Hammerhead HLCL001 Manual

Compact self leveling cross line laser with integrated tripod leg
Hide thumbs

Advertisement

Quick Links

COMPACT SELF-
LEVELING CROSS
LINE LASER
WITH INTEGRATED
TRIPOD LEG
MODEL HLCL001
ATTACH YOUR RECEIPT HERE
Serial Number ______________________ Purchase Date _______________________
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-877-888-1880, 8:30 a.m. – 8:00 p.m.
EST (Monday – Friday) & 10:00 a.m. – 6:00 p.m. EST (Saturday and Sunday).

Advertisement

loading
Need help?

Need help?

Do you have a question about the HLCL001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hammerhead HLCL001

Summary of Contents for Hammerhead HLCL001

  • Page 1 LEVELING CROSS LINE LASER WITH INTEGRATED TRIPOD LEG MODEL HLCL001 ATTACH YOUR RECEIPT HERE Serial Number ______________________ Purchase Date _______________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-888-1880, 8:30 a.m. – 8:00 p.m.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Technical Specifications ......... . . 2 Safety Instructions .

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Safety Instructions for Compact Self-Leveling Cross Line Laser WARNING LASER RADIATION. Do not stare into beam. Class II laser product. Turn the laser beam on only when CAUTION using this tool. LASER RADIATION - DO NOT STARE INTO BEAM •...
  • Page 4 SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS DANGER TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference.

  • Page 5: Unpacking

    SAFETY INSTRUCTIONS DANGER People with electronic devices, such as pacemakers, should consult their physician(s) before using this product. Operation of electrical equipment in close proximity to a heart pacemaker could cause interference or failure of the pacemaker. UNPACKING When unpacking the box, do not discard any packing materials until all of the contents are accounted for: a.

  • Page 6: Description

    DESCRIPTION KNOW YOUR SELF-LEVELING CROSS LASER This self-leveling cross laser is highly versatile. It can be hand-held or leveled on a horizontal surface. OPEN LOCKED PARTS DESCRIPTION Power switch Laser aperture Leveling mode selection ring Folding legs Battery compartment COMPACT SELF-LEVELING CROSS LINE LASER WITH INTEGRATED TRIPOD LEG...

  • Page 7: Operation

    OPERATION 1. TO INSTALL BATTERIES The battery compartment holds one LATCH “AA” battery. a. Depress the latch to open the battery cover. b. Insert one new “AA” alkaline battery, following the polarity (+/-) as indicated on the pole plate. c. Securely close the cover. NOTE: •...
  • Page 8 OPERATION 2. TO TURN THE COMPACT POWER SELF-LEVELING CROSS LINE SWITCH LASER ON AND OFF The power switch is located on the top of the tool. a. To turn the compact self- leveling cross line laser on, depress the power switch. WARNING When turning on the compact self- leveling cross line laser, always be aware of protecting your eyes and the eyes...
  • Page 9 OPERATION 3. SELF-LEVELING MODE Your compact self-leveling cross line laser has two working modes: self-leveling mode and lock mode. In self-leveling mode, the tool will level itself if it is within ±4° of horizontal. INDICATOR a. Place the compact self- leveling cross line laser on a flat, smooth surface that is within ±4°...
  • Page 10 OPERATION 4. LOCK MODE This mode cannot be used to perform horizontal or vertical leveling, because the laser lines are no longer self leveling. a. To choose the lock mode, rotate the leveling mode ring until the indicator aligns with “ ”...
  • Page 11 OPERATION c. Unfold the three legs of cross line laser, align the raised parts on the cross line laser with the notches in the base, insert the cross line laser into the base. There is a magnetic block at the bottom of the cross line laser, and a metal block inside the base, they will help to strengthen the connection, Now the cross line laser and the rotational table of the base are combined together.

  • Page 12: Maintenance

    MAINTENANCE This compact self-leveling cross line laser has been designed to be a low- maintenance tool. However, in order to maintain its performance, you must always follow these simple directions: a. Avoid exposing the tool to shock, continuous vibration or extreme hot or cold temperature.

  • Page 13: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION The laser line Battery is weak. Replace with a new projection is weak. battery. The laser line is hard The tool is too far from the Move the tool closer to to see. target. the target. No battery installed or Install a new battery.

  • Page 14: Warranty

    WARRANTY This compact self-leveling cross line laser is warranted to the original purchaser from the original purchase date for 24 Months, Hammerhead consumer laser models will be free from defects in material or workmanship for a period of ninety days if the tool is used for professional use. Please retain your receipt.
