- Page 1 Installation guide 1U Enterprise Revision 1.0...
- Page 2 The development of Aculab’s products and services is continuous and published information may not be up to date. It is important to check the current position with Aculab plc. Copyright © Aculab plc. 2011 – 2012 all rights reserved.
-
Page 3: Table Of Contents
1.1.8 Electrostatic discharge precautions ............6 1.1.9 1U chassis physical details ..............6 1.2 Powering the Prosody X on......................7 1.3 Powering the Prosody X off ......................7 1.4 E1/T1 trunk numbering ........................ 7 1.5 Ethernet connections........................8 1.6 Cabling ............................8 1.6.1 Cable pinouts ................... - Page 4 F.6 Regulierungszeichen .........................21 Appendix G: Earthing requirements for Scandinavia ............. 22 Appendix H: Technical Specifications ..................22 Appendix I: Prosody X documentation references ..............22 TABLE OF FIGURES Figure 1-1 1U chassis front layout (4 trunk shown) ............7 Figure 1-2 RJ45 pin numbering ..................9 Figure 1-3 75 Ohm E1 Balun ..................
-
Page 5: Getting Started
1.1.5 Airflow and cooling CAUTION The chassis uses forced air-cooling internally. It is imperative that Prosody X systems are operated with all covers fitted and that none of the ventilation holes/slots on the front, or rear of the chassis are obstructed. Installation in a rack should be such that the airflow required for safe operation is not compromised. -
Page 6: Power Connection
Prosody X Installation guide 1.1.6 Power connection The Prosody X is supplied as an AC powered system. The Prosody X will auto adjust to the supplied voltage in AC installations (100 to 240 volts AC ± 10% at 50 to 60Hz ±... -
Page 7: Powering The Prosody X On
Check that the electrical outlet is grounded and it is within the permitted range shown on the rating label • Plug the power cord into the AC power inlet socket on the rear of the Prosody X • Connect the other ends of the power cord into a suitable electrical outlet •... -
Page 8: Ethernet Connections
Ethernet switch. Cabling The Prosody X is connected to other network equipment via CAT 5, 5e, 6 or 6e cables. There are two types of interface and they have different pin assignments. The pin-out of the RJ45/48 connectors for both E1/T1 and Ethernet connections are detailed below. -
Page 9: Cable Pinouts
Some legacy E1 PSTN networks require 75 Ohm trunk connection. The default impedance for E1 trunks in the Prosody X is 120 Ohm. It is important to confirm with the network operator which impedance the PSTN is using during the installation process, as a mismatch can lead to signal degradation and erratic equipment behaviour that is difficult to diagnose later. -
Page 10: Cable Lengths
For E1 trunks converted to BNC cabling, it is recommended that overall span length is limited to 100m maximum and that 75 Ohm cabling and connectors are used. The 75 Ohm adapter should be installed close to the Prosody X RJ45 socket to minimise impedance mismatch effects. -
Page 11: Initial Hardware Checks
Prosody X Installation guide Initial hardware checks When the Prosody X is turned on, the STARTING UP indicator will turn on and the unit will go through the boot sequence. Using the AIT/ACT guide, the card can be configured. Configuring the card is indicated by LOADING. When complete, the IN SERVICE indicator on the front panel will turn on. -
Page 12: Hardware Maintenance
Contact your supplier for advice on fan replacement if the unit is out of warranty. Moving an installed Prosody X A Prosody X should not be moved while operating. If a Prosody X has to be moved, the power must be disconnected to prevent equipment damage or risk to operator safety. -
Page 13: Appendix A: Usa/Canada Approval Details
Prosody X Installation guide Appendix A: USA/Canada approval details This section applies only to E1/T1 trunk interfaces configured for T1 operation. FCC connection requirements This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the exterior of the cabinet of this equipment is a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX. - Page 14 Approval number US:5TCXDNANCapplianX Approval holder Aculab plc, Lakeside, Bramley Road, Mount Farm, Milton Keynes. MK1 1PT, UK FCC approves the apparatus for connection to public T1 services as specified in the approval certificate, this appendix, and the 'Installation guide' subject to the conditions set out in these documents.
-
Page 15: Appendix B: Approval Details For Uk And Other Eu Countries
Prosody X Installation guide Appendix B: Approval details for UK and other EU countries 15 of 22... -
Page 16: Appendix C: Approval Details For Australia
Specialists, and subject to the conditions set out in this appendix. Usage and type The Prosody X is principally designed for use connected to a 2048 Kbps integrated services digital network (primary rate ISDN) with TS038 signalling including the New Zealand Primary Rate ISDN network (not currently covered by approval). -
Page 17: Appendix D: Warranty And Support
Returned Material Authorisation procedure. Spare parts and accessories Please take a note of the serial number on the Prosody X when contacting your supplier for spare parts, and ensure you mention the parts are for a Prosody X chassis. -
Page 18: Appendix E: Safety Information
CAUTION Under no circumstance connect the Prosody X to a power source with voltage or frequency different to that stated. Contact your local supplier for advice if your power input is different to that shown on the rating label. -
Page 19: Grounding The Prosody X
Use a grounded 3 connection IEC60320 AC power cable Serviceable parts The Prosody X has no user serviceable parts inside. Regulatory marking The CE Marking has been applied to the Prosody X to demonstrate compliance with the following European standards: • EN55022 and EN55024 for electromagnetic compatibility. -
Page 20: Appendix F: Sicherheitshinweise
Das Typenschild gibt die erlaubte Stromstärke und den Frequenzbereich für dieses System wieder. VORSICHT Schliessen Sie Prosody X unter keinen Umständen an eine andere als die angegebene Stromquelle mit dem vorgegebenen Frequenzbereich an. Setzen Sie sich mit einem für ihre Region zuständigen Lieferanten in Verbindung, wenn Ihre Spannungsversorgung vor Ort nicht der auf dem Typenschild angegebenen entspricht. -
Page 21: Prosody X - Erdung
Prosody X muss wie folgt geerdet werden: • Verwenden Sie ein geerdetes 3-poliges Wechselstromkabel des Typs IEC60320 Wartungsteile Prosody X beinhaltet keine Teile, die vom Benutzer gewartet werden müssen. Regulierungszeichen Das CE-Prüfzeichen gewährleistet, dass Prosody X den folgenden europäischen Standards entspricht. -
Page 22: Appendix G: Earthing Requirements For Scandinavia
E1 Trunks meet ITU G.703/G.704 recommendations: • Default 120 Ohm termination (75 Ohm configuration option) T1 Trunks meet ANSI T1.403 recommendations: • Fixed 100 Ohm termination Appendix I: Prosody X documentation references General Prosody X documentation: www.aculab.com 22 of 22...
