User Guide
SOEKS EcoVisor F4
The following user guide will provide you with
comprehensive information on how to use your
SOEKS EcoVisor F4 device. We strongly recommend
you read the entire user guide and follow all of the
instructions listed on this guide.
The manufacturer has the right to change the
interface of the device after updating the device's
firmware.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EcoVisor F4 and is the answer not in the manual?

Questions and answers

Related Manuals for SOEKS EcoVisor F4

Summary of Contents for SOEKS EcoVisor F4

  • Page 1 SOEKS EcoVisor F4 The following user guide will provide you with comprehensive information on how to use your SOEKS EcoVisor F4 device. We strongly recommend you read the entire user guide and follow all of the instructions listed on this guide.

  • Page 2: Table Of Contents

    Contents CONTENTS ....................................2 SAFETY INSTRUCTIONS ................................4 DESCRIPTION AND DEVICE OPERATION ............................5 ........................................5 URPOSE ......................................5 PECIFICATIONS SOEKS E F4 .................................. 7 EVICE ISOR PROPER USE....................................7 ..................................... 7 WITCHING .................................... 7 AIN MENU OF THE DEVICE ....................................
  • Page 3 ....................................22 ATTERY REPLACEMENT ................................... 22 CCUMULATOR CHARGING PERFORMANCE LIFE, STORAGE AND RECYCLING ........................23 ..................................... 23 ERFORMANCE LIFE ........................................23 TORAGE ........................................ 23 ECYCLING TRANSPORTATIONS.................................. 23 MANUFACTURER'S WARRANTY ..............................23...

  • Page 4: Safety Instructions

    Safety instructions Before using the device, please read all of the safety instructions listed below and pay attention to them when using the device. Disregard of safety instructions can lead to malfunction or total breakdown of the device. The manufacturer's warranty is not valid if it is discovered the reason of breakdown because of failure to follow the safety instructions below.

  • Page 5: Description And Device Operation

    Description and device operation Purpose SOEKS EcoVisor F4 is designed to: • perform express analysis of nitrate contents in fresh fruit and vegetables. Nitrate content analysis is based on conductivity of alternating high-frequency current in the measured product (ionometry). •...
  • Page 6 Scale range of magnetic field (magnetic From 0.08 to 20 (from 0.10 to 25) induction) intensity crest value, A/m (meTl) Max. permissible relative measurement ± 18% uncertainty of magnetic field intensity, % Scale range of magnetic field intensity crest From 10 to 5000 value, V/m Max.

  • Page 7: The Device Soeks Ecovisor F4

    The Device SOEKS EcoVisor F4 Main parts of the device consist of: Micro USB slot for charging the accumulator. Touchscreen for displaying information and menu navigation. OK button for switching the device on/off, confirmation button. LEFT button for menu navigation, return to previous menu when pressing for 2 seconds.

  • Page 8: Service Information

    Measurement of nitrate content level is based on the patented technology of a biobased product ionometry (Patent of invention № 23 90 767 ionometry. Method for biobased products and the device for its performance) and has been developed by the SOEKS company.
  • Page 9 That kind of analysis requires a lot of time and is not free. Nevertheless, the presence of such laboratory and qualified analytical chemist at home is impossible for the majority of people. The EcoVisor F4 is a like portable lab that allows you to avoid buying suspicious products.
  • Page 10 After entering the "Nitrate tester" mode. you will see a list of products. You must choose a product from the list. Press the UP and DOWN icons on the display or press LEFT and RIGHT buttons on the device to navigate through the menu. You can confirm your choices by pressing icon of the product in the list or by pressing OK button on the device.

  • Page 11: Radiation Measurement - Dosimeter

    After the measurement process is completed, information about the nitrate content in the product will be displayed. "Normal nitrate content. The product is safe for consumption. "Insignificant excess of standard". Product can be consumed in small quantity. Heat processing is recommended.
  • Page 12 For instance, radiation background at highlands is always higher than at low land. SOEKS EcoVisor F4 measures radiation in micro Sieverts per hour (mSv/h) and micro roentgen (mcR/h), where 0.01 mSv/h corresponds to 1 mcR/h according to biological radiation effect.
  • Page 13 Natural radiation background usually ranges from 0.08 mSv/h till 0.18 mSv/h. Safe radiation background level for a human is considered to be up to 0.4 mSv/h (the 0.4 mSv/h exposure per hour). When Level of Radiation is exceeded (more than 0.4 mSv/h), the recommended time of staying in an irradiation area is regressive.

  • Page 14: Electromagnetic Field Measurement - Emf Meter

    Measure the radiation exposure level at a distance of a few meters from the measured object. Set the device directly near the measured object and measure the radiation exposure at the possible nearest distance to the measured object. Compare the results that have been received at a distance and near the object. In order to measure contaminated liquid, measure directly above the water's surface.

  • Page 15: Electromagnetic Field In Facilities

    Nowadays it is experimentally proven that electromagnetic fields negatively affect immunologic reactivity of body. Research data points to the fact that immunogenesis processes are violated and suppressed when being affected by electromagnetic fields. When being affected by electromagnetic fields, changes in the pituitary adrenal system may occur. When being affected by electromagnetic fields, pituitary adrenal system is stimulated and therefore the amount of adrenalin in the blood rises and can trigger blood clotting.

  • Page 16: Electromagnetic Field From Pc

    Electromagnetic field from TV with a diagonal less than 51 cm (20”) is measured at a distance of 50 ± 1 cm in front, behind and next to the TV. When screen diagonal is more than 51 cm, the EM field is measured the same way at a distance of 100 ± 1 cm. The device must be preliminarily turned on and work at least 20 minutes before measuring.
  • Page 17 Hard water negatively affects digestive system, hair and skin when we shower. It can also cause kidney diseases. With the help of EcoVisor F4 now, it is possible to determine whether the water is suitable for drinking, domestic needs or if it requires purification.
  • Page 18 After entering the "WATER MEASUREMENT" mode, probe calibration is performed. When calibrating, the probe must not be in the water. After calibrating, recommendations on how to dip the probe in the water will be displayed. It is necessary to dip the probe into water, wait until temperature stabilizes (indication will be shown in upper right corner of the display) and press MEASURE icon on the display or OK button on the device.

  • Page 19: Settings

    Settings In the "SETTINGS" mode, it is possible to perform device settings against the following parameters: setting up radiation measurement units; setting up radiation background threshold; setting up accumulated dose threshold; setting up display brightness; sound settings; setting up time of switching to sleep mode; setting up time of shutting down the device;...

  • Page 20: Setting Up Accumulated Dose Threshold

    Setting up accumulated dose threshold ln this menu selection, you can set up accumulated dose threshold and the device will notify you when it is exceeded. The threshold can be set up from Oto 1 Sv (or from Oto 100 R). In order to choose the unit, press LEFT and RIGHT icons on the display or LEFT AND RIGHT buttons on the display case.

  • Page 21: Setting Up Time Of Automatic Switching Off The Device

    Setting up time of automatic switching off the device In this menu selection, you can set up time of automatic switching off (from 1 to 60 minutes) or to turn the mode off. In order to choose the unit, press LEFT and RIGHT icons on the display or LEFT AND RIGHT buttons on the display case.

  • Page 22: Switching Off Touchscreen

    Switching off touchscreen In this menu selection, you can switch off the touchscreen. The setting is performed by pressing “ ✓ ” icon on the display or LEFT and RIGHT buttons on the display case. When touchscreen function is turned off, it is necessary to press and hold RIGHT button, in order to switch between hours and minutes.
  • Page 23 Performance life, storage and recycling Performance life Performance life is 8 years from the selling date. Storage The device in the original package must be kept in heated warehouse with the air temperature from +5 to +40 C and maximum relative humidity 80% at the 25 grades temperature.
  • Page 24 We recommend that you read thoroughly the instructions outlined in this manual before contacting the warranty repair service. Please send all your comments to our e-mall address at our official website: Soeks.Store The guarantee shall be void if: The serial number of the device is not the same as the number in the guarantee coupon.
