3.26 [82.8]
n
4.31 [109.5]
A
WEIGHT - 1.298 LBMASS
n
3.91 [99.3]
n
3.51 [89.2]
A
(2) x 4-40 UNC
.99 [25.0]
1.97 [50.1]
USED ON:
MATERIAL:
FINISH:
CHAMFER ALL THREADS 30
TO ROOT DIAMETER
(2) x 8-32 UNC
.40 [10.2]
.80 [20.3]
P/N SUFFIX DEFINITION
UNLESS OTHERWISE SPECIFIED
-1 CONVERSION COATING
DIMENSIONS ARE IN INCHES AND
-2 PAINTING
INCLUDE CHEMICALLY APPLIED
-3 MARKING
OR PLATED FINISHES
-R REWORK
TOLERANCES AS FOLLOWS
SCALE:
1:1
`
DEC. .XXX
.005
`.010
R. PODLENA
DEC. .XX
DR:
`1
64
FRACT.
/
`30
CH:
P. BONAFEDE
ANGLES
'
CONCENTRICITY
.003 TIR
APP:
BREAK ALL SHARP EDGES
DATE DR:
11/26/2003
.005 MIN. .010 MAX.
~
32
MAX. SURF. ROUGHNESS:
DO NOT SCALE DRAWING
VIEW A-A
SCALE 1 : 1
2.19 [55.7]
3.04 [77.1]
OUTLINE
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST FOR
ROCHESTER, NEW YORK
QUOTATION OR PERFORMANCE
OF WORK FOR NAVITAR
0.0
inch
1.0
SCREENSTAR 1.25X TELEPHOTO
ADAPTER
0.0
mm
25.0
SIZE
1-16303
B
SHEET
4.35 [110.5]
REV
B
1
OF
1
