GRIDFREE LIFESTYLE KIT Installation Manual

Hybrid - lithium
Hide thumbs Also See for LIFESTYLE KIT:

Advertisement

Quick Links

Download this manual
Lifestyle Kit Manual Hybrid 2022.indd 1
Lifestyle Kit Manual Hybrid 2022.indd 1
- L I T H I U M
1
3/08/22 4:52 PM
3/08/22 4:52 PM

Advertisement

loading
Need help?

Need help?

Do you have a question about the LIFESTYLE KIT and is the answer not in the manual?

Questions and answers

Related Manuals for GRIDFREE LIFESTYLE KIT

Summary of Contents for GRIDFREE LIFESTYLE KIT

  • Page 1 - L I T H I U M Lifestyle Kit Manual Hybrid 2022.indd 1 Lifestyle Kit Manual Hybrid 2022.indd 1 3/08/22 4:52 PM 3/08/22 4:52 PM...
  • Page 2 We are always happy to help guide you through the install, troubleshoot, and answer any questions. You can contact us on 09 218 5533, info@gridfree.store. We recommend reading these instructions in full prior to starting your install. Lifestyle Kit Manual Hybrid 2022.indd 2 Lifestyle Kit Manual Hybrid 2022.indd 2 3/08/22 4:52 PM 3/08/22 4:52 PM...
  • Page 3 1x 16mm² Cable (Black) 1m Pre-Crimped (Red + Black) 1x Battery Communications Cable 1x Customized MCB Enclosure 1x 200A MCCB 4x Leader Fuse Holder 4x Leader Fuse Lifestyle Kit Manual Hybrid 2022.indd 3 Lifestyle Kit Manual Hybrid 2022.indd 3 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 4 1x Solar Combiner Terminal Block 2x DC Isolator 1x Growatt 5KW ES Hybrid Inverter 6x Growatt ARK LiFePO4 y 2.56kWh Battery 1x Growatt ARK Battery Base Lifestyle Kit Manual Hybrid 2022.indd 4 Lifestyle Kit Manual Hybrid 2022.indd 4 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 5 12x PERC MONO Solar Panel Lifestyle Kit Manual Hybrid 2022.indd 5 Lifestyle Kit Manual Hybrid 2022.indd 5 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 6 ZTPV-25X ZTPV-25X Generator/ Mains Input Mains Distribution Box 2x DC Isolator Communication Cable 200A Breaker 4x Leader Fuse Solar Combiner Terminal Block Lifestyle Kit Manual Hybrid 2022.indd 6 Lifestyle Kit Manual Hybrid 2022.indd 6 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 7 Start by creating two sets of six panels wired together. Connect the positive terminal of one panel to the negative terminal of the next panel for each string. Lifestyle Kit Manual Hybrid 2022.indd 7 Lifestyle Kit Manual Hybrid 2022.indd 7...
  • Page 8 SISO SWITCH SISO SWITCH ² Run the 6mm solar cables from the solar panels to the DC isolators, and cut it to length. Lifestyle Kit Manual Hybrid 2022.indd 8 Lifestyle Kit Manual Hybrid 2022.indd 8 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 9 The positive wire uses “Metal conductor A” and “Solar connector housing A”, the negative wire uses “Metal conductor B” and “Solar connector housing B”. Lifestyle Kit Manual Hybrid 2022.indd 9 Lifestyle Kit Manual Hybrid 2022.indd 9 3/08/22 4:53 PM...
  • Page 10 Insert the crimped “Metal conductor A” into the “Solar connector housing A” until it clicks, then tighten the gland nut using a spanner. Lifestyle Kit Manual Hybrid 2022.indd 10 Lifestyle Kit Manual Hybrid 2022.indd 10 3/08/22 4:53 PM...
  • Page 11 Insert the crimped “Metal conductor B” into the “Solar connector housing B” until it clicks, then tighten the gland nut using a spanner. Lifestyle Kit Manual Hybrid 2022.indd 11 Lifestyle Kit Manual Hybrid 2022.indd 11 3/08/22 4:53 PM...
  • Page 12 Repeat the process of crimping MC4 connectors onto a new set of cables (refer to page 9-11), which will connect the PV Array DC isolators to the PV Array fuses. Lifestyle Kit Manual Hybrid 2022.indd 12 Lifestyle Kit Manual Hybrid 2022.indd 12...
  • Page 13 Make sure the clamp inside the fuse holders are contacting the metal conductor, and NOT the insulation of the wire. Lifestyle Kit Manual Hybrid 2022.indd 13 Lifestyle Kit Manual Hybrid 2022.indd 13 3/08/22 4:53 PM...
  • Page 14 SISO SWITCH SISO SWITCH The PV Array DC isolators are now wired into the PV Array fuses. Lifestyle Kit Manual Hybrid 2022.indd 14 Lifestyle Kit Manual Hybrid 2022.indd 14 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 15 ² cable from the M8 and both positives together in the other side. Then run the section of 16mm bolt terminals to the hybrid inverter. Lifestyle Kit Manual Hybrid 2022.indd 15 Lifestyle Kit Manual Hybrid 2022.indd 15 3/08/22 4:53 PM...
  • Page 16 For your safety, do not connect or disconnect any solar cables when there is current running through them. Lifestyle Kit Manual Hybrid 2022.indd 16 Lifestyle Kit Manual Hybrid 2022.indd 16 3/08/22 4:53 PM...
  • Page 17 Keep the fuses disconnected by ensuring the fuse holders are open with the fuses left out and the PV Array DC isolator is switched to the “OFF” position, before wiring. Lifestyle Kit Manual Hybrid 2022.indd 17 Lifestyle Kit Manual Hybrid 2022.indd 17...
  • Page 18 1m cables between the components to ensure that the M6 ends (smaller holes) are inserted into the hyrbid inverter and the M8 ends (larger holes) are inserted into the circuit breaker. Lifestyle Kit Manual Hybrid 2022.indd 18 Lifestyle Kit Manual Hybrid 2022.indd 18...
  • Page 19 0000 000 000 ² Wire the negative (-) 35mm x 1m cable from the hybrid inverter to the 200A MCCB circuit breaker. Lifestyle Kit Manual Hybrid 2022.indd 19 Lifestyle Kit Manual Hybrid 2022.indd 19 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 20 Please refer to the Battery Mount and Installation Guide for detailed installation instructions. This manual is included in the ARK lithium battery box. Lifestyle Kit Manual Hybrid 2022.indd 20 Lifestyle Kit Manual Hybrid 2022.indd 20 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 21 Connect the power connections, following the instructions detailed in the battery installation manual. Lifestyle Kit Manual Hybrid 2022.indd 21 Lifestyle Kit Manual Hybrid 2022.indd 21 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 22 000 000 000 0000 000 000 Connect the CAN communication cables as described in the battery installation manual. Lifestyle Kit Manual Hybrid 2022.indd 22 Lifestyle Kit Manual Hybrid 2022.indd 22 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 23 (excluding the panels). Double check everything is wired correctly and tightened before proceeding, to prevent damage to your system. For this manual, all steps should be done by an electrician. Lifestyle Kit Manual Hybrid 2022.indd 23 Lifestyle Kit Manual Hybrid 2022.indd 23 3/08/22 4:53 PM...
  • Page 24 The hybrid inverter does not have an earth to neutral connection. This connection can be made at the main distribution board, unless the system is being used with a generator that also has an earth neutral connection. Lifestyle Kit Manual Hybrid 2022.indd 24 Lifestyle Kit Manual Hybrid 2022.indd 24 3/08/22 4:53 PM...
  • Page 25 ZTPV-25X Switch on the circuit breaker and fuses in the following order. First, switch on the battery to hybrid inverter 200A MCCB circuit breaker. Lifestyle Kit Manual Hybrid 2022.indd 25 Lifestyle Kit Manual Hybrid 2022.indd 25 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 26 Set Program 36 to L51 and press “ESC”. If there are any issues, please check all cables and connections. Then, double check Program 5 is LI and program 36 is L51. Lifestyle Kit Manual Hybrid 2022.indd 26 Lifestyle Kit Manual Hybrid 2022.indd 26 3/08/22 4:53 PM...
  • Page 27 IP66 PV ARRAY DC ISOLATOR ON I SISO SWITCH Lastly, switch the PV Array DC isolators to the “ON” position. Lifestyle Kit Manual Hybrid 2022.indd 27 Lifestyle Kit Manual Hybrid 2022.indd 27 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 28 0000 000 000 The Green LED on the PV Charge should flash, and the panel voltage should be around 200V-300V in full sunlight. Lifestyle Kit Manual Hybrid 2022.indd 28 Lifestyle Kit Manual Hybrid 2022.indd 28 3/08/22 4:53 PM 3/08/22 4:53 PM...
  • Page 29 If you dont believe you have knowingly used enough power to drain the batteries, check all your appliances to see if something is using more power than it should. Lifestyle Kit Manual Hybrid 2022.indd 29 Lifestyle Kit Manual Hybrid 2022.indd 29...
