  • Page 1 Human Machine Interface XGT PANEL LXP Series...
  • Page 2 Safety Precautions Before using the product… T o use the product safety and effectively , please read this instruction manual thoroughly before use. ► Please keep to the safety precaution, for it to prevent accidents and potential danger from occurring. Safety precaution is classified into ‘...
  • Page 3 Safety Precautions Design Precautions Warning ► Install a safety circuit external to the HMI to protect the whole control system in case of external power supply trouble. Serious trouble may occur to the entire system due to erroneous output/operation of the HMI. Design Precautions Caution In/output signal or communication cable should be at least 100mm apart from High-...
  • Page 4 Safety Precautions Wiring Precautions Warning ► Be sure to turn off the HMI and external power before wiring. Otherwise, it may result in an electric shock or damage to the product. Caution ► Wire correctly by checking each of the product’s rated voltage and terminal layout. Otherwise, it may result in fire, electric shock or erroneous operation.
  • Page 5 Safety Precautions Startup and Maintenance Precautions Warning ► Do not touch the terminals while power is on. Otherwise, it may cause electric shock or erroneous operation ► Turn off the HMI and external power when cleaning or tightening the terminal. Otherwise, it may cause electric shock or erroneous operation.
  • Page 6 Date Contents Revised Location ‘22.06 V1.0 First Edition ’22.06 V1.1 Change the general type Main Unit ※ The number of User’s manual is indicated the right side of the back cover. ⓒ LS ELECTRIC Co., Ltd 2022 All Rights Reserved.

  • Page 7: Table Of Contents

    Chapter 1 Overview Chapter 1 Overview ................................1-1 1.1 How to use the Instruction Manual ............................ 1-1 1.2 Feature ....................................1-2 1.3 Terminology ..................................1-7 1.4 Specification of product name ............................1-8 Chapter 2 Standard Specification ........................... 2-1 2.1 General Standards ................................2-1 2.2 Function Standards ................................
  • Page 8 Chapter 1 Overview Chapter 5 XGT Panel Menu Explanation ........................ 5-1. 5.1 Project ....................................5-3 5.1.1 Start ................................... 5-3 5.1.2 Screen ..................................5-4 5.1.3 Maintenance ................................5-7 5.2 Controller Settings ................................5-8 5.2.1 List of Connected Devices ............................5-8 5.2.2 Detailed Controller Settings ............................. 5-9 5.3 Control Panel..................................
  • Page 9 Chapter 1 Overview 1. Type of Problem ................................App 1-1 2. Problems when Starting .............................. App 1-2 3. Problems after the monitor on ............................ App 1-3 4. Problems with figure and object display ........................App 1-5 5. Communication problems ............................App 1-8 6.
  • Page 10 Chapter 1 Overview Chapter 1 Overview 1.1 How to use the Instruction Manual Sequence Item Contents Chapter 1 Overview It describes and provides information about this manual. Chapter 2 Standard Specification It describes features for each XGT Panel Chapter 3 System Configuration It describes XGT Panel and system configuration for each XGT Pane It describes the installation, wiring and precautions for reliability of the PLC...
  • Page 11 Chapter 1 Overview 1.2 Features The XGT Panel has the following features. (1) Various types of external interfaces (a) Supports various USB devices, Ethernet, and maximizes the customer’s usability. (b) Connect devices such as PLC · Inverter communication in a variety of ways. ...
  • Page 12 HIKVISION DS-2CV2Q DAHUA DH-SF125 1) For IP cameras that are guaranteed to operate, this means a product validated by LS Electric. (7) Supports LXP dedicated extended memory (a) Data protection is possible by applying dedicated I/F. (8) Supports XP-VLink function (a) By supporting XP-VLink function, it is possible to combine/separate the product, so various installation configurations are possible.
  • Page 13 (9) Supports Ethernet bridge function (a) Ethernet bridge means a function that connects network segments in the data link layer of the OSI model, LXP series supports Ethernet bridge function to connect data between LAN0 and LAN1, enabling system configuration without a network switch.
  • Page 14 Chapter 1 Overview (12) Providing various convenience functions (a) Various alarm functions are provided.  The history alarm can be divided into several alarm groups and alarm lists. The desired alarm can be displayed on the screen with the alarm explorer. ...
  • Page 15 Chapter 1 Overview (14) Compliance with protection standards (EHSR standards) (a) Ensure that there is no explosive reaction between the materials used and potentially explosive components  Compliance with specifications (b) Protects against other explosion hazards  Compliance with specifications...

  • Page 16: Terminology

    Chapter 1 Overview 1.3 Terminology It describes terms used in this manual. Term Definition Note A standard element that has a specified function which configures the system. Ex) CPU module Module Devices such as I/O board, which are inserted onto the mother board or base Power Module I/O unit.
  • Page 17 Chapter 1 Overview 1.4 Product Name Rule It describes terms used in this product’s names. (1) Display unit Menu Sign Contents Note (A) Type Display unit (B) LCD size 12.1” LCD Support (C) Camera option Not supported Support (D) XP-VLink support Not supported Blank...
  • Page 18 Chapter 1 Overview (2) Main unit Menu Sign Contents Note (A) Type Main unit Runtime installed (B) Runtime option Runtime not installed Support (C) XP-Vlink Not supported (D) Power DC 24V Blank Export product (E) Reserved ship certification Explosion proof product Coated product...
  • Page 19 Chapter 1 Overview (3) Extended memory option Menu Sign Contents Note (A) Type Option unit (B) Option type Extended memory (C) Memory capacity 64GB Blank (D) Reserved Coated product (4) XP-VLink Cable option Menu Sign Contents Note (A) Type Option unit (B) Option type detachable cable Small to medium size...

  • Page 20: Chapter 2 Standard Specification

    * Duration time: 11ms IEC 61131-2 endurance * Pulse wave: half sine pulse (3 times each in X, Y and Z directions) Square wave DC: ±1,000V LS ELECTRIC Impulse noise Electrostatic IEC 61131-2 Discharge ±4 kV(contact discharge), ±8 kV(air discharge)
  • Page 21 hapter 2 Standard Specification Note (1) IEC(International Electro technical Commission) - International private group facilitating international cooperation of electric/electronic standardization, issuing international standards and operating the compliance evaluation systems. (2) Pollution degree - As an index representing the pollution degree of an environment to determine the insulation of a device, pollution degree 2 generally means the status generating non-conductive contamination.

  • Page 22: Function Standards

    Note (1) Built-in Camera A built-in camera of the LXP series is supported max.720p. For stable using, we suggest 640p. (2) XP-VLink(XGT-View Link) XP-VLink means the ability to combine LXP Display Unit and Main Unit using XP-VLink I/F cable. In the case of models supporting XP-VLink, display unit and Main unit are combined according to the installation environment Or you can install it separately.
  • Page 23 hapter 2 Standard Specification 2) Main unit Item LXP-M00D LXP-M01D LXP-M10D LXP-M11D Processor 1.6GHz, Quad core Drawing Memory 128Mbyte Memory Operation RAM 4GByte Backup RAM 1Mbyte ○ ○ XP-VLink Support, Battery CR2032(about 3years/25℃) HDMI V2.0, 1 channel Interface Audio Out 3.5Ф, 40mW, 1 channel Extended Interface Support, 64GB extended memory...
  • Page 24 Chapter 2 Standard Specification (2) Special Type(Explosion-proof product) 1) Display Unit Item LXP-D1200 LXP-D1201 LXP-D1210 LXP-D1211 Display type TFT color LCD Color indication 32bit color(16.7M) Screen size 12.1” Display Display resolution 1024x 768 Backlight LED method, automatic On/Off support Backlight lifetime 50,000 hour Touch panel Capacitive touch...
  • Page 25 Note (1) Built-in Camera A built-in camera of the LXP series is supported max.720p. For stable using, we suggest 640p. (2) XP-VLink(XGT-View Link) XP-VLink means the ability to combine LXP Display Unit and Main Unit using XP-VLink I/F cable. In the case of models supporting XP-VLink, display unit and Main unit are combined according to the installation environment Or you can install it separately.
  • Page 26 Chapter 2 Standard Specification 2) Main unit Item LXP-M00D LXP-M01D LXP-M10D LXP-M11D Processor 1.6GHz, Quad core Drawing memory 128Mbyte Memory Operation RAM 4GByte Backup RAM 1Mbyte ○ ○ XP-VLink Support, Battery CR2032(about 3years/25℃) HDMI V2.0, 1 channel Interface Audio Out 3.5Ф, 40mW, 1 channel Extended interface Support, 64GB extended memory...
  • Page 27 (7) USB Maximum Allowable Current The maximum allowable current for each channel of USB Host of LXP series is 500mA. When connecting a device that requires a current consumption of 500mA or more, a USB device capable of supplying external power must be used for normal operation.

  • Page 28: Cable Standards

    Chapter 2 Standard Specification 2.3 Cable Standards 2.3.1 UTP Cable ① Shield type: Three types (UTP, FTP, STP) ② Seven types of frequency bands used 7 types (Cat.1-7) UTP cables are categorized into two types with the following standards. (1) Cable types (shields) Type Details Purpose...
  • Page 29 hapter 2 Standard Specification (2) Type per used frequency Transmission Type Used frequency (MHz) Purpose speed (Mbps) Category 1 Audio frequency Telephone network (2Pair) Category 2 Multi pair communications cable Category 3 Telephone network + Computer network 1)Speed up the computer network Category 4 2) Low-loss communications cable Category 5 and...

  • Page 30: Chapter 3 System Configuration

    Chapter 3 System Configuration XGT Describes the characteristics of XGT Panel and system configuration 3.1 Part Names 3.1.1 Display unit 1. Built-in Camera 1. 내장 카메라 2. Power LED 2. 전원 LED 5. Panel fixing 5.고정 브라킷 홀 portion 3. Front USB(Device) 3.
  • Page 31 7. Built-in Camera 8. XP-VLink( Power) 7. 내장 카메라 조정 레버 adjustment lever 6. Anti-Drop Lock 8. XP-Vlink(I/F) 9. Main Unit 커넥터 9. Main Unit connector 10. VESA Hole 11. PE connector 11. PE단자 12. 케이블 고정홀 12. Cable fixing hole 13.

  • Page 32: Main Unit

    3.1.2 Main unit 11. Din-rain brakect 10. Extended memory 12. VEAS hole 9. XP-VLink I/F 1. XP-VLink Power 8. Multimedia - SD-Card - Audit Out - HDMI 2. Battery Cover - USB Host × 2 3. Termination Resister SW 4. Power In 6.
  • Page 33 Name Function Termination COM1, COM2, COM3 Termination Resistance ON/OFF Switch Resistance S/W Power Input Main Unit 24Vdc Power input terminal PE Connector PE Connection 1. COM1: RS-232C x 1, RS422/485 x 1 Serial 2. COM2: RS-232C x 1, RS422/485 x 1 3.

  • Page 34: System Configuration

    3.2 System Configuration 3.2.1 Project Transfer To use XGT Panel, you must create project data in LXP-Designer and transfer it to XGT Panel. With Ethernet, project data can be transferred quickly. If the LAN environment is established as shown below, you can use it more easily and effectively.

  • Page 35: Combined Configuration

    If project data can not be transferred using communication, you can transfer data using USB storage device or SD card. Please refer to Chapter 5 and LXP-Designer User's Guide for more information. SD Card, USB Notes (1) Refer to the communication manual for how to make the Ethernet cable (2) Refer to LXP-Designer manual for project transfer method 3.2.2 Combined Configuration The main unit can be combined with the display unit for installation on panels and VESA mounts...

  • Page 36: Xp-Vlink Service

    3.2.3 XP-VLink Service The display unit and the main unit can be connected by XP-VLink and installed separately. XP-VLink requires a cable for XP-VLink I/F and supports up to 3m and 5m. You can use the same functionality as the combined when configuring a detachable configuration Display unit LXP Main unit...

  • Page 37: Chapter 4 Installation And Wiring

    Chapter 4 Installation and Wiring Chapter 4 Installation and Wiring 4.1 Installation 4.1.1 Installation Environment This machine has high reliability regardless environment. But for reliability and stability, be careful the followings (1) Environment condition (a) Install at the panel which can protect this machine from water and dust. XGT Panel is designed by IP66 Standard in front parts and IP20 Standard in rear parts.
  • Page 38 Chapter 4 Installation and Wiring Notes (1) Waterproof and dustproof standard (a) IP66 Standards 1) The protection standards of XGT Panel have been designed to meet the IP66 test conditions, in accordance with the degrees of protection provided by enclosures of IEC60529. As this machine installed at the panel, it is not guaranteed with all installation environment even though its protection standards for the front parts are satisfied.

  • Page 39: Precautions Before Handling

    Chapter 4 Installation and Wiring 4.1.2 Precautions before handling This section describes the precautions for handling the XGT Panel from opening to installation.  Do not drop or subject it to strong impacts.  Do not open the product case or take any action. In such cases, we are not responsible for the product. ...
  • Page 40 Chapter 4 Installation and Wiring 4.1.3.1 Panel installation Describes how to install the XGT Panel on the panel and notes. (1) Panel cut  Before installing the XGT Panel on the panel, it must be manufactured on the panel as shown in the table below. Unit : [mm] Type LXP-D12xx...
  • Page 41 Chapter 4 Installation and Wiring (2) Panel installation  When mounting the XGT Panel on the panel, please install 100mm or more in each direction. Unit: [mm] Notes (1) In order to be less affected by electromagnetic waves (radiation noise) or heat generated by other control devices, Required.
  • Page 42 Chapter 4 Installation and Wiring (3) Fixing  For the XGT Panel using the brackets on the panels as shown below. (The bracket is included in the product.) Fixed Bracket Panel Notes (1) During installation, XGT Panel should be closely contacted to the panel not to have any gap. In the environment requiring water-proof/dust-proof effect, install and fix a bracket on a slope.
  • Page 43 Chapter 4 Installation and Wiring (4) Product Separation  Loosen the fixing bracket screw and remove the bracket from the XGT Panel.  Press the Anti-drop lock as shown below and then slowly push it forward to remove it from the panel. Panel Back of product Notes...
  • Page 44 Chapter 4 Installation and Wiring 4.1.3.2 Panel installation on VESA mount XGT Describes how to install XGT Panel on VESA mount and precautions. (1) VESA mount specifications  Refer to the table below for VESA mount screw hole sizes. unit: [mm] Type note LXP-D12xx...
  • Page 45 Chapter 4 Installation and Wiring 4.1.4 Precautions for the main unit  For products that can be installed separately. ( LXP-Mx0D, for detailed product model names, refer to 1.4 Model Name Assignment Criteria) 4.1.4.1 Installation on the display unit (1) Fixing ...
  • Page 46 Chapter 4 Installation and Wiring  DIN rail, lift the product slightly upwards and remove from the bottom. < How to remove DIN rail>  Mounting on a DIN rail, the DIN rail may be deformed, so tighten the DIN rail fixing bolt at the product installation location ...

  • Page 47: Wiring

    Chapter 4 Installation and Wiring 4.2 Wiring Describes the wiring matters when installing the XGT Panel. 4.2.1 Power Wiring XGT Panel is divided into DC (DC) product. Power Product Name DC 24V LXP-MxxD Caution ► Connecting AC power to a device that uses DC power may cause product damage or fire. Be careful of connection.
  • Page 48 Chapter 4 Installation and Wiring Use the following specifications for the power cable. Cable specification (Unit: ㎟) Type Wire Type Thermal Resistance Screw Torque Power and protection 0.51N•m 1.5(AWG16) ~ 2.5(AWG12) Copper 60℃ ground Notes (1) For installations where there is voltage drop, it is recommended to use stranded wire with a cross sectional area greater than 2 ㎟.
  • Page 49 Chapter 4 Installation and Wiring For XGT Panel power supply, I / O devices and power devices, separate the power supply system as shown below. Use the surge absorber as shown in the figure below to prevent surge such as lightning. Main Power XGT Panel Others...

  • Page 50: Ground Wiring

    Chapter 4 Installation and Wiring When there is concern about noise penetration, use an insulation shield transformer or a noise filter. Be sure to twist the wiring of the input power supply as short as possible and do not let the wiring of the shielding transformer or noise filter pass through the duct.
  • Page 51 Chapter 4 Installation and Wiring 4.2.3 XP-VLink connection wiring The display and main unit wiring methods and precautions when installing XP-VLink . (1) Connect LXP-OCxx to DISP0 of Main Unit. (2) DISP of Main Unit Connect the power line to be supplied to the Display Unit with the connector provided on the PWR (+/-). * Main Unit DISP PWR output 15.5 V DISP PWR 4-15...
  • Page 52 Chapter 4 Installation and Wiring (3) Connect XP-VLink I/F, Power cable to Display Unit. DISP PWR DISP 0 Notes (1) DISP PWR input power is 15.5 V, please use the power supplied from the main unit. * Power supply other than the power supplied from the main unit may cause equipment failure. 4-16...
  • Page 53 Chapter 4 Installation and Wiring 4.2.4 Secure the external interface cable (1) Connect the cable tie to the external interface cable fixing hole on the back of the unit. (2) Fix the cable tie firmly so that the external interface cable does not fall off by external force. Caution ►...

  • Page 54: Chapter 5 Xgt Panel Menu Explanation

    : The name of a LXP-Series product in use is displayed. : The physical addresses of LAN0 and LAN1 are displayed. ○ c ○ d : An address with which you can contact is displayed. : It is connected to the LS ELECTRIC product information page.
  • Page 55 Chapter 5 Description of XGT Panel menu (2) Connection status ○ The connection status item displays the status of the storage device and Ethernet currently connected to the product. When a storage device and Ethernet are connected to the product, the corresponding item changes to a dark color icon. When installing storage SD Ethernet device and Ethernet...

  • Page 56: Project

    Chapter 5 XGT Panel Menu Explanation 5.1 Project It is the menu for operation and management of projects saved in XGT Panel. 5.1.1 Start It is the menu related to the start method and screen settings of the projects saved in HMI. If you select the [START] tab in the [Project] screen as shown below, the screen moves to the setting items.

  • Page 57: Screen

    Chapter 5 Description of XGT Panel menu 5.1.2 Screen This is a menu for setting how to display objects and characters within the screen after the HMI project starts. If you select the [Screen] tab in the [Project] screen as shown below, the screen moves to the setting items. Menu Description The Title Bar is always shown on the pop-up window screen.
  • Page 58 Chapter 5 XGT Panel Menu Explanation Menu Description You can drag so that the pop-up window screen moves out of the edge of the screen. Drag to move to the edge When Window move out of screen is not set, even if you drag the window screen as Window move out of screen shown above, it does not move out of the edge of the screen.
  • Page 59 Chapter 5 Description of XGT Panel menu Menu Description When the project is executed, the progress status of the project is displayed. Show progress bar <Example for project start when Show progress bar is not set> <Example for project start when Show progress bar is set>...

  • Page 60: Maintenance

    Chapter 5 XGT Panel Menu Explanation 5.1.3 Maintenance This is a menu to import or copy a project from the storage device for product maintenance. If you select the [Maintenance] tab in the [Project] screen as shown below, the screen moves to the setting items. [Touch setting screen] Menu Description...

  • Page 61: Controller Settings

    Chapter 5 Description of XGT Panel menu 5.2 Controller Settings In Controller Setting, you can check and change the communication settings of the controllers connected to the XGT Panel. 5.2.1 List of Connected Devices If you click [Controller Setting], you can see the list of set controllers as shown below. If you select a controller, you can check and set the settings for the corresponding controller and register up to 16 controllers.

  • Page 62: Detailed Controller Settings

    Chapter 5 XGT Panel Menu Explanation 5.2.2 Detailed Controller Settings (1) Common Setting You can set details for common setting items by communication drive of the controller. The below figure is an example where XGK Ethernet communication drive of the company is set, and you can change the setting value of the controller set in LXP-Designer.
  • Page 63 Chapter 5 Description of XGT Panel menu Notes 1) Timeout: For effective data communication, if there is no response within the timeout set when communicating with the controller, it is considered that data communication is not possible, and the next data request is made. At this time, retry communication as much as Timeout retry count since the timeout setting time.
  • Page 64 Chapter 5 XGT Panel Menu Explanation (2) Communication Setting As the basic setting item for communication by communication drive of the controller, the figure below is an example where dedicated XGT Cnet communication and Ethernet communication drive of the company are selected. You can change the set value of the controller set in LXP-Designer in Communication Setting.
  • Page 65 Chapter 5 Description of XGT Panel menu * PLC Communication Setting for Ethernet Communication Item Descriptions The IP of the controller connected by an Ethernet cable is displayed. Target Port The port to which the controller is to be connected is displayed. Local Port The local port of the controller is displayed.
  • Page 66 Chapter 5 XGT Panel Menu Explanation (3) Extended Setting Depending on the type of controller selected in LXP-Designer, the items, which can be set additionally, are displayed differently. Item Descriptions Use extended protocol Extended protocols can be used. ※ After all settings are completed, click the Apply button to apply the settings. Notes For the Extended Setting menu, it is displayed only when support is available depending on the type of communication driver.

  • Page 67: Control Panel

    Chapter 5 Description of XGT Panel menu 5.3 Control Panel Through the Control Panel menu, you can set the overall operation of the device, such as the screen brightness, touch sensitivity, and update of the XGT Panel. [XGT Panel Default Screen] When you click [Control Panel], a list of settable menus is created on the left side as shown below, and detailed setting items for the corresponding menu are created on the right side.

  • Page 68: Display

    Chapter 5 XGT Panel Menu Explanation 5.3.1 Display This is a setting menu related to LCD operation of XGT Panel. Item Descriptions Brightness The LCD screen brightness can be set in the range between 1 and 100%. The LCD backlight operation can be set. - When Automatically turn off backlight is set to Off, the screen is always turned on.

  • Page 69: Touch

    Chapter 5 Description of XGT Panel menu 5.3.2 Touch Detailed setting of XGT Panel Touch is available. The touch suitable for the installed environment can be set through setting the mode and sensitivity of touch. Name Description Bare Hands: Mode used when using a device by hands. Gloves: Mode used when using a device while wearing gloves.

  • Page 70: Date/Time

    Chapter 5 XGT Panel Menu Explanation 5.3.3 Date/Time It sets the date and time displayed on the XGT Panel. Name Description Sets the date of the device. If you touch the number part in which the date was entered as shown below, the number pad pops up.

  • Page 71: Ethernet

    Chapter 5 Description of XGT Panel menu 5.3.4 Ethernet It is the menu for setting Ethernet of XGT Panel. This menu sets the parameters for LAN0 and LAN1. (1) General < LAN 0 (eth 0) > < LAN 1 (eth 1) > * If you scroll down the screen, you can find LAN1.
  • Page 72 Chapter 5 XGT Panel Menu Explanation Default setting LAN0 Default setting LAN1 If the default setting If the default setting is LAN0, data is LAN1, data communication with communication with other networks other networks through LAN0 through LAN1 Other band networks Other band networks <Example of setting Default to LAN1 or LAN2>...
  • Page 73 Chapter 5 Description of XGT Panel menu Notes 1) Using DHCP: This is a function to automatically receive an IP address from the connected router. When using the function, the directly set IP address is updated with the assigned IP. 2) IP address: IP address to set for each LAN0, LAN1 Ethernet interface.
  • Page 74 Chapter 5 XGT Panel Menu Explanation (2) Advanced Name Description LAN0 and LAN1 data can be connected to configure the system without a network switch. (For detailed description, please refer to Feature 1.2 ‘Supporting Ethernet Bridge function’.) Ethernet Bridge When the ON button is checked, IP for Bridge Mode is activated. In IP for Bridge Mode, you can select a LAN IP to be used as Ethernet Bridge.

  • Page 75: Sound

    Chapter 5 Description of XGT Panel menu 5.3.6 Sound You can set the sound and buzzer functions of XGT Panel. Name Description Sets the volume of the sound output using the speaker connected to the device. Audio You can drag while touching the Audio Volume bar to adjust the volume, or you can touch + and - on both sides of the Audio Volume bar to adjust the volume.

  • Page 76: Menu Bar

    Chapter 5 XGT Panel Menu Explanation 5.3.7 Menu Bar This is a function provided so that a user can use the device status and convenience functions more conveniently after a project starts. The initial setting is to be displayed at the top, and the menu bar is displayed upon operation as follows. <Start project>...
  • Page 77 Chapter 5 Description of XGT Panel menu When set to ON, the controller setting menu appears on the menu bar within a project. Settings When touching it, the screen is switched to the controller setting screen, and when you touch x on the top right, the screen returns to the monitoring screen.
  • Page 78 Chapter 5 XGT Panel Menu Explanation When set to ON, the device monitor menu appears on the menu bar within a project. Device Monitor ○ Common: Displays a list of all devices set in logging, recipe, alarm, etc. ○ Screen: Displays a list of all devices connected to objects placed on the screen. ○...
  • Page 79 Chapter 5 Description of XGT Panel menu When set to ON, the resource monitor menu appears on the menu bar within a project. When you touch this, the resource monitor pop-up window appears. CPU Usage by core: CPU usage of quad-core by core ①...
  • Page 80 Chapter 5 XGT Panel Menu Explanation When set to ON, the USB Change menu appears on the menu bar within a project. When touching it, a pop-up window for selecting a USB is created, and the USB with a check mark is an USB in use among the USBs currently installed. Change Function List...

  • Page 81: System Os

    Chapter 5 Description of XGT Panel menu 5.3.8 System OS (1) Select Language This allows you to set the language. (Setting English, Korean, Chinese and Japanese possible) * When selecting the checkbox of the language you want to change, The runtime restarts and you go to the initial screen where the language changed. 5-28...
  • Page 82 Chapter 5 XGT Panel Menu Explanation (2) HDMI If you connect the monitor and the XGT Panel with an HDMI cable, you can see the screen of the XGT Panel on the monitor as well. <Basic settings before HDMI cable connection> <HDMI settings activate after HDMI cable connection>...
  • Page 83 Chapter 5 Description of XGT Panel menu (3) Bootimage You can set the system boot image. Name Description When touching the Load image button, the file explorer appears and you can find and select the path where the boot image exists. When selected, the selected image is created in the Boot image box.
  • Page 84 Chapter 5 XGT Panel Menu Explanation (4) Update It updates Runtime or OS using the storage device. Name Description You can check Runtime version and OS version. Version Information You can select and update Runtime or OS. Insert the USB storage device or SD card in which the update file is included, and then carry out the update as follows.
  • Page 85 Chapter 5 Description of XGT Panel menu (5) BackUp You can select a storage device to be backed up. 5-32...
  • Page 86 Chapter 5 XGT Panel Menu Explanation (6) Initialize You can execute NVRAM memory, project initialization, and factory reset. Name Description NVRAM When touching the YES button on the pop-up window created when NVRAM is touched, NVRAM memory is reset. Project When touching the YES button on the pop-up window created when you touch the Project button, the project file downloaded from LXP-Designer is reset.
  • Page 87 Chapter 5 Description of XGT Panel menu (7) ETC You can output 5V voltage from the COM2 port. * If you check the checkbox, it is applied automatically. 5-34...

  • Page 88: Diagnosis

    Chapter 5 XGT Panel Menu Explanation 5.4 Diagnosis You can diagnose various memory, network, camera, and touch functions. [XGT Panel Default Screen] If you touch [Diagnosis], a menu list for various diagnoses shows up on the left. If you touch the menu on the left, the detailed diagnosis screen of the corresponding menu is created on the screen on the right.

  • Page 89: Memory

    Chapter 5 Description of XGT Panel menu 5.4.1 Memory You can diagnose the memory usage status of various storage devices. * Check the memory device you want to diagnose, and then click Start to start the diagnosis. * If the storage device is recognized, a success message is created. If it cannot be recognized, a fail message is created. Name Description Internal Storage...

  • Page 90: Network

    Chapter 5 XGT Panel Menu Explanation 5.4.2 Network Ethernet ping test and serial communication by COM port can be diagnosed. Name Description When touching LAN0 or LAN1 to be diagnosed, the IP input pop-up window is displayed Ethernet When entering the Ethernet communication destination IP and touching the Done button, communication diagnosis can be performed.
  • Page 91 Chapter 5 Description of XGT Panel menu The RS-232 serial test can be performed by connecting COM1 port and COM2 port. Communication Speed Select TX, RX Carry Out Test RS-232 <How to connect> COM1 ↔ COM2 Pin 2 ↔ Pin 3 Pin 3 ↔...

  • Page 92: Camera

    Chapter 5 XGT Panel Menu Explanation 5.4.3 Camera You can test the built-in camera, USB, and IP camera. Notes The Camera Diagnosis function is not currently supported. Support will be provided later 5-39...

  • Page 93: Touch

    Chapter 5 Description of XGT Panel menu 5.4.4 Touch You can diagnose whether or not the recognition of the screen touch is bad. Name Description When touching the Test button, a number of check arrangement buttons appear. Touch Test Touch the button and perform the touch test. If the test is completed, you can touch the Confirm button to return to the previous screen.

  • Page 94: Others

    Chapter 5 XGT Panel Menu Explanation 5.4.5 Others You can diagnose whether or not the battery or LCD is abnormal. Name Description When touching the Test button, The result message is appeared at the bottom output window. Battery Test When touching the Test button, The display device test will be started. LCD Test 5-41...
  • Page 95 Chapter 5 Description of XGT Panel menu The screen changes in the order of Red → Green → Blue → Black → White. When changing, you can touch the screen to move to the next color. If the screen color change is completed, a screen asking if there is an abnormality appears. Depending on whether or not an abnormality exists, when you touch the button, it returns to the Others screen of Diagnosis, and the result message is displayed in the output window.

  • Page 96: Utility

    Chapter 5 XGT Panel Menu Explanation 5.5 Utility You can use additional functions (file explorer, multimedia viewer, CDV editor). [XGT Panel Default Screen] When you touch Utility, the screen is switched to the menu screen where you can run File Explorer, Multimedia Viewer, and CSV Editor.

  • Page 97: File Send

    Chapter 5 Description of XGT Panel menu 5.5.1 File Send You can copy, move, delete, and execute files. * The local directory is displayed on the left side of the file explorer screen, and you can select local and remote directories on the right side.

  • Page 98: Multimedia Viewer

    Chapter 5 XGT Panel Menu Explanation 5.5.2 Multimedia Viewer Notes The Multimedia Viewer function is not currently supported. The function is expected to be supported within the year. 5.5.3 CSV Editor Notes The CSV Editor function is not currently supported. The function is expected to be supported within the year. 5-45...

  • Page 99: Chapter 6 Maintenance

    Chapter 6 Maintenance Chapter 6 Maintenance To keep the XGT Panel in the best condition, perform regular inspections. 6.1 maintenance and inspection Periodic inspection is necessary as the device may be affected by the surrounding environment. 1-2 times every 6 months. Please refer to the items below for the items to be checked.

  • Page 100: Periodic Maintenance

    Chapter 6 Maintenance 6.3 Periodic Maintenance Inspect the following items once or twice every 6 months and take necessary measures. check list How to check Criteria action Measured by Surrounding -10 to 50 C temperature/hygrometer temperature Corrosive gas measurement Surrounding Surrounding 10 to 85%RH 10 to 85%RH...
  • Page 101 Chapter 6 Maintenance Notes (1) Battery replacement time is indicated by a system alarm. system alarm is displayed only when an alarm item in LXP - Designer is set. (2) Replace the battery only with Hitachi Maxel (part number CR2032). There is a risk of fire or explosion if other batteries are used.

  • Page 103: Chapter 7 Emc Standard Certification

    Chapter 7 Compliance with EMC Standards Chapter 7 EMC Standard Certification 7.1 Requirement for EMC Standard Certification EMC command is regulated on “It doesn’t produce the Strong electromagnetic waves: Emission” and “It is not affected by electromagnetic wave from external: Immunity”. The following is describing the contents to meet the EMC command when configuring the system by using the XGT Panel.

  • Page 104: Kc Standard Certification

    Chapter 7 Compliance with EMC standards standard Certification 7.1.2 KC The XGT Panel acquire the electromagnetic fitness registration (KC specification) certified by wave laboratory under information- communication part Class A device This device is a device registered for electromagnetic compatibility for business use, so the seller or user Please be aware of this and if it is sold or purchased by mistake , Please exchange.

  • Page 105: Appendix 1 Troubleshooting

    Appendix 1 Troubleshooting Appendix 1 Troubleshooting 1. Type of Problem During XGT Panel operation, display of displayed figures and objects, and downloading from L XP- Designer , etc. occur in XGT Panel. We have categorized the types of problems. Please refer to the relevant problem section below. Description Classification of problem Malfunction when starting.
  • Page 106 Appendix 1 Troubleshooting 2. Problems when Starting Questions Why does black screen show up when turning on the device? When turning on the device, black screen shows up and the booting is impossible. phenomenon <Cause> (1) Because the device is not set as a booting mode. (2) Black screen may appear because of malfunction of backlight.

  • Page 107: Problems After The Monitor On

    Appendix 1 Troubleshooting initialization of the storage device with slow recognition speed or low recognition ratio. Depending on the characteristics of the storage device, however, the power initialization can be an obstacle to the initialization work. Thus, depending on Phenomenon, select what has higher recognition ratio by properly using the power initialization option.
  • Page 108 Appendix 1 Troubleshooting during monitoring. In case when the number of image used for project is a lot, the memory usage can more easily reach the limit. In this case, XGT Panel closes the monitoring by itself and then takes an action to secure the memory again.

  • Page 109: Problems With Figure And Object Display

    Appendix 1 Troubleshooting 4. Problems with figure and object display The shape of object is not shown or the number or character value which has to be shown is Questions not shown. The shape of object is not shown or the number or character value which has to be shown is not phenomenon shown.
  • Page 110 Appendix 1 Troubleshooting Object type Phenomenon The part screen set in the object is not shown. Word Part But if communication is set with other object in the same part screen, it can be shown by that object. Animation Animation is not shown. Graph is not shown.
  • Page 111 Appendix 1 Troubleshooting Questions After switching the screen, the previous screen remains for a few minute After switching the screen, when there is no background or image in the part or number Phenomenon indication device, the previous screen remains for a few minute because of change of part <Cause>...

  • Page 112: Communication Problems

    Appendix 1 Troubleshooting 5. Communication problems Question It seems that communication does not work On the screen where the object is not many, communication works but when you move the Phenomenon screen where the object is many, timeout occurs. < Cause > (1) In the device setting, the communication time-out is set to be too short.
  • Page 113 Appendix 1 Troubleshooting Caution ► Before trial operation of the product, be sure to check if a normal communication is available between XGT Panel and the subject device of control App1-9...

  • Page 114: Remove The Usb Memory Card

    Appendix 1 Troubleshooting 6. Remove the USB memory card Question When removing the USB memory equipment, device is stopped for some times. This happens when doing data backup including logging, recipe. Phenomenon < Cause > (1) This happens because memory card is removed when doing data backup. <Solution>...

  • Page 115: External Memory Recognition

    Appendix 1 Troubleshooting 7. External memory recognition Question USB, SD Card not recognized. The USB or SD card is inserted but the unit does not recognize it. Phenomenon <Cause> (1) It appears when the USB memory or SD card is partitioned. <Solution>...

  • Page 116: Touch Recognition

    Appendix 1 Troubleshooting 8. Touch recognition Question It recognizes that you have touched a place you do not want. The place where I did not touch was touched. Phenomenon <Caution> (1) Check the surface of the touch panel for foreign matter such as water or oil. (2) Check if the power or communication cable is passing on the surface of the touch panel.

  • Page 117: Error Message During Program Execution

    Appendix 1 Troubleshooting 9. Error message during program execution When a problem occurs during the execution of XGT Panel, such as device startup, device diagnosis and environment setting, project download, and controller monitoring, an error message is displayed in the form of a message box. In this case, the message always displays a four-digit code before this content.
  • Page 118 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address Viewing Now, there is no downloaded project so No project in XGT you can’t see connection information. device 0x03 0x01 XGT Panel Panel. information Download the project from XP-Builder. Because of update error or Flash disk Failed to Start error, program can’t be executed.
  • Page 119 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address System 0x21 None alarm Scheduler 0x22 None related Recipe 0x23 None related Logging 0x24 None related Data list 0x25 None Abnormal send- Communication status is abnormal. payload.
  • Page 120 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address In case of not reading file where project property is included, download is Failed to get 0x06 XP Builder stopped. If this problem is repeated, Project ID.
  • Page 121 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address this problem is repeated, contact Customer Service Center. In case that it fail to delete the sound Failed to delete file of previous project because of error 0x0E XGT Panel Sound File.
  • Page 122 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address When downloading, the alarm history in Failed to initialize the NV-RAM is initialized in case of selecting the previous project’s monitor RECIPE area in NV 0x16 XGT Panel RAM.
  • Page 123 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address Failed to XGP It can’t find software to reboot XGT Panel startup 0x1D XGT Panel program. Please Panel. update XGT Panel Update the XGT Panel. Software.
  • Page 124 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address There is version information file but when it can’t read file normally because Cannot read XGT of the device error, downloading is 0x57 XGT Panel Panel software stopped because it doesn’t know version.
  • Page 125 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address The project data file is not saved correctly. Save the project data file at Download file size the USB again. When this symptom is 0x5E XGT Panel is invalid.
  • Page 126 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address Downloaded font file is moved to the original storage location. But when it Cannot move new 0x66 XGT Panel fails, the downloading is stopped. If this font files.
  • Page 127 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address In the present XGT Panel the new updated XGT Panel software’s name can not be changed. After rebooting the XGT Panel, update again. When rebooting, if you can’t start engine, delete Failed to rename 0x05...
  • Page 128 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address Because the each module version information can’t be read because of Failed to Create XGT Panel/ XGT Panel’s error, it failed to initialize. 0x21 Initialized Module XP-Builder Version File.
  • Page 129 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address To reboot the engine is not available because of wrong file which is developed by downloading wrong Failed to Start module or communication error. Engine. Please Touch 0x28 XGT Panel...
  • Page 130 Appendix 1 Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address XGT can’t be set as update mode because of XGT Panel error. After downloading new XGT Panel module through homepage, etc., copy UpdateNew.exe file among new module to the Failed to Initialize \\FlashDisk\LSISProduct\ directory of...

  • Page 131: Appendix 2 Appearance Size

    Appendix 2 Dimensions Appendix 2 Appearance size Unit: mm 1 . LXP-D12xx App2-1...

  • Page 132: Lxp-Mxxd

    Appendix 2 Dimensions 2 . LXP- MxxD App2-2...

  • Page 133: Appendix 3 Warranty Details And Environmental Policy

    (6) In case the company is not responsible for other natural disasters or fires 3. The above guarantee means only the HMI unit, so please consider safety when configuring the system or applying the product. 2. Environmental Policy LS ELECTRIC is following the environmental policy as follows. Environment Product Disposal Guide...
  • Page 134 Tel: 1-949-333-3140 E-Mail: america@ls-electric.com Disclaimer of Liability LS ELECTRIC has reviewed the information in this publication to ensure consistency with the hardware and software described. However, LS ELECTRIC cannot guarantee full consistency, nor be responsible for any damages or compensation, since variance cannot be precluded entirely.

This manual is also suitable for:

Lxp-d1200Lxp-d1201Lxp-d1210Lxp-d1211Lxp-m00dLxp-m01d ... Show all

Table of Contents
