PRODUCT MANUAL
16 Litre Dehumidifier
Product Code:
Serial Number Range:
Year Of Manufacture:
KEEP THIS BOOKLET FOR FUTURE REFERENCE
Nottingham: 0115 946 1988
London: 0208 830 3333
Nottingham: sales@hscgroupuk.co.uk
London: sean@hscgroupuk.co.uk
240 Volt
DHP20
www.hscgroupuk.co.uk
The Hire Supply Company (UK) Limited
Advertisement
Table of Contents
Related Manuals for HSC Master DHP20
Summary of Contents for HSC Master DHP20
- Page 1 PRODUCT MANUAL 240 Volt 16 Litre Dehumidifier Product Code: DHP20 Serial Number Range: Year Of Manufacture: KEEP THIS BOOKLET FOR FUTURE REFERENCE Nottingham: 0115 946 1988 www.hscgroupuk.co.uk London: 0208 830 3333 The Hire Supply Company (UK) Limited Nottingham: sales@hscgroupuk.co.uk London: sean@hscgroupuk.co.uk...
-
Page 2: Table Of Contents
EN - INSTRUCTION MANUAL 1 Device models ......................2 Product overview ......................3 Control panel ....................... 4 About this operating manual ..................5 Product description ....................6 Safety ........................... 7 Transport and installation ..................8 Device operation and control..................9 Maintenance and care....................10 Troubleshooting...................... -
Page 3: Product Overview
2 Product overview Illustration 1: Front and rear view Control panel Recess for stacking Castor Base Inlet air grille with filter holder Handle Operating hours counter Cable winder Air outlet Carry handle Button/indicator Description Operating hours counter Display of operating hours... -
Page 4: Control Panel
3 Control panel Illustration 2: Control panel Hygrostat rotary selector Red fault indicator Yellow indicator Device switch Green indicator Button/indicator Description Device switch Switching device ON/OFF: ■ Position [I]: Device continuously on ■ Position [II]: Starting pump and draining off condensate Indicators Operating status of device: ■... -
Page 5: About This Operating Manual
4 About this operating manual 5 Product description This operating manual (hereinafter referred The device dehumidifies the air in the room. to as the manual) allows the operator to op- In the process, condensate collects in the erate the humidifier (referred to as the condensate tank from where it can be re- device) safely and efficiently. -
Page 6: Safety
Intended use ■ Maintenance and troubleshooting tasks must be performed by suitably qualified The device is intended solely for dehumidi- fying air at atmospheric pressure in a com- persons only. Shut down the device and mercial environment. disconnect the mains plug. WARNING! Risk of explosion, injury from Intended use also includes compliance with burns or poisoning by refrigerant... -
Page 7: Transport And Installation
WARNING! Risk of infection 7 Transport and installation The condensate may be contaminated with Transport pathogens. WARNING! Risk of injury from device Ü Never drink the condensate. toppling over Ü Regularly pump off the condensate. Ü Transport the device in an upright posi- Avoid leaving condensate in the collect- tion and secure it against tipping or slip- ing vessel or in the condensate drain... -
Page 8: Device Operation And Control
Report any transport damage or incom- 3. The power socket to which the device is plete delivery to your dealer. connected must be equipped with a RC circuit breaker. This is particularly import- Adjusting handle ant for operation in humid rooms and on 1. -
Page 9: Maintenance And Care
ð The device switches off automatically ATTENTION! Risk of damage to property as soon as the set target humidity is Ü Detergents can cause damage to sur- reached. The device remains however faces. Use only mild detergents. in ready mode. If the target humidity is Ü... - Page 10 8. Mount the filter holder together with the filter in the same way as it was installed at the factory. Cleaning evaporator ü The evaporator must be de-iced and dry. 1. Switch off the device at the device switch and disconnect the power plug. Illustration 3: Removing condensate tank 2.
-
Page 11: Troubleshooting
10 Troubleshooting Ü Before starting work, allow hot compon- WARNING! Risk of poisoning by refriger- ant, injury from burns, crushing or elec- ents to cool down. tric shock during troubleshooting Faults and malfunctions during Ü All work in connection with troubleshoot- operation ing and repairs must be carried out by In the event of a fault or malfunction, refer to... -
Page 12: Repair
11 Repair Storage During the warranty period, all repairs must be performed by persons authorised by the CAUTION! Risk of injury from device top- manufacturer. pling over Ü Do not stack more than two devices one After the warranty period has elapsed, cer- tain repair can be carried out by the device on top of the other. -
Page 13: Ec Declaration Of Conformity
13 EC Declaration of Conformity EC Declaration of Conformity in accordance with Low Voltage Directive 2014/35/EC An- nex IV Manufacturer: DANTHERM Via Gardesana 11 37010- Pastrengo (VR), S.p.A ITALY Product: Dehumidifier Type: DHP 20 We herewith declare that the machine conforms to all relevant requirements of the fol- lowing EU Directives: ■... - Page 14 Technical Data Model DHP 20 Article-no. 0110-0020-062 230 V / 50 Hz W max. 395 W 10 A min. 60 dB(A) (3 m) 490 / 330 / 360 mm H/W/L 21 kg R1234YF / 0,27 kg + 5 °C — + 32 °C 375 m 16 l / 24 h 30 °C / 80 % 4,7 l / 24 h 20 °C / 60 %...
- Page 15 Recycling ENVIRONMENTAL PROTECTION: Please recycle any unwanted materials as opposed to disposing them as general waste. It is recommended the original is retained and used to store the product when not in use for prolonged periods of time. If this is not applicable ensure the materials are sorted and recycled in accordance with local regulations SPECIFICATION CHANGE: It is our policy to continually improve products to ensure these meet the rigours of the industry we serve.
