- Page 1 1U High Availability Chassis Installation guide Revision 1.4...
- Page 2 The development of Aculab’s products and services is continuous and published information may not be up to date. It is important to check the current position with Aculab plc. Copyright © Aculab plc. 2012-2015 all rights reserved.
-
Page 3: Table Of Contents
2.1.1 Battery replacement ................14 2.2 Cooling fan failure ........................14 2.3 Power Module Failure ........................ 15 2.4 Moving an installed Prosody X 1U HA chassis ............... 16 2.5 Basic fault finding ........................16 Appendix A: USA/Canada approval details ................17 USA federal communication commission warnings ................ - Page 4 Appendix I: Field Replaceable Spares ..................25 TABLE OF FIGURES Figure 1-1 Prosody X 1U HA chassis front layout (16 trunk shown) ........7 Figure 1-2 Prosody X 1U HA chassis rear layout (AC Input shown) ........7 Figure 1-3 AC power inlet connectors ..................8 Figure 1-4 DC power inlet terminals and polarity ..............
-
Page 5: Getting Started
1.1.5 Airflow and cooling CAUTION The chassis uses forced air-cooling internally. It is imperative that Prosody X 1U HA systems are operated with all covers fitted and that none of the ventilation holes/slots on the front, or rear of the chassis are obstructed. -
Page 6: Power Connection Ac Option
Prosody X Installation guide 1.1.6 Power connection AC option The Prosody X 1U HA chassis can be supplied as an AC powered system. The AC chassis power modules will auto adjust to the supplied voltage in AC installations (90V to 264V AC at 47 to 63Hz). -
Page 7: Prosody-X 1U Ha Chassis Physical Details
Prosody X Installation guide 1.1.10 Prosody-X 1U HA chassis physical details The Prosody X 1U HA chassis is designed to fit into 19 inch rack mounting cabinets commonly found in telecoms switch room environments. Width Depth Height Weight # With rack mounts... -
Page 8: Powering The Prosody X Ha 1U On
Prosody X Installation guide Powering the Prosody X HA 1U on Connect power cords to the Prosody X 1U HA chassis according to the following procedure: • Check that the electrical outlet is grounded and it is within the permitted range shown on the rating label •... -
Page 9: Powering The Prosody X 1U Ha Chassis Off
Ethernet switch equipment, which can sustain the required data throughput with little or no packet loss. There are two Prosody X 1U HA chassis IP communication interfaces, as this can offer additional redundancy, if required, in a correctly configured network. -
Page 10: Ethernet Leds
The left-hand LED, yellow LED indicates link speed, on for 1000-BaseT and off for 100-BaseT. Cabling The Prosody X 1U HA chassis is connected to other network equipment via Cat 5e or Cat 6 cables. There are two types of interface and they have different pin assignments. -
Page 11: Cable Pin-Outs
Some legacy E1 PSTN networks require 75 Ohm trunk connection. The default impedance for E1 trunks in the Prosody X 1U HA chassis is 120 Ohm. It is important to confirm with the network operator which impedance the PSTN is using during the installation process, as a mismatch can lead to signal degradation and erratic equipment behaviour that is difficult to diagnose later. -
Page 12: Cable Lengths
Ethernet equipment legacy compatibility The Prosody X IP communication interfaces are designed to operate at Fast Ethernet (100Base-T) or Gigabit Ethernet (1000Base-T) data rates. If connected to network equipment that is not Fast Ethernet capable, the interface will attempt to negotiate a 10Base-T link speed. -
Page 13: System Initialisation
The system start-up process will run automatically at power on. Initial hardware checks When the Prosody X is turned on various LED indicators are used to indicate the state of the system. The two power supply status LEDs will be illuminated at all times in normal operation. -
Page 14: Hardware Maintenance
Hardware maintenance Servicing Other than a Lithium battery, there are no user serviceable parts inside the Prosody X 1U HA chassis. The unit may optionally be powered off for inspection every year and to remove any dust that accumulates internally. This should only be performed by qualified technical personnel. -
Page 15: Power Module Failure
Note: the front and rear fan assemblies are not the same. Power Module Failure The Prosody X 1U HA chassis has a redundant power system. LEDs on the front panel and on each power module show the power module is operating. If a single module fails the appropriate LED, marked on the front panel, will go out and an alarm will sound. -
Page 16: Moving An Installed Prosody X 1U Ha Chassis
The replacement power module LEDs, front and rear should now come on. Moving an installed Prosody X 1U HA chassis A Prosody X 1U HA chassis should not be moved while operating. If a Prosody X 1U HA chassis has to be moved, the power must be disconnected to prevent equipment damage or risk to operator safety. -
Page 17: Appendix A: Usa/Canada Approval Details
Prosody X Installation guide Appendix A: USA/Canada approval details This section applies only to E1/T1 trunk interfaces configured for T1 operation. FCC connection requirements This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the exterior of the cabinet of this equipment is a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX. -
Page 18: Usa Federal Communication Commission Warnings
This device must accept any interference received, including interference that may cause undesired operation. No changes or modifications to the Prosody X are allowed without explicit written permission from Aculab. Any changes or modifications could void the end users authority to operate the device and invalidate the warranty. -
Page 19: Appendix B: Approval Details For Uk And Other Eu Countries
Prosody X Installation guide Appendix B: Approval details for UK and other EU countries Disposal of equipment at end of service life Please contact Aculab plc for instructions on how to dispose of this WEEE equipment. 19 of 25... -
Page 20: Appendix C: Approval Details For Australia
Specialists, and subject to the conditions set out in this appendix. Usage and type The Prosody X is principally designed for use connected to a 2048 Kbps integrated services digital network (primary rate ISDN) with TS038 signalling including the New Zealand Primary Rate ISDN network (not currently covered by approval).
