Reznor CL31 Installation

RELAY KIT INSTALLATION FOR MULTIPLE HEATER CONTROL
• DO NOT use these multiple heater control options with a two-stage gas valve or a two-stage
thermostat.
• These instructions are designed to assist a qualified electrician in installing this multiple heater
control kit.
• All electrical wiring and connections, including electrical grounding, MUST be in accordance with
the National Electric Code ANSI/NFPA No. 70 (latest edition) or, in Canada, with the Canadian
Electrical Code, Part 1, CSA Standard C22.1. In addition, the installation must comply with local
ordinances and applicable gas company requirements.
• These relay kits are designed to permit the control of up to six heaters (one control unit and up to five additional non-
control units) with one single-stage thermostat or with a time clock and single or multiple single-stage thermostats.
For maximum safety, the multiple control is installed in the low voltage circuit. Interruption of the supply voltage
is not recommended.
• Refer to the installation manual provided with the heater for important safety information.
• Pay attention to all dangers, warnings, cautions, and notes highlighted in this manual. Safety markings should not
be ignored and are used frequently throughout to designate a degree or level of seriousness.
• Model/option/voltage applicability is listed in
Table 2
components listed in
Voltage/Phase
208/1, 230/1
*
Except as follows: unit size 400 can have five (5) additional non-control units, unit size 800 can have three (3) additional non-control units,
and unit size 1200 can have two (2) additional non-control units.
*
Item No. Component
— Option package PN
1 Relay assembly
1A Relay
2 Screw
3 Label
*
See Figure 1.
**
Option CL31 includes components for one control unit and one additional unit. Option CL32 includes components for each additional non-
control unit.
***
Consists of a relay plug, 24VAC, DPDT (PN 211411) and a relay socket (PN 211415) with wires (all with terminals): 42-inch red, 42-inch
white, 6-inch blue, and 6-inch brown. If replacing a previously-used relay only (PN 98118), order kit (PN 263527) to replace.
Install the relay kit as follows. Item numbers refer to
1. Turn OFF gas and electric power.
2. Install relay assembly on control unit and on all non-control units (see
a. Remove access panel from main heat section.
b. Position relay assembly (1 and 1A) on control panel and secure using screws (2).
OPTIONS CL31 AND CL32 FOR MODEL LDAP
⚠ CAUTION ⚠
Table 1
are available before beginning installation.
Table 1. Model/Voltage/Option Applicability
Option for
Control Unit
CL31
Table 2. Relay Kit Components
Description
***
Assembly
With wires and wire terminals
#8-18 × 1/2, for securing relay bracket
Wiring diagram

INSTALLATION

Revision: LDAP-CL31,32 (06-22) 1041278-A
Supersedes: LDAP-CL31,32 (04-22) 1041278-0
and kit components are listed in
Option for
Non-Control Unit(s)
CL32
1041280 (1)
208365 (2)
18549 (2)
38529 (4)
208185 (2)
Table 2.
Figure
Table 2. Ensure that all
No. of Non-Control
Units Permitted
*
4
**
Option
CL31 CL32
PN (Quantity)
1041286 (1)
208365 (1)
18549 (1)
38529 (2)
208185 (1)
1):
