Assembly Guide
Cubii JR2+ Compact Elliptical
Remove all of the components from the Cubii JR2+ box.
Included you should find:
A CUBII JR2+ UNIT BODY E SCREWDRIVER
B LEFT AND RIGHT PEDALS F CHARGING CABLE
C WHEEL CUP STOPPER G AC POWER ADAPTER
SCREWS (X4)
D
A
F
D
C
G
E
STEP 1 — Align
Align the right pedal with
the right arm. Insert the
bottom of the pedal into
the two small holes.
STEP 2 — Flip
For maximum support,
make sure you flip the
pedal you are assembling
so it is at the bottom and
close to the base.
STEP 3 — Screw
With a screwdriver, screw
in the pedal until tight.
Make sure it does not
wobble.
B
STEP 4 — Repeat
Repeat steps 1-3 with the left pedal.
CHARGING YOUR JR2+
The charge port is located above the
crossbar near the front of the unit. Once
plugged in, the screen will power on and the
lightning bolt symbol will flash to indicate the
unit is charging. The symbol will remain solid
when it is fully charged.
The Cubii App
BLUETOOTH®* APP FEATURES
The app supports many features such as:
• Personalize your profile and workout goals
• Track activity and see your progress
• Adjust certain elliptical settings
• Create or participate in group leaderboards
• Chat with friends and socialize in our one-
of-a-kind Cubii Communitii
™
• and much more!
*The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Fitness Cubed Inc is under
license. Other trademarks and trade names are those of their respective owners.
INSTALLING THE CUBII APP
The Cubii app is currently available on your app store by searching for
"Cubii". For more detailed information on downloading, installing, or
using the Cubii app, see the included JR2+ Owner's Manual.
PAIRING WITH THE CUBII APP
To pair with the Cubii app, please follow these instructions:
1. Start pedaling to trigger the Bluetooth® signal. You'll see the
Bluetooth® symbol glow and start blinking on the display console.
2.
Confirm that you've enabled Bluetooth® Wireless Technology in your
device's settings.
3. The app will detect your Cubii elliptical via Bluetooth® Wireless
Technology. Select your elliptical in the app.
4. Once successfully paired, the Bluetooth® symbol will stop blinking.
5. Select if you would like to become User 1, User 2, or proceed as Guest.
6. Start your workout and enjoy your Cubii experience!
From here on, every time you launch the app, it will search for all Cubii
devices in your vicinity and automatically connect with an elliptical that
it has already paired with. If it does not automatically reconnect, you can
manually reconnect in the app.
Find Your Comfort Zone
Find the seat configuration that suits you most. If you feel there is not
enough room between your knees and the desk, push your Cubii JR2+
away from you and lower the chair height.
SECURING YOUR CHAIR
If you're using Cubii JR2+ while sitting in a chair with wheels or casters,
follow the steps below:
1 Find the Wheel Stopper that is included with your JR2+.
.
2 Lift up the back of your Cubii JR2+ and place the interfacing portion
.
of the wheel stopper under the base plate. The nub goes through
the anchor hole.
3 Roll one wheel from your chair onto the circle of the stopper until it is
.
snug in place.
4 If you feel you are too close to your Cubii, the Wheel Stopper can be
.
detached from the base plate and positioned in the location that is
best for your needs.
Wheel Stopper
Anchor Hole
Find detailed product manual, assembly instructions, and
warranty details at cubii.com/manuals
