Page 2 FCA Australia recommends that customers have all maintenance and, where necessary, repairs, carried out at an authorised Abarth repairer. Please see website www.fiat.com.au/fiat-dealers for a list of authorised Abarth repairers in your region (*). Authorised Abarth repairers use highly qualified technical staff and ensure that only appropriate equipment and tools are used on your vehicle.
Page 3 DASHBOARD AB0A0468 1. Side vent – 2. Right stalk: controls wiper, washer, trip computer – 3. Instument panel and warming lights – 4. Left stalk: external lights controls – 5. Turbo pressure gauge – 6. Central air vents – 7. Uconnect™ – 8. Passenger air bag – 9. Oddment compartment/document tray – 10. Heating/ventilation/climate control – 11. Power windows control – 12. Gear lever –...
Page 4 AB0A0469 1. Side vent – 2. Levers on steering wheel (only versions with Abarth competizione transmission) – 3. Instument panel and warming lights – 4. Turbo pressure gauge – 5. Central air vents – 6. Oddment/Car radio compartment – 7. Passenger air bag – 8. Oddment compartment/document tray – 9. Heating/ventilation/climate control – 10. Power windows control –...
Page 5 CHILD RESTRAINTS INSTALLATION OF THE WARNING ATTACHING CLIP Correct engagement of the child The recommendation of the ISO child 1) When installing a child restraint restraint attaching clip 1-fig. 4 is (restraints) seats to be used with the ensure that head restraint is raised achieved by depressing the retainer and tether strap is placed underneath vehicle in the main Owner Handbook...
Page 6 Child restraint system installation The table provides guidelines on positioning child restraint systems on the car seats. Each child restraint system position complies with the UNECE standards Number of seats Seat number Airbag Airbag ENABLED DISABLED Seat suitable for rearward facing child restraint systems Seat suitable for forward facing child restraint systems...
Page 7 Number of seats Seat number Airbag Airbag ENABLED DISABLED Sear suitable for ISOFIX forward facing fixtures (F2/ F2X / F3) (IUF) Sear suitable for forward facing Booster fixtures (B2/ NO (1) Only B2 B3 fixtures) U = Position suitable for a "universal" child restraint system approved for this weight category. UF = Position suitable for a "universal"...
Page 8 SUPPLEMENTARY FUEL TYPE RESTRAINT The engine in this vehicle is designed SYSTEM (SRS) - to use only unleaded fuel with an AIRBAG octane rating (RON) not less than 95. For the type of fuel to use and for information regarding what to do if FRONT AIRBAGS your car is accidentally filled with other types of fuel see the main owner’s...
Page 9 TYRES In the label fig. fig. 6 shows the type of tyre adopted and the required infl ation pressure. Refer to the “Technical data” chapter for futher information. F0S158Ab...
Page 10 NOTE ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
Page 11 ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
Page 12 FCA Italy S.p.A. – MOPAR – Technical Service Operations - Service Library Largo Senatore G. Agnelli 3 – 10040 Volvera – Torino (Italy) Print N. 603.53.929 – 04/2021 – 1 Edition...
Page 14 Dear Customer, We would like to congratulate and thank you for choosing an Abarth 595/695. We have written this handbook to help you get to know all the features of your car and use it in the best possible way. You should read it right through before taking to the road for the first time.
Page 15 If, after buying the car, you decide to install electrical accessories (with the risk of gradually draining the battery), contact an Abarth Dealership. They will calculate the overall electrical consumption and check that the car’s electrical system can support the required load.
Page 16 SCHEDULED SERVICING Correct maintenance of the car is essential for ensuring that it maintains its performance and its safety features, its environmental friendliness and low running costs for a long time to come. THE OWNER HANDBOOK CONTAINS ... important information, advice and warnings for correct use, driving safety and maintenance of your car over time. Special attention must be paid to the symbols provided (safety of persons) (environmental protection)
Page 17 If after buying the car, you decide to install electrical accessories that require a permanent electrical supply (e.g. radio, satellite anti-theft system, etc.) or accessories that in any case burden the electrical supply, contact an Abarth Dealership, whose personnel will check whether the car’s electrical system is able to withstand the load required, or whether it needs to be integrated with a more powerful battery.
Page 18 USE OF THE OWNER HANDBOOK OPERATING INSTRUCTIONS Each time direction instructions (left/right or forwards/backwards) about the vehicle are given, these must be understood as regarding an occupant in the driver's seat. Special cases not complying with this rule will be specified as appropriate in the text. The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do not correspond to the actual arrangement of your car.
Page 20 GETTING TO KNOW YOUR CAR KNOWING THE INSTRUMENT PANEL SAFETY STARTING AND DRIVING IN AN EMERGENCY SERVICING AND MAINTENANCE TECHNICAL SPECIFICATIONS MULTIMEDIA CONTENTS...
Page 22: Table Of Contents
GETTING TO KNOW YOUR CAR In-depth knowledge of your new car DASHBOARD ......10 starts here. THE KEYS........11 The handbook you are reading will tell IGNITION DEVICE ......13 you how things are done, and how it FIAT CODE SYSTEM ....13 works in a simple, direct way.
Page 23: Dashboard
DASHBOARD AB0A0363C 1. Adjustable air vents 2. Fixed air vents 3. Left stalk: direction indicators, dipped beam headlights, main beam headlights, Lane change function 4. Turbo pressure gauge, “SPORT” display 5. Instrument panel 6. Right stalk: windscreen washer/wiper, rear window washer/wiper 7. Uconnect™ multimedia system 8. “SPORT” mode, emergency lights, front/rear fog lights 9.
Page 24: The Keys
Briefly press the button : unlocking control. Should a new remote control of doors and boot, timed switching-on be necessary, contact an Abarth of internal lights and double flashing of Dealership and be ready to present direction indicators (where provided).
Page 25 AB0A0008C They must be disposed of as specified by law in the special containers or taken to an Abarth Dealership, which will take care of WARNING their disposal. 1) The electronic components inside the key may be damaged if the key is subjected to strong shocks.
Page 26: Ignition Device
STOP if the engine come with the car. Contact an Abarth 7) It is absolutely forbidden to carry out does not start, before the starting Dealership if you still cannot start the any after-market operation involving operation can be repeated.
Page 27: Doors
The correct lever position with locked symbols remains on, contact an to position (B) fig. 7 in the driver side doors is shown by the red (2) symbol, Abarth Dealership. door lock. visible on the handles. DOORS WARNING If one of the doors is not...
Page 28: Seats
SEATS Then release lever (4) and, pushing on the backrest, slide the seat forward FRONT SEATS (movement C). Lengthwise adjustment Lift lever (1) fig. 9 and push the seat forwards or backwards: in the driving position, you should be able to rest your arms on the rim of the steering wheel.
Page 29 Passenger side without position memory To bring back the seat in its initial position proceed as follows: slide the seat backwards pushing on the backrest to the desired position (movement D); adjust lever (4) fig. 12 (movement E); raise the backrest (movement F) until you hear the lock click.
Page 30 10) If a side bag is fitted, it is dangerous check that the seat belt is fully to use seat covers not available from extended and not twisted Lineaccessori Abarth.
Page 31: Head Restraints
HEAD RESTRAINTS STEERING WHEEL 11) After releasing the adjustment lever, always check that the seat is locked on the REAR The steering wheel can be adjusted guides by trying to move it back and forth. vertically. (where provided) If the seat is not locked into place, it may unexpectedly slide and cause the driver to To adjust bring the lever fig.
Page 32: Rear-View Mirrors
REAR-VIEW DOOR MIRRORS Proceed as follows: MIRRORS INTERIOR MIRROR The mirror is fitted with a safety device that causes its release in the event of a violent impact with the passenger. Lever (1) fig. 20 can be used to move the mirror to two different positions: normal or anti-glare.
Page 33: External Lights
EXTERNAL LIGHTS daytime running lights switch off and Flashing the headlights the side lights and dipped headlights To do this, pull the stalk towards the DAYTIME RUNNING switch on. steering wheel (unstable position) LIGHTS (DRL) "Daytime warning light switches on in fig.
Page 34 AB0A0352C conditions for all drivers while travelling WARNING The function can only be with headlights on. activated with the ignition device at Contact an Abarth Dealership to have MAR. the fog lights properly adjusted.
Page 35: Interior Lights
FOG LIGHTS ALIGNMENT which you are driving. Comply with legal (where provided) requirements. Contact an Abarth Dealership to have the fog lights properly adjusted. INTERIOR LIGHTS ADJUSTING THE FRONT CEILING LIGHT HEADLIGHTS ABROAD The fig.
Page 36: Window Washing
The ceiling light turns off 10 seconds D: continuous fast operation. after closing all the doors and on E: temporary fast operation (unstable locking the doors. The interior lights position). are switched off in any case after 15 The temporary fast function lasts as minutes to preserve battery charge.
Page 37 In case of direct passage from position rear window wiper on, in continuous WARNING Keep the window clean in slow operation. Operation stops when (B) to position (E), when the lever is the sensor area. reverse gear is disengaged. released it returns to position (A). AUTOMATIC WIPING “Smart washing”...
Page 38 If operation is not subsequently Deactivation restored, contact an Abarth Dealership. The user can disable automatic wiping 8) Make sure the device is switched off if there is ice on the windscreen glass.
Page 39: Manual Climate Control System
MANUAL CLIMATE CONTROL SYSTEM (where provided) CONTROLS AB0A0223C...
Page 40 10 minutes. Have – air intake from outside them. the system inspected at an Abarth Dealership before the summer. WARNING In warm-humid weather WARNING It is advisable to switch the...
Page 41: Automatic Climate Control System
AUTOMATIC CLIMATE CONTROL SYSTEM (where provided) CONTROLS AB0A0224C...
Page 42 : directs air flow to the Have the system inspected at an fig. 31 button turns off). central and side dashboard vents to Abarth Dealership before the summer. (1) AUTO button: automatic climate ventilate the body and face during the control function on hot season.
Page 43: Electric Windows
ELECTRIC WINDOWS ELECTRIC SUNROOF (where provided) 21) 22) Turn the ignition key to the MAR Sunshade position and press the following buttons: 1. Opening/closing of the left window. 2. Opening/closing of the right window. AB0A0287C To close: Press button (2) fig. 34 and hold it down: the roof will move to the "spoiler"...
Page 44: Soft Top
SOFT TOP Proceed as follows: WARNING keep the button (2) fig. 34 pressed (where provided) so that the roof closes completely in The 595C version is provided with an 23) When leaving the car, always remove stages the key from the ignition device to avoid automatically actuated electric soft after full closing, wait for the sunroof the risk of injury to those still inside the...
Page 45 OPERATION USING THE BUTTONS automatically to the full opening INSIDE THE CAR position (vertical opening). Opening from roof fully closed If one of the two buttons is pressed position before the final position is reached, the Press the button (1) fig. 38 once to soft top will stop and move back to the open the roof automatically to the initial position (spoiler position).
Page 46 WARNINGS If one of the two buttons is pressed before the stop position is reached, the The horizontal and vertical parts of soft top may stop in an intermediate the soft top can be operated at any horizontal open position. speed lower than 100 and 80 km/h respectively.
Page 47 To restore automatic movement, Do not keep the soft top folded for contact an Abarth Dealership. a long time: this could cause folds and INITIALISATION creases in the fabric.
Page 48 FRONT SPOILER once the all closed position has been reached, continue to press the button The car is provided with a front spoiler until the soft top makes a full opening which can be raised to improve and closing run. aerodynamic comfort inside the passenger compartment.
Page 49: Bonnet
CLOSING the risk of injury due to accidental operation of the soft top: improper use Proceed as follows: of the roof can be dangerous. Before hold the bonnet up with one hand and during operation, always check that and with the other remove rod (3) no-one is at risk of being injured by the fig.
Page 50: Boot
located under the large handle. The 30) Use both hands to lift the bonnet. Before lifting, check that the windscreen activation of the symbol on the wiper arms are not raised from the display indicates that the tailgate is not windscreen, that the vehicle is stationary shut properly.
Page 51: Interior Fittings
After a few seconds the button goes The driver and passenger side sun 33) If you are travelling in areas with few back to its initial position and the cigar visors include document pockets filling stations and you want to transport fuel in a spare tank, comply with the law by lighter is ready for use.
Page 52 35) The cigar lighter becomes very hot. present on all Lineaccessori Abarth Handle it with caution and do not allow it components to be used by children to avoid the risk of fire or burns.
Page 53: Roof Rack/ Ski Rack
"Technical 38) 39) 40) specifications". 39) Evenly distribute the load and take Lineaccessori Abarth provides a into account, when driving, the increased specific roof rack/ski rack for the responsiveness of the car to side wind. tailgate.
Page 54: Audio System
AUDIO SYSTEM PROTECTING THE ENVIRONMENT The basic audio system is composed The following devices are used for two mid-woofers, diameter 165 mm, reducing petrol fuel engine emissions: on the front doors; three-way catalytic converter two tweeters, diameter 19 mm, in the Lambda sensors front pillars;...
Page 55 KNOWING THE INSTRUMENT PANEL This section of the handbook provides INSTRUMENT PANEL all information that is useful for getting FEATURES........43 to know, interpreting, and using the MENU ITEMS ......46 instrument panel correctly. TRIP COMPUTER ......52 EOBD SYSTEM ......53 WARNING LIGHTS AND MESSAGES ........
Page 56: Instrument Panel Features
INSTRUMENT PANEL FEATURES COLOUR DISPLAY “STANDARD” SCREEN AB0A0472 1. Odometer (display of distance travelled in kilometres/miles) 2. Digital engine coolant temperature gauge 3. Digital rev counter (tachometer) 4. Range 5. SBR system indications 6. Outside temperature gauge 7. Car speed indication 8. Schedule 9. Current Consumption 10.
Page 57 SPORT MODE If the SPORT mode is active, the longitudinal/lateral accelerometer indicator screen (G-meter information) fig. 61 is displayed automatically. AB0A0473 1. Digital engine coolant temperature gauge 2. Digital rev counter (tachometer) 3. Engaged gear indicator 4. Car speed indication 5.
Page 58 (“Ghost function”). acceleration/deceleration with resulting coolant. In this case, stop the engine increased fuel consumption and and contact an Abarth Dealership. DIGITAL FUEL LEVEL harmful emissions. GAUGE INSTRUMENT PANEL The digital gauge indicates the amount...
Page 59: Menu Items
MENU ITEMS the automatic dual zone climate control scroll up or down through the options; display is also adjusted. during setting operations, they The menu comprises a series of For adjusting, see the "Menu items" increase or decrease values. options which can be selected using paragraph in this chapter.
Page 60 brightness of the instruments Speed beep (Speed select the main menu setting you wish limit) accordingly. to change; – With this function it is possible to set press the + or buttons (with single The brightness of the instrument panel the car speed limit (km/h or mph);...
Page 61 button down to return to the standard To adjust, proceed as follows: hold the MENU button down screen without storing. again to return to the standard screen briefly press the MENU button: or to the main menu according to To cancel the setting, proceed as the display will show the two submenus where you are in the menu.
Page 62 – Autoclose (Automatic press the + or button to move English, German, Portuguese, Spanish, central locking with car between the two submenus; French, Dutch, Polish, Turkish and moving) once you have selected a submenu, Russian. (where provided) press the MENU button briefly; To set the desired language, proceed When activated (On), this function when you select “Distance”, briefly...
Page 63 – buttons are pressed. is turned to MAR. Go to an Abarth To consult this information, proceed as To set the desired volume, proceed as Dealership, where the "Service follows: Schedule"...
Page 64 – Reset tyres (iTPMS press the + or buttons to select proceed as follows: reset) “Yes” (to confirm enable/disable) or press the MENU button briefly, (where provided) “No” (to abort); the display will flash "On" or "Off" press the MENU button briefly, With this function it is possible to reset depending on the previous setting;...
Page 65: Trip Computer
TRIP COMPUTER To show the Uconnect™ information “Trip B” may be used to display the on the display ("On"), or clear it ("Off"), figures relating to: The Trip computer is used to display proceed as follows: Distance travelled B information on car operation when the Average consumption B press the MENU button briefly,...
Page 66: Eobd System
mountain roads, etc.), conditions of and also zero them to begin a new Start of journey procedure use (load, tyre pressures, etc.). Trip mission: With the ignition key in the MAR-ON planning must therefore take the above brief press to access the various position, reset by pressing the TRIP into account.
Page 67 WARNING After eliminating the failure, to check the system completely, Abarth Dealerships must run a bench test and, if necessary, road tests which may also call for a long journey.
Page 68: Warning Lights And Messages
The warning light will flash and a buzzer will sound if the car is in motion and the front seat belts are not correctly fastened. For permanent deactivation of the acoustic signal (buzzer) of the S.B.R. (Seat Belt Reminder) system contact an Abarth Dealership. The system can be reactivated at any time using the Setup Menu.
Page 69 In this case, the rear wheels may suddenly lock and the car may swerve when braking sharply. On some versions the display shows the dedicated message. amber Drive very carefully to an Abarth Dealership to have the system inspected immediately. amber AIR BAG FAILURE The warning light switches on when the ignition key is turned to MAR, but it should switch off after a few seconds.
Page 70 In this case, stop the car immediately (should it be in motion), stop the engine for about 20 seconds and then restart the engine. If the warning light stays on, contact an Abarth Dealership.
Page 71 Under these conditions, the vehicle can continue travelling at moderate speed without demanding excessive effort from the engine. Prolonged use of the car with the warning light on may cause damage. Contact an Abarth amber Dealership as soon as possible.
Page 72 If this is not the case, carry out the Tyre reset procedure after restoring the normal operating conditions. If the malfunction warning persists, contact an Abarth Dealership as soon as possible. Warning light...
Page 73 Warning light What it means LEFT DIRECTION INDICATOR The warning light turns on when the direction indicator control lever is moved downwards or, together with the right indicator, when the hazard warning light button is pressed. green RIGHT DIRECTION INDICATOR The warning light turns on when the direction indicator control lever is moved upwards or, together with the left indicator, when the hazard warning light button is pressed.
Page 74 MIN and MAX marks on the reservoir itself. Also check visually for any fluid leaks. Contact an Abarth Dealership if the warning light switches on when the engine is started again;...
Page 75 It is also displayed each time the key is turned to MAR or, for some markets, every 200 km (or equivalent value in miles). amber Go to an Abarth Dealership, where the "Service Schedule" operations will be performed and the message will be reset. ASR SYSTEM...
Page 76 The display will show the symbol together with a dedicated message on some versions when there is an anomaly in the Hill Holder system. amber In this case, contact an Abarth Dealership as soon as possible. FUEL CUT-OFF SYSTEM The display will show the symbol and a dedicated message if the fuel cut-off system intervenes.
Page 77 The symbol switches on in the event of fuel level sensor failure. Contact an Abarth Dealership. amber RAIN SENSOR FAILURE The symbol switches on in the case of failure of the rain sensor. Contact an Abarth Dealership as soon as amber possible.
Page 78 (on certain versions together with a dedicated message on the display) stop the engine immediately and contact an Abarth Dealership. IMPORTANT 17) If there is a failure in the transmission, contact an Abarth Dealership as soon as possible to check the system.
Page 79 SAFETY The chapter that you are about to read ACTIVE SAFETY SYSTEMS ... 67 is very important: it describes the safety iTPMS (indirect Tyre Pressure systems with which the car is equipped Monitoring System)....... 70 and provides instructions on how to OCCUPANT PROTECTION use them correctly.
Page 80: Active Safety Systems
ACTIVE SAFETY surface where the grip of the left and The ESC system corrects the car’s right wheels varies, or on corners. understeer and oversteer, distributing SYSTEMS the brake force on the wheels The Electronic Braking Force The vehicle has the following active appropriately.
Page 81 uphill: car stationary on a road with Depending on the slipping conditions, 65) 66) 67) 68) 69) 70) two different control systems are a gradient higher than 5%, engine PBA (Panic Brake running, brake pressed and gearbox activated: Assist) SYSTEM in neutral or gear (other than reverse) if the slipping involves both drive The PBA system is designed to...
Page 82 driving, especially when cornering, far road is about to reach its limit. You must 59) ESC performance features must not more able to prevent understeer. slow down to a suitable speed. induce the driver to take unnecessary or 51) The ABS cannot overrule the natural unfounded risks.
Page 83: Itpms (Indirect Tyre Pressure Monitoring System)
iTPMS (indirect space-saver wheel, being smaller than the original wheel, provides less grip. Tyre Pressure 67) The ASR cannot overrule the natural Monitoring System) laws of physics, and cannot increase the grip available according to the condition of (where provided) the road.
Page 84 If the warning the Reset procedure is carried out. surface (e.g. icy, snowy, unsurfaced persist, contact an Abarth Dealership. roads...) the warning may be delayed or The Reset procedure must be carried partial in detecting the deflation of one out: or more tyres.
Page 85: Occupant Protection Systems
SEAT BELTS 80) Insufficient tyre inflation increases fuel consumption, reduces the tread duration USING THE SEAT BELTS and may affect the capacity to drive safely. All vehicle seats are equipped with seat belts with three anchor points and OCCUPANT a retractor. The driver is responsible PROTECTION for respecting, and ensuring that all SYSTEMS...
Page 86: Sbr System (Seat Belt Reminder)
WARNING When putting the back seat paragraphs). will be interrupted and the warning to its normal position, make sure the NOTE Contact an Abarth Dealership light switches on fixed. If the entire seat belts are positioned so they are to deactivate this acoustic warning time has not elapsed and reverse gear ready to use.
Page 87: Pre-Tensioners
PRE-TENSIONERS deactivated and the icon lights up with fixed light until the end of the entire The car is equipped with front seat cycle. belts pretensioners, that reduce slack Furthermore, the icons light up to in the belts in the event of a severe indicate the status of the seat belts frontal collision.
Page 88 LOAD LIMITERS both fig. 74. In general, do not place To increase passenger safety, the front any objects between the person and seat belt reels contain a device which the belt. allows the force acting on the chest and shoulders to be modulated during the belt restraining action in the event of a frontal collision.
Page 89: Child Restraint Systems
Contact an Abarth Dealership manoeuvre. wear or cuts. should intervention be necessary on these components. Children must be seated safely and comfortably. As far as the...
Page 90 WARNING 87) SERIOUS DANGER. When an active passenger airbag is fitted, DO NOT install rear facing child restraint systems on the front seat. Deployment of the airbag in an accident could cause fatal injuries to the child regardless of the severity of the impact.
Page 91 All restraint devices must bear the type-approval data, together with the control mark, on a label solidly fixed to the child restraint system which must never be removed. Lineaccessori Abarth offers child restraint systems for each weight group. These devices are recommended having been specifically designed for Abarth cars.
Page 92 FITTING A CHILD RESTRAINT SYSTEM WITH SEAT BELTS 91) 92) 93) 94) The Universal child restraint systems installed with the seat belts only are type-approved on the basis of the ECE R44 standard and are divided into various weight groups. AB0A0063C AB0A0065C WARNING The figures are indicative...
Page 93 seat cushion meets the backrest, remove the parcel shelf and fix the upper strap (provided with the child restraint system) to the dedicated anchor (2) fig. 80 located at the bottom of the seat back. WARNING The central rear seat is not approved for any type of ISOFIX child restraint system.
Page 94 injured, even fatally. When fitting a restraint system for newborns or children, strictly comply with the instructions provided by the Manufacturer. 93) When the child restraint system is not used, secure it with the seat belt or with the ISOFIX anchorages, or remove it from the car.
Page 95 Child restraint system installation The table provides guidelines on positioning child restraint systems on the car seats. Each child restraint system position complies with the UNECE standards. Number of seats Seat number Airbag Airbag ENABLED DISABLED Seat suitable for rearward facing child restraint systems (U) Seat suitable for forward...
Page 96 Number of seats Seat number Airbag Airbag ENABLED DISABLED Sear suitable for forward facing Booster fixtures NO (1) Only B2 (B2/B3 fixtures) U = Position suitable for a "universal" child restraint system approved for this weight category. UF = Position suitable for a "universal" forward facing child restraint system approved for this weight category. IUF = Position suitable for an "ISOFIX"...
Page 97 Child restraint system installation (right-hand drive version) The table provides guidelines on positioning child restraint systems on the car seats. Each child restraint system position complies with the UNECE standards. Number of seats Seat number Airbag Airbag ENABLED DISABLED Seat suitable for rearward facing child restraint...
Page 98 Number of seats Seat number Airbag Airbag ENABLED DISABLED Sear suitable for forward facing Booster fixtures Only B2 NO (1) (B2/B3 fixtures) U = Position suitable for a "universal" child restraint system approved for this weight category. UF = Position suitable for a "universal" forward facing child restraint system approved for this weight category. IUF = Position suitable for an "ISOFIX"...
Page 99: Supplementary Restraint System (Srs) - Airbag
SUPPLEMENTARY While travelling, do not let the child Main recommendations to carry children safely sit incorrectly or unfasten the belts. RESTRAINT SYSTEM Install the child restraint systems Never allow a child to put the belt's (SRS) – AIRBAG on the rear seat, which is the most diagonal section under an arm or protected position in the event of an behind their back.
Page 100 occupants body and the structures and calibrated to protect front seat Passenger front airbag which could cause injury. It will deflate passengers wearing seat belts. This consists of an instantly immediately afterwards. Their volume at the moment of inflating bag contained in a special Front airbags are not a replacement of maximum inflation fills most of the compartment in the dashboard fig.
Page 101 front airbag and the front side bag are reactivated. AB0A0307C AB0A0073C AB0A0228C WARNING WARNING To manually deactivate the 99) Do not apply stickers or other objects passenger side front airbag and the on the steering wheel, on the dashboard front side bag, see paragraph "Menu in the passenger side airbag area, on side items"...
Page 102 In this case, the warning light may not indicate a possible problem with the airbag restraint system. Before driving off, contact an Abarth Dealership to have the system checked immediately. 104) The warning light indicates the passenger airbag protection status. If...
Page 103 Passenger's front airbag and child restraint systems: IMPORTANT AB0A0072...
Page 104 Abarth driver and the passenger and airbags Dealership. If the car is scrapped, have protecting the head. Non-activation of...
Page 105 Abarth Dealership to have the system 110) When the ignition key is turned to checked immediately. MAR, the warning light switches for few 106) In some versions, in case of LED seconds, then if the passenger airbag is failure (located on the plate of the active it should switch off.
Page 106 STARTING AND DRIVING We have now reached the "heart" of STARTING THE ENGINE ....94 the car: let's see how to use the car to WHEN PARKED ......95 its full potential. USING THE MANUAL We’ll look at how to drive safely in TRANSMISSION ......
Page 107: Starting The Engine
117) It is dangerous to run the engine in enclosed areas. The engine consumes Contact an Abarth Dealership if you still oxygen and engine exhaust contains cannot start the engine. carbon dioxide, carbon monoxide and 19) 20) other toxic gasses.
Page 108: When Parked
120) The car should be braked after a few 120) clicks of the lever. If it is not, contact an Abarth Dealership to have it adjusted.
Page 109: Using The Robotised Sequential Transmission
USING THE WARNING The clutch pedal should mode (automatic = AUTO or manual = be used only for gear changes. Do no display). ROBOTISED not drive with your foot resting on SEQUENTIAL STARTING THE CAR the clutch pedal, however lightly. NOTES TRANSMISSION Where present, the electronic clutch...
Page 110 request may adversely affect the In this way the engine speed and correct operation of the engine or the power can be suddenly increased and transmission, the system will not allow then automatically restored when the the gear change but will automatically conditions set previously are resumed.
Page 111 If the engine does not With the car stationary, the engine 3 seconds from the request: if the start, contact an Abarth Dealership. running and (1 st ), (2 nd ) or (R) engaged, request is not executed, the system will...
Page 112: Dualdrive Electric Power Steering
operate the handbrake. Wait until Although it is strongly inadvisable, IMPORTANT the indication of the gear engaged if you are driving downhill and, for disappears on the display before unexpected reasons, you let the car 24) Using the levers incorrectly (levers releasing the brake pedal.
Page 113: Sport Function
SPORT FUNCTION may become harder: this is normal WARNING When the SPORT button is and is due to the intervention of the pressed, the function is activated about When the SPORT button (1) fig. 97 system to protect the electric steering 5 seconds later.
Page 114: Parking Sensors
PARKING SENSORS car indicate that an obstacle has increases as the distance between been detected. The system indicates the car and the obstacle decreases; (where provided) becomes continuous when the a detected obstacle by displaying an Parking sensors are located in the rear distance between the car and the arc according to the distance of the bumper to detect and inform the driver,...
Page 115 Some conditions may influence the not attached to prevent the activation by an Abarth Dealership. Interventions performance of the parking system: of the sensors. on the bumper that are not carried out Reduced sensor sensitivity and a Do not apply stickers to the sensors.
Page 116: Refuelling The Car
REFUELLING THE Symbols for petrol powered cars Stop the engine before refuelling. Only refuel with unleaded petrol with octane rating (RON) not less than 95, E5: Unleaded petrol containing up to in compliance with the European 2.7% (m/m) oxygen and with maximum specification EN228.
Page 117: Saving Fuel
SAVING FUEL fuel consumption (by up to +25% in an for faster acceleration will increase fuel consumption. In the same way urban cycle). GENERAL INFORMATION improper use of a high gear increases Climate control system Car maintenance consumption, emissions and engine Using the climate control system will Checks and adjustments should be wear.
Page 118 and rough road surfaces also adversely affect consumption. Stops in traffic During prolonged hold-ups (e.g. level crossings) switch off the engine.
Page 119 EMERGENCY STARTING .... 122 Warranty Booklet. FUEL CUT-OFF SYSTEM .... 123 It is also possible to call the 00 800 TOWING THE CAR ..... 123 3428 0000 freephone number to search the nearest Abarth Authorised Dealership.
Page 120: Hazard Warning Lights
HAZARD WARNING the centre of the diffuser, extending The lights switch off automatically when progressively towards the edges. emergency braking ceases. LIGHTS REPLACING A BULB These lights are switched on by pressing button (1) fig. 102, regardless GENERAL of the position of the ignition key. INSTRUCTIONS Before replacing a bulb check the contacts for oxidation;...
Page 121 Halogen bulbs: (type D) release the fastening clip from its housing to remove the bulb. Halogen bulbs: (type E) release the fastening clip from its housing to remove the bulb. Xenon gas discharge bulbs: (type F) contact an Abarth Dealership for replacement.
Page 122 Light bulbs Type Power Ref. Figure Main beams Dipped headlights Xenon gas discharge dipped beam headlights (where present) Front side lights / daytime running lights LED/W21W Front direction indicators PY24W Side direction indicators Rear direction indicators PY2IW Tail/brake light P21 / 5W 5/21W Reverse gear...
Page 123: Replacing An Exterior Bulb
29) Where possible, it is advisable to have bodywork (please use a sufficiently rigid bulbs changed at an Abarth Dealership. and appropriately thick plastic card). The correct operation and direction of the AB0A0309C external lights are absolutely essential for...
Page 124 To replace the bulb, proceed as refit the bulb in its housing and remove the rubber cap on the bulb follows: reconnect the connector; holder; refit the protection cap in its housing release the two bulb holding clips (1) apply leverage in the point shown and turn clockwise.
Page 125 (where provided) AB0A0097C fig. 110: For replacing these bulbs, contact an 1: side / brake light; remove the assembly; Abarth Dealership. disconnect the electrical connector 2: direction indicators. REAR LIGHT CLUSTERS (2) fig. 112; To replace the bulb proceed as follows: press the retaining device (3) fig.
Page 126: Replacing Interior Bulbs
Contact an the retaining device is correctly locked; Abarth Dealership. screw in the two fastening screws and reinstall the guard caps. REPLACING NUMBER PLATE LIGHTS INTERIOR BULBS To replace the bulbs, proceed as...
Page 127: Fuse Replacement
FUSE Refer to the tables on the following pages to identify the protective fuse. REPLACEMENT FUSE LOCATION Contact an Abarth Dealership to have a Dashboard fusebox fuse replaced. To access the fuse you must remove GENERAL INFORMATION the press-fit cover (5) fig. 120.
Page 128 To access the fuses, proceed as WARNING follows: Fully press screw (1) fig. 122; 131) Contact an Abarth Dealership to have at the same time slowly rotate the a fuse replaced. screw anticlockwise, until resistance is 132) If the fuse blows again, contact an encountered (do not overtighten);...
Page 129 DASHBOARD FUSEBOX AB0A0106C PROTECTED DEVICE FUSE AMPERE Headlight alignment corrector 5 (*) Diagnosis socket, Uconnect, climate control, EOBD Brake light switch, instrument panel node Central door locking Windscreen/rear window washer pump Driver side electric window...
Page 130 PROTECTED DEVICE FUSE AMPERE Passenger side electric window Parking sensor, controls backlighting Climate control, brake lights, clutch, electric sunroof, electric mirrors Instrument panel node (*) (where provided)
Page 131 ENGINE COMPARTMENT FUSEBOX AB0A0319C PROTECTED DEVICE FUSE AMPERE HI-FI Climate control electric fan Headlight washers Horns Main-beam headlights 10/15(*) Electric roof motor...
Page 132 PROTECTED DEVICE FUSE AMPERE Robotised sequential transmission control unit power supply (+ ignition) Heated rear window Fog lights Robotised sequential transmission control unit Front power socket (with or without cigar lighter) (*) Only for versions equipped with Xenon gas discharge lamps...
Page 133: Fix&Go Kit
Fix&Go KIT OPT1 kit plug the electrical connector of the tyre inflation kit into the 12V socket of (for versions/markets, where provided) the car and start the engine; The Fix&Go quick tyre repair kit is operate the compressor by pressing located in the boot inside a dedicated the ON/OFF button (5) fig.
Page 134 ON/OFF button (5) fig. 126. When turning on, do not resume driving but the pressure gauge (7) indicates the contact an Abarth Dealership. prescribed pressure indicated in Only for OPT1: Press the air release the "Wheels" chapter in this Owner...
Page 135: Emergency Starting
141) This starting procedure must be If the symbol on the display turns when the engine has been started, performed by expert personnel because on constantly, contact an Abarth remove the leads reversing the order incorrect actions could cause electrical Dealership immediately. above.
Page 136: Fuel Cut-Off System
TOWING THE CAR To restore the correct operation of the IMPORTANT car, proceed as follows: The tow ring provided with the car is turn the ignition key to the MAR housed in the tool bag under the boot 32) Never use a fast battery charger to position;...
Page 137 When not tow the car and contact an Abarth towing the car, you must comply with all Dealership. specific traffic regulations related to the towing device and adopt an appropriate driving behaviour.
Page 138 SERVICING AND MAINTENANCE Proper maintenance allows car SCHEDULED SERVICING ... 126 performance to be maintained over SERVICE SCHEDULE ....127 time, operating costs to be contained, PERIODIC CHECKS ....130 and safety system performance to be DEMANDING USE OF THE safeguarded.
Page 139: Scheduled Servicing
Scheduled Servicing interventions are set out by the Manufacturer. Failure to have them carried out may invalidate the warranty. It is advisable to inform an Abarth Dealership of any small operating irregularities without waiting for the next scheduled service deadline.
Page 140: Service Schedule
SERVICE SCHEDULE WARNING Once you have carried out the last intervention in the table, continue with the scheduled servicing, maintaining the frequency indicated in the plan by marking each operation with a dot or dedicated note. Warning: simply restarting the maintenance from the start of the plan may cause the allowed interval to be exceeded for some operations! ...
Page 141 Thousands of miles Thousands of kilometres Years Check cleanliness of hood and boot locks, cleanliness and lubrication of linkage Check soft top operation while closing and opening; check of seals and lubrication of canvas sliding side guide (only 595C/695C version) Check handbrake lever travel and adjust, if necessary Visually inspect conditions and wear of front and rear disc brake pads and operation of pad wear indicator (where present)
Page 142 (5) The following are essential to ensure correct operation and prevent serious damage to the engine: only use spark plugs of the same make and type specially certified for 1.4 Turbo petrol Abarth engines (see the information in the "Engine" paragraph); strictly comply with the spark plug replacement interval given in the Service Schedule;...
Page 143: Periodic Checks
LUBRICANTS products, which and wear; have been designed and produced check cleanliness of bonnet specifically for Abarth cars (see and luggage compartment locks, table "Capacities" in the "Technical cleanliness and lubrication of linkage; specifications" chapter).
Page 144: Checking Levels
CHECKING LEVELS 148) 149) 135 HP, 145 HP and 160 HP versions AB0A0353C 1. Engine oil filler 2. Engine oil dipstick 3. Engine coolant 4. Windscreen washer fluid 5. Brake fluid 6. Battery...
Page 145 163 HP, 165 HP and 180 HP versions AB0A0349C 1. Engine oil filler 2. Engine oil dipstick 3. Engine coolant 4. Windscreen washer fluid 5. Brake fluid 6. Battery WARNING 148) Never smoke while working in the engine compartment: gas and inflammable vapours may be present, with the risk of fire. 149) Be very careful when working in the engine compartment when the engine is hot: you may get burned.
Page 146 34) Abarth 595/695 is designed and built for road use, in compliance with the current regulations. Car use in the track must be considered as occasional and in any case under the responsibility of the user. The car CANNOT be modified or tampered with for any reason; this would alter the Manufacturer type-approval and/or safety requirements.
Page 147 ENGINE OIL WARNING After adding or changing BRAKE FLUID the oil, let the engine turn over for a few Check that the fluid is at the maximum seconds and wait a few minutes after level (the fluid level in the reservoir must turning it off before you check the level.
Page 148: Battery
You are advised to go to an flammable. The engine compartment Abarth Dealership to have the oil and filters USEFUL ADVICE FOR contains hot components which may set it changed. EXTENDING THE LIFE OF on fire.
Page 149: Recharging The Battery
155) Using the battery with low fluid will It is advisable to contact an Abarth WARNING If the charge level remains irreparably damage the battery and may...
Page 150: Replacing The Windscreen/Rear Window Wiper Blades
REPLACING THE REPLACING WIPER negative (-) symbols, and are shown BLADES on the battery cover. The battery WINDSCREEN/REAR Proceed as follows: terminals must also be corrosion-free WINDOW WIPER and firmly secured to the terminals. lift up the windscreen wiper arm (1) BLADES If a "quick-type"...
Page 151: Lifting The Vehicle
As a result of its sporty nature, the car is fitted with aerodynamic spoilers at the bottom and side skirts at the sides. If the car needs to be raised, go to an Abarth Dealership which is equipped with arm lifts and workshop lifts. AB0A0113C AB0A0114C...
Page 152: Wheels And Tyres
It is normal for the pressure to increase periodically check that the tyres have An Abarth Dealership will be happy to when the car is used; for the correct no cuts in the side wall, abnormal...
Page 153: Car Inactivity
CAR INACTIVITY WARNING When using snow tyres 162) If tyre pressure is too low, it may with a maximum speed index below overheat and be severely damaged as a If the car is to be left inactive for longer result. the one that can be reached by the car than a month, the following precautions 163) Do not switch tyres from the...
Page 154: Bodywork
Use only original also not to be underestimated. WARNING After setting the ignition paint products for touch-ups (see Abarth has used the best device to STOP and having closed “Bodywork paint identification plate” in manufacturing technologies on your the driver side door, wait at least the “Technical Specifications”...
Page 155 can damage the car over a period of Versions with matt paintwork Some versions are fitted with time; exclusive decorations on the door These versions have exclusive matt wash the bodywork using a low mirror covers; do not use pressurised paintwork which requires special care pressure jet of water;...
Page 156 Wipe a sponge with a slightly soapy Avoid (if at all possible) parking the acetone) for cleaning the plastic lenses solution over the bodywork, frequently car under trees; remove vegetable of the headlights. rinsing the sponge. resins immediately as, when dried, it Rinse well with water and dry with may only be possible to remove them WARNING When cleaning the car...
Page 157 The soft top fabric is treated with a Clean the surface with a microfibre defrost windows/vehicle glass as they can special water-repellent, waterproof cloth or soft sponge dipped in a damage the paint. 42) It is not advisable to wash with product.
Page 158: Interior
PLASTIC AND COATED covered area, applying a uniform light 51) Rinse immediately to remove soap PARTS pressure (do not rub hard). to prevent stains. Repeat the operation if It is advisable to clean interior plastic needed. Rinse and wring out the microfibre 52) Follow the instructions on the parts with a moist cloth and a solution cloth, and pass over the covered area...
Page 159 TECHNICAL SPECIFICATIONS Everything you may find useful for IDENTIFICATION DATA ....147 understanding how your car is made ENGINE ........148 and works is contained in this chapter INTAKE SYSTEM ....... 150 and illustrated with data, tables and TRANSMISSION ......151 graphics.
Page 160: Identification Data
IDENTIFICATION BODYWORK PAINT D Maximum authorized weight of IDENTIFICATION PLATE vehicle fully laden. DATA The plate is applied on the external E Maximum authorised weight of fully The following identification codes are tailgate post (left side) and it bears the laden car plus trailer.
Page 161: Engine
ENGINE (For markets where provided) 1.4 TB PETROL ABARTH 1.4 TB PETROL ABARTH 1.4 TB PETROL ABARTH 160 GENERAL INFORMATION 135 HP 145 HP Engine code 312A1000 312B4000 312B4000 Cycle Otto Otto Otto Number and position of cylinders 4 in line...
Page 162 1.4 TB PETROL 1.4 TB PETROL 1.4 TB PETROL 1.4 TB PETROL ABARTH ABARTH ABARTH ABARTH GENERAL INFORMATION 163 HP 165 HP 180 HP(*) 180 HP Engine code 312B6000 312B3000 312B3000 312A3000 Cycle Otto Otto Otto Otto Number and position of cylinders...
Page 163: Intake System
INTAKE SYSTEM Model 1.4 TB PETROL ABARTH Timed sequential electronic injection, with fixed geometry Intake system turbocharger 168) WARNING 168) Modifications or repairs to the fuel supply system that are not carried out properly or do not take the system’s technical specifications...
Page 164: Transmission
Clutch Self-adjusting pedal without idle stroke Traction Front 1.4 TB PETROL ABARTH - ROBOTISED SEQUENTIAL Model GEARBOX Five forward speeds plus reverse with electronically managed Transmission electro-hydraulic control system Clutch...
Page 165: Brakes
BRAKES 1.4 TB PETROL ABARTH 135 HP – 145 HP Model front rear Service brakes self-ventilated discs solid disc Model 1.4 TB PETROL ABARTH 165 HP front rear Service brakes perforated self-ventilated discs perforated solid discs Model 1.4 TB PETROL ABARTH 180 HP...
Page 166: Suspension
SUSPENSION Model 1.4 TB PETROL ABARTH MacPherson independent wheels, mechanical crossmember, shock Front absorbers and coil springs; anti-roll bar. torsion beam with interconnected wheels consisting of a torsion axle, Rear anti-roll bar and two tubular arms with shock absorbers and coil...
Page 167: Steering
STEERING Model 1.4 TB PETROL ABARTH rack and pinion with dual strategy electric power steering Type (normal/sport) Kerb-to-kerb turning circle (m) 10.8...
Page 168: Wheels
WHEELS Load index (capacity) RIMS AND WHEELS Alloy rims. Tubeless radial carcass 70 = 335 kg 81 = 462 kg tires. All approved tyres are listed in the registration document. 71 = 345 kg 82 = 475 kg 72 = 355 kg 83 = 487 kg WARNING If there are any discrepancies between the Owner...
Page 169 keeps the bead of tubeless tyres in position on the rim). RIM PROTECTOR TYRES AB0A0356C 169) WARNING 169) Do NOT fit wheel hubs when using integral hubs fixed (with springs) to the steel rim, and tyres other than the factory- fitted tyres provided with the Rim Protector (fig.
Page 170 (**) Winter tyres (Pirelli Snow Sport 195/45 R16) are also available for use if the car is mainly driven on snow-covered roads. (***) Snow chains suitable for 205/40 R17 tyres are available at the Abarth Dealership. These may be used at a maximum speed of 50 km/h.
Page 171 COLD TYRE INFLATION PRESSURE (bar) When the tires are warm, the inflation pressure should be + 0.3 bar in relation to the recommended figure. However, recheck that the value is correct with the tyre cold. Medium load (*) Full load Tyres Front Rear...
Page 172: Dimensions
DIMENSIONS Dimensions are expressed in mm and refer to the vehicle equipped with its standard-supplied tyres. Height is measured with car unladen. BOOT VOLUME Unladen capacity (V.D.A. standards) = 185 dm 3 AB0A0292C 3660 2300 1490 1415/1409 (*) 1627 1408/1402 (*) (*) With 205/40 R17 tyres...
Page 173: Weights And Loads
WEIGHTS AND WARNING A trailer cannot be towed so there are no provisions for fitting a tow LOADS hook. To identify the weights and masses of your car, refer to the car registration document containing the type- approved weights (for markets where provided) or the plate applied to the rear floor under the boot lining, next to the spare wheel compartment.
Page 174: Refuelling
REFUELLING Model 1.4 TB PETROL ABARTH Prescribed fuels and original lubricants Fuel tank (litres) Unleaded petrol no lower than 95 R.O.N. (EN228 specifications) Fuel tank reserve (litres) 50% mixture of distilled water and Engine cooling system (litres) 5.15 PARAFLU UP (*) Engine sump (litres) 2.75...
Page 175: Fluids And Lubricants
PRODUCT SPECIFICATIONS Original liquids and Features Specification Applications lubricants SELENIA ABARTH Fully synthetic lubricant 10W50 According to Service for ultra high performance SAE 10W–50 ACEA C3 9.55535-GH2 Contractual Technical...
Page 176 Original liquids and Features Specification Applications lubricants Synthetic fluid for brake and clutch systems. TUTELA TOP 4/S Hydraulic brakes and 9.55597 or MS.90039 Brake fluid Exceeds specifications Contractual Technical hydraulic clutch controls F.M.V.S.S. no. 116 DOT Reference N° F005.F15 4, ISO 4925 SAE J1704. Red protective with antifreeze action, based Cooling circuits...
Page 177: Performance
7.8 (**) / 8 (***) 1.4 TB PETROL ABARTH 160 HP 7.3 (**) / 7.4 (***) 1.4 TB PETROL ABARTH 163 HP (*) (****) 7.3 (**) / 7.4 (***) 1.4 TB PETROL ABARTH 165 HP (****) 7.3 (**) / 7.4 (***) 1.4 TB PETROL ABARTH 180 HP (****)
Page 178: Fuel Consumption And Co 2 Emissions
FUEL CONSUMPTION AND CO 2 EMISSIONS The fuel consumption and CO 2 emission figures declared by the manufacturer are determined on the basis of the type-approval tests laid down by the applicable standards in the country where the car is registered. The type of route, traffic conditions, weather conditions, driving style, general condition of the car, trim level/equipment/accessories, use of the climate control system, car load, presence of roof racks and other situations that adversely affect the aerodynamics or wind resistance lead to different fuel consumption values than those measured.
Page 179: Prescriptions For Handling The Car At The End Of Its Life
PRESCRIPTIONS FOR HANDLING THE CAR AT THE END OF ITS LIFE (for markets where provided) FCA has been committed for many years to safeguarding the environment through the constant improvement of its production processes and manufacturing products that are increasingly "eco-compatible". To provide the best possible service in terms of compliance with environmental laws and European Directive 2000/53/EC governing cars at the end of their life, FCA is offering its customers the chance to hand over their car at the end of its life without incurring any additional costs.
Page 180 MULTIMEDIA TIPS, CONTROLS AND GENERAL INFORMATION ... 168 This chapter describes the main functions of the Uconnect™ 5" AUX and USB SOURCE ....169 LIVE, Uconnect™ 5" Nav LIVE, Uconnect™ 5” LIVE / Nav LIVE ..170 Uconnect™ 7" HD LIVE and UCONNECT™...
Page 181: Tips, Controls And General Information
WARNING The volume may be Abarth Dealership with an ID and the or if the electronic control unit (Body increased when receiving traffic car papers.
Page 182: Aux And Usb Source
Immediately stop using the system in the event of a fault. Otherwise the system might be damaged. Contact an Abarth Dealership as soon as possible to have the system repaired. AUX and USB SOURCE To connect an external device, use the AUX input fig.
Page 183: Uconnect™ 5" Live / Nav Live
Uconnect™ 5” LIVE / Nav LIVE Controls on front panel AB0A0367C...
Page 184 Front control panel summary table Button Functions Mode Ignition Short button press Switching off Short button press Volume adjustment Left/right rotation of knob Volume activation/deactivation (Mute/Pause) Short button press Display on/off Short button press Exit the selection/return to previous screen Short button press Settings Short button press...
Page 185 Controls on the steering wheel The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below.
Page 186 Controls on steering wheel summary table Button Interaction (pressure/rotation) Acceptance of incoming call; Answering the second incoming call and putting the active call on hold; Display of the last 10 calls on the instrument panel Rejection of incoming call; Ending of call in progress;...
Page 187 Switching the system NOTE The DAB frequency can be used For languages not supported by on/off in countries where digital transmission the system which feature special The system is switched on/off by technology is available. The device will characters (e.g. Greek), the keyboard pressing the (ON/OFF) button/knob.
Page 188 priority is determined according to the audio for private conversations. The during the pairing stage a screen order of connection. The last device mobile phone audio is transmitted appears on the display showing the connected will have the highest priority; through the car’s sound system;...
Page 189 pressing the "Redial" graphic button. WARNING Some mobile phones may See you later. not take the SMS delivery confirmation I will be 5 (or 10, 15, 20, 25, 30, 45, Text Message Reader settings into account when interfacing 60)* minutes late. The system can read the messages with Uconnect™.
Page 190 more efficient and evolved use of by pressing the Uconnect™ LIVE you will be informed with a message on the car, directly from the radio. The the radio screen. icon on the radio. When the activation application functions are present process is complete, a message The update includes a download of the according to the vehicle configuration...
Page 191 The my:Car app was developed or markets, where provided even if my:Car present in the radio. to improve the customer's driving my:Car allows you to keep the experience, therefore they are available condition of your car always under eco:Drive™ display in all markets where the Uconnect™...
Page 192 Audio; map. Tap “Select” to continue or tap NOTE: the use of a memory stick Phone / Bluetooth®; “Back” to enter another address; is recommended, while the use of SiriusXM Setup (where provided); when the new route is shown, tap mass storage devices, such as mobile Radio Setup;...
Page 193 "Download TomTom HOME", then Connect the USB device to the process, otherwise installation will be interrupted. follow the instructions provided. computer. Connect the USB device prepared Downloading a map with the computer. TomTom HOME is Insert the USB device containing the If a map update is available for the started automatically.
Page 194 The version of the map on the USB Show recent calls Navigation (Uconnect™ 5" Nav LIVE only) device is the same as or is a previous Show outgoing calls The following voice commands can be version of the one already on the Show missed calls given after pressing the button on the system.
Page 195: Uconnect™ 7" Hd Live - Uconnect™ 7" Hd Nav Live
UCONNECT™ 7” HD LIVE - UCONNECT™ 7” HD NAV LIVE Controls on front panel AB0A0399C...
Page 196 Front control panel summary table Button Functions Mode Ignition Short button press Switching off Short button press Volume adjustment Left/right rotation of knob Volume activation/deactivation (Mute/Pause) Short button press Display on/off Short button press Exit the selection/return to previous screen Short button press Scrolling the list or tuning to a radio station Left/right rotation of knob...
Page 197 Summary table of display buttons Button Functions Mode Radio Access to the Radio mode Press button Media Source selection: USB, AUX, Bluetooth® Press button Phone Phone data display Press button Access the additional functions (e.g. Compass display, Uconnect™ Press button Uconnect™...
Page 198 Controls on the steering wheel The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below.
Page 199 Controls on steering wheel summary table Buttons Interaction Acceptance of incoming call Answering the second incoming call and putting the active call on hold Display of the last 10 calls on the instrument panel Activation of voice recognition Interruption of the voice message in order to give a new voice command Interruption of voice recognition Rejection of incoming call Ending of call in progress...
Page 200 Switching the system Media mode At the bottom: display of the following on/off buttons: Press the "Media" button to select the The system is switched on/off by "Browse": list of the radio stations desired audio source among those pressing the button/knob available;...
Page 201 "Tracks": list of available tracks. NOTE The "Tracks" button does not system display or confirm on the device the PIN displayed; “Map": navigation map view (versions allow any operation on the AUX device. with Uconnect™ 7" HD Nav LIVE if the pairing procedure is completed NOTE The indexing time of a USB successfully, a screen is displayed.
Page 202 previous system pairing also from the the front panel or on the steering display and call the contacts in the list of Bluetooth® devices on the wheel. phonebook of the mobile phone; phone and make a new pairing. display and call contacts from the registers of previous calls;...
Page 203 if no phone is paired with the system MAKING A PHONE CALL received by the mobile phone (the list yet, the display shows a dedicated displays a maximum of 60 messages The operations described below can screen; received). only be accessed if supported by the access "Settings"...
Page 204 The Abarth Telemetry application the radio, as described in the "Pairing a more. unlocks the potential of the new Abarth mobile phone" paragraph, to access 595/695. The objective is to create APPS MODE the Uconnect™ LIVE services in your driving confidence and make drivers Press the “Uconnect”...
Page 205 their performance on the smartphone Timer create a customised itinerary that may thanks to the Uconnect™ LIVE App be reused by the user in the future. and, if they wish to give their consent, Settings to share their performance with the Through the settings, users can select Uconnect™...
Page 206 port and the contents of the phone system navigation and using navigation Before using Apple CarPlay, enable Siri will be automatically shown on the controlled by the smartphone. from Settings > General > Siri on the Uconnect™ system display. smartphone. To use Apple CarPlay, the The user can choose to change their smartphone must be connected to the To check the compatibility...
Page 207 Exiting from the Apple CarPlay and Engine Off Options; information on the weather or warnings Android Auto apps about speed camera locations. Audio; You can still access the contents of the Phone; NOTE The "Weather" and "Report Uconnect™ system with the CarPlay Radio Setup;...
Page 208 Call back you can deactivate the warning sounds system can also be updated at the Show recent calls by selecting “Settings”, then “Sounds Abarth Dealership (the dealer may Show outgoing calls and warnings”. charge for updating the navigation Show missed calls system).
Page 209: Mopar® Connect
Navigate to “address” 171) Where provided, the my:Car™ app Abarth website. is not intended to replace the Owner Go to "city name" centre Some of the packages made available Handbook of the car.
Page 210 Proceed as follows: Download the Uconnect™ LIVE the Abarth Dealership or contact take note of the total odometer app for smartphones or access the Customer Care. reading; www.driveuconnect.eu portal to use make sure that the instrument panel the connected services.
Page 211: Official Type Approvals
OFFICIAL TYPE APPROVALS Radio devices All radio equipment provided with the car complies with Directive 2014/53/EU, UA.RED.TR, the French SAR Decree Law of 15/11/2019 and the UKCA (UK Conformity Assessed) Certification of 01/01/2021 in force in the United Kingdom. For further information visit the www.mopar.eu/owner or http://aftersales.fiat.com/elum/ websites...
Page 212: Right Hand Drive Version
RIGHT HAND DRIVE VERSION DASHBOARD AB0A0391C 1. Adjustable air vents 2. Fixed air vents 3. Left stalk: direction indicators, dipped beam headlights, main beam headlights, Lane change function 4. Turbo pressure gauge, “SPORT” display 5. Instrument panel 6. Right stalk: windscreen washer/wiper, rear window washer/wiper 7.
Page 213: Instrument Panel Features
INSTRUMENT PANEL FEATURES AB0A0475 1. Odometer (display of distance travelled in kilometres/miles) 2. Digital engine coolant temperature gauge 3. Digital rev counter (tachometer) 4. Range 5. SBR system indications 6. Outside temperature gauge 7. Car speed indication 8. Schedule 9. Current Consumption 10.
Page 214 AB0A0476 1. Digital engine coolant temperature gauge 2. Digital rev counter (tachometer) 3. Engaged gear indicator 4. Car speed indication 5. Maximum engine rpm reached (“Ghost function”) 6. Digital fuel level gauge 7. SBR system indications 8. Longitudinal/lateral instantaneous acceleration 9. Odometer (display of distance travelled in kilometres/miles) 10. Front headlight aiming 11.
Page 218 MAINTAIN YOUR VEHICLE IN TIP TOP CONDITIONS WITH Mopar Vehicle Protection offers a series of service contracts that are designed to give all our customers the pleasure of driving their vehicle without any hitch's and concerns. Our product portfolio consists of a wide and flexible range of extended warranty and maintenance plans endorsed by FCA.
Page 219 NOTES...
Page 222 CONTENTS plastic parts ... . . 145 Dualdrive electric power steering ....99 seats ....145 nalogue pressure gauge .
Page 223 Glove compartment ... 38 Light bulbs ear light clusters (bulb bulb types ....107 replacement) ... . . 110 andbrake .
Page 224 Sensors mechanical key ... . 11 Uconnect™ 5”/7” HD parking ....101 Third brake light (bulb AUX and USB source .
Page 225 Wheels and tyres ... . 139 tyre inflation pressure ..155 When parked ....95 Window bags (side airbags for head protection) .

This manual is also suitable for:

695

Abarth 595 Owner's Manual

Getting to Know Your Car

Knowing the Instrument Panel

Safety

Starting and Driving

In an Emergency

Servicing and Maintenance

Technical Specifications

Multimedia

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Abarth 595

Summary of Contents for Abarth 595

This manual is also suitable for:

Table of Contents
