5.27 [133.9]
n
5.69 [144.4]
(2) x 4-40 UNC
.99 [25.0]
1.97 [50.1]
USED ON:
MATERIAL:
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES AND
INCLUDE CHEMICALLY APPLIED
OR PLATED FINISHES
TOLERANCES AS FOLLOWS
DEC. .XXX
FINISH:
DEC. .XX
FRACT.
ANGLES
CONCENTRICITY
BREAK ALL SHARP EDGES
.005 MIN. .010 MAX.
~
CHAMFER ALL THREADS 30
MAX. SURF. ROUGHNESS:
TO ROOT DIAMETER
.30 [7.6]
.40 [10.2]
(2) x 8-32 UNC
.80 [20.3]
3.04 [77.1]
WEIGHT - 6.144 LBMASS
P/N SUFFIX DEFINITION
DOCUMENT ARE PROPRIETARY
-1 CONVERSION COATING
-2 PAINTING
-3 MARKING
RESPONDING TO REQUEST FOR
-R REWORK
QUOTATION OR PERFORMANCE
SCALE:
1:2
`
.005
`.010
DJM
DR:
`1
64
/
`30
CH:
PB
'
.003 TIR
APP:
PB
DATE DR:
3/30/2004
32
DO NOT SCALE DRAWING
5.80 [147.2]
2.95 [75.0]
OUTLINE
THE CONTENTS OF THIS
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
ROCHESTER, NEW YORK
OF WORK FOR NAVITAR
0.0
inch
1.0
SCREENSTAR 0.65X WIDE ANGLE
ADAPTER
0.0
mm
25.0
SIZE
1-16423
B
SHEET
REV
B
1
OF
1
