understand all warnings and operating instructions before using any tool or equipment. When using tools or equipment, basic safety precautions should always be followed to reduce the risk of personal injury. Improper operation, maintenance or modification of tools or equipment could result in serious injury and property damage. -
Page 6: Miter Saw Stand Safety
MITER SAW STAND SAFETY SAFETY INSTRUCTIONS FOR USING THE MITER SAW STAND ● Keep children away. All visitors should be kept at a safe distance from the work area. ● Always keep work area clean. Cluttered areas and benches invite accidents. ●... - Page 7 ● Always wear eye protection with side shields that meets the requirements of ANSI Z87.1 when working with the miter saw to prevent eye injury. Ordinary eyeglasses do not provide adequate protection because they do not contain impact resistant safety glass. Also, use a face mask for additional safety and wear a dust mask if the cutting operation produces dust.
-
Page 8: Preparation
PREPARATION Before beginning assembly or operation of the product, make sure all parts are present. Compare parts with package contents list and hardware contents list on page 3. If any part is missing or damaged, do not attempt to assemble, install or operate the product. Estimated Assembly Time: 5~10 minutes Tools required for assembly (not included): Adjustable Wrench, 5 mm Hex Wrench. -
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS WARNING For your own safety, never connect miter saw plug to any power source outlet until all assembly and adjustment steps are completed, and you have read and understood the safety and operating instructions. INSTALLING THE EXTENSION SUPPORT ARM ASSEMBLY (FIG. - Page 10 INSTALLING THE MITER SAW MOUNTING BRACKETS (FIG. 3) ● Turn the lock knob (L) counterclockwise to lose the tension of mounting brackets (B). ● Place the front holding clamp (1) on the front rail of the stand, and then lower the back end of the bracket over the back rail of the stand.
-
Page 11: Adjustment Instructions
ADJUSTMENT INSTRUCTIONS ADJUSTING THE EXTENSION SUPPORTS (FIG. 5) The extension support helps keep the workpiece level and stable during cutting operations. ● Loosen the extension support lock knob (N) and slide the extension support to the desired length. Tighten the extension support lock knob (N). -
Page 12: Operating Instructions
OPERATING INSTRUCTIONS WARNING Take care when setting up and folding the stand to reduce the hazard of pinching hands and fingers. SETTING UP THE STAND (FIG. 7, 8) ● Lift up the stand, and press the stand leg lock levers (M) to unfold the stand legs. The location pin should be locked into the lower slot (1). - Page 13 MOUNTING THE MITER SAW TO THE STAND (FIG. 10) WARNING ● Do not mount the miter saw to the stand without first ensuring the stand is extended fully and locked securely. To set up the stand, follow the instruction in section “SETTING UP THE STAND”...
- Page 14 ● Insert the bolts (1) through the washers (2), the mounting holes (3) of the miter saw and the slots of the saw mounting brackets (B) into the square nuts (4) to mount and lock the miter saw to the saw mounting brackets (B). ● Tighten all bolts (1) using a 5 mm hex wrench.
- Page 15 NOTE: If you do not have a 10” miter saw, you must use 3/4” (19 mm) plywood to mount your miter saw. The plywood must be a minimum of 4” (101.6 mm) wider than the largest width of the miter saw base. The plywood should be at least as deep as the smallest depth of the miter saw base or a minimum of 16”...
-
Page 16: Maintenance
MAINTENANCE WARNING ● Always wear safety goggles or safety glasses with side shields and dust mask during power tool operation or when blowing dust. ● Ocassionally check the saw mounting brackets, making sure the mounting brackets are tight by following “ADJUSTING THE MITER SAW MOUNTING BRACKETS” on page 11. GENERAL MAINTENANCE Remove the miter saw when servicing or cleaning the stand. -
Page 17: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 888-3KOBALT(888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also contact us at partsplus@lowes.com. Left Right PART DESCRIPTION PART # Miter saw mounting brackets X8FV (Left) / X8FU (Right) Extension support arm &... - Page 18 PAGE INTENTIONALLY LEFT BLANK...
- Page 19 PAGE INTENTIONALLY LEFT BLANK...
-
Page 20: Warranty
WARRANTY The manufacturer will offer replacement parts for this product which under normal usage have proven to be defective in their manufacture or workmanship for a period of THREE (3) years from the date of initial retail purchase. This warranty is valid only to the original purchaser. This warranty is not transferable and does not cover any parts that have been subjected to misuse, abuse, alteration, overload, accident or normal wear of moving parts.
