TREND TCH/AT/B75R Quick Start Manual

Rechargeable
Angle Twist
Torch
TCH/AT/B75R
INST/TCH/AT/B75R v1.0
ANGLE TWIST TORCH
REF. TCH/AT/B75R
Thank you for purchasing this Trend product,
which should give lasting performance if used
in accordance with these instructions.
Denotes risk of personal injury, loss
of life or damage to the tool in case of
non-observance of the instructions.
INTENDED USE
This accessory is intended to be used as a
torch only. The torch has Low, High and UV
light functions.
SAFETY
Read and understand the instruction sheet
carefully before using. This is a sensitive
precision tool. Do not disassemble or drop it.
Please note the magnets in the base. Store out
of reach of children. Do not use as a toy or as
a weapon.
PLEASE KEEP THESE INSTRUCTIONS IN
A SAFE PLACE.
Users must be competent in using woodworking
equipment before using our products. Consider
working environment before using tools. Ensure
working position is comfortable and component
is clamped securely. Please keep children and
visitors away from tools and work area. All
tools have a residual risk so must therefore be
handled with caution.
CE DECLARATION CONFORMITY
This product conforms with EMC
Directive 2014/30/EU.
OPERATION
Remove battery safety tab before use.
Mode 1 Short press: Low – High – Off
Mode 2 Long press: UV – Off – Mode 1
When the torch is off or on Mode 1, long press
the button to turn to Mode 2.
The switch indicator will show green if battery
is more than 3.3V and it will show red if battery
falls below 3.0-3.3V.
If the battery is less than 3V, the indicator will
turn red and flash for 2 minutes until it goes out.
Remove battery safety tab before use.
Charging
The battery has a safety tab fitted for transit,
this must be removed before use. To charge
battery use supplied USB cable to connect
with USB socket adaptor (not supplied).
The switch indicator will show red, which
means it is charging and will turn to green
when fully charged. Battery charge time can
take 6 to 8 hours.
Micro USB port
Micro
USB
GUARANTEE
All Trend products are guaranteed against
any defects in either workmanship or material,
except products that have been damaged due
to improper use or maintenance.
