Evektor SportStar RTC Maintenance Manual

Hide thumbs Also See for SportStar RTC:

Advertisement

Quick Links

TECHNICAL CONTENT OF THIS DOCUMENT IS APPROVED ON
THE BASIS OF AUTHORIZATION DOA NO. EASA.21J.057.
1. CONCERNING TO:
2. REASON:
3. REQUIRED ACTIONS:
4. LATEST DAY OF THE ACTION: Immediately after receiving this bulletin.
5. CARRIED OUT BY:
6. COSTS COVERED BY:
7. NECESSARY MATERIAL:
8. WORK PROCEDURE:
9. APPENDICES:
Valid from: 12.09. 2022
QS-406/F-07I
tel: +420 572 537 605
page: 1/1
SERVICE BULLETIN No. RTC-038a R3
THIS SB COULD BE AFFECTED BY AD.
All airplanes SPORTSTAR RTC
Issue of Revision 3 of Airplane Maintenance Manual for
SportStar RTC Issue 02, Doc. No. ERTC022-10-AS.
Owner / operator will insert changed pages (enclosed to this
bulletin) into the AMM.
Owner/operator of the airplane.
Owner/operator of the airplane.
Changed pages of the AMM are enclosed to this bulletin.
Insert changed pages, marked with Rev. 3, which are enclosed
to this bulletin, into AMM, write down date of pages insertion
and put the signature into the LoR on page 01-41.
Changed pages to the AMM doc. No. ERTC022-10-AS,
Revision 3, dated 2022-09-12.
fax: +420 572 537 901
Letecká 1008, 686 04 Kunovice, Czech Republic
issues
e-mail:
evektor@evektor.cz
https://www.evektor.cz
