PRODUCT SPECIFICATIONS
• Power: DC2 x 1.5V Alkaline AA battery
• Operation Current: <6uA (standby), <1200mA (alarm)
• Alarm Volume: >85dB(A) at 3 meters.
• Smoke Sensitivity: 0.108-0.141dB/m
• Heat Sensitivity: 54-70℃
• Local Smoke Alarm Sound Pattern:
BI 0.5s - pause 0.5s – BI 0.5s – pause 0.5s – BI 0.5s – pause 1.5s,
DESCRIPTION
The unit is a photoelectric 3V DC smoke alarm. It is operated by 3v AA Alkaline
battery. With the photoelectric technology, it is more sensitive to detecting slow
smolder fires which general thick, black smoke, little heat and may smolder for
hours before bursting into flames. The smoke alarm do not contain the
radioactive material which is harmless to the environment.
The smoke alarm should be installed in every room (except the bathroom), and
every other area of the home, making sure the people in the home will be able
to hear and respond to the alarm sound. For minimum protection you should fit
an alarm in the hallway between the living areas and sleeping areas. Place the
unit near to the living areas as possible and ensure the alarm is audible when
the bedrooms are occupied.
Typical single storey dwelling with recommended:
Install a smoke alarm on the ceiling inside each bedroom and in the hallway
outside each separate sleeping area. If a bedroom area hallway is more than 30
Model: FJ158D-H04
feet long, install a smoke alarm at each end. If there is a basement: install a
smoke alarm on the basement ceiling at the bottom of the stairwell.
Wireless - Photoelectric
Typical multi-storey dwelling with recommended protection.
Install a smoke alarm on the ceiling inside each bedroom and in the hallway
Smoke Alarm
outside each separate sleeping area. If a bedroom area hallway is more than 30
feet long, install a smoke alarm at each end install a smoke alarm at the top of a
User Manual
first – to- second floor stairwell.
MADE IN CHINA
Advertisement
Table of Contents
Related Manuals for ecoey FJ158D-H04
Summary of Contents for ecoey FJ158D-H04
- Page 1 Install a smoke alarm on the ceiling inside each bedroom and in the hallway outside each separate sleeping area. If a bedroom area hallway is more than 30 Model: FJ158D-H04 feet long, install a smoke alarm at each end. If there is a basement: install a smoke alarm on the basement ceiling at the bottom of the stairwell.
- Page 2 How To Connect With Your Wifi • 1. Search and download “Tuya Smart” in app store; • 2. Register account as requirements by cell phone number or email; • 3. Login Tuya app as follows after registered; There are 2 ways to connect internet, you can choose the one you like. Smart mode internet connection is recommended as it’s easier.
- Page 3 • 8. If the product connection is unsuccessful. Click “I got it” to try again. Repeat step 5 to conduct the smart mode networking and repeat step 6 to conduct the AP mode networking. • 9. Observe alarm information： When an alarm happening, in addition to Tuya platform send alarm message to cell phone APP (Pay attention to the message popping up once a minute, if there are two or more alarm messages within one minute, the message will not be displayed again.);...
- Page 4 • 10. Exit account Click the drop-down arrow beside 123 and choose Home management to enter home settings. Click remove family then choose “Confirm leave” to exit home. Above steps can be ignored to if want exit account directly. Exit methods as follows: Click Profile then choose settings, at last click logout to exit account.
