  • Page 1 A PPL IANC E S FOR LIV IN G OPERATION MANUAL GAS COOKTOPS MODELS XFFD AGH XFFD AGH XFFD XFFD AGH XFFD AGH XFFD X AGH MB AGH XFFD AGH XFFD XFFD AGH XFFD AGH MB.
  • Page 2 ARTUSI Family. This instruction manual has been specially created to inform you of the full range of features your ARTUSI appliance has to offer and serves as an introduction to getting the very best out of your ARTUSI appliance.
  • Page 3: Table Of Contents

    Instructions for use Installation Abnormal Operation Installation Diagrams Use of Electric Elements Maintenance Instructions for the installer Gas Connection Electrical connection User characteristics Warranty Rev.13052022...
  • Page 4: Instructions For Use

    INSTRUCTIONS FOR USE INSTALLATION All the operations concerned with the installation (electrical and gas connections, adaptation to type of gas, necessary adjustments, etc.) must be carried out by authorised personnel, in terms with the standards in force. Kindly read the part titled, Instructions for the installer.
  • Page 5 COOKING USE OF COOKWEAR Warning: To ensure a safe working distance is maintained between the control knobs and the pot, it is recommended that large pots are not used on the central, front burner of the 6 burner model. Always centralise pots over the burners and check that the pot is not too close to the control knobs.
  • Page 6: Installation Diagrams

    * all measurements are in millimetres ** minimum distance to combustible splashback * Distance is the minimum clearance from the top of the benchtop to any overhead surface. 170** Fig. 3 ** The height of the top of the pan support with respect to the bench top surface is 48mm Rev.13052022...
  • Page 7 1 2 3 4 1 2 3 4 5 1 2 3 4 5 Rev.13052022...
  • Page 8 ** minimum distance to combustible splashback * Distance is the minimum clearance from the top of the benchtop to any overhead surface. 170** ** The height of the top of the pan support with respect to the bench top surface is 48mm Fig.
  • Page 9 1 2 3 4 Rev.13052022...
  • Page 10 ** minimum distance to combustible splashback * Distance is the minimum clearance from the top of the benchtop to any overhead surface. 170** ** The height of the top of the pan support with respect to the bench top surface is 48mm Rev.13052022...
  • Page 11 ** minimum distance to combustible splashback 30 mm. 170** 40 mm. * Distance is the minimum clearance from the top of the benchtop to any overhead surface. ** The height of the top of the pan support with respect to the bench top surface is 48mm Rev.13052022...
  • Page 12 Fig. 3 Rev.13052022...
  • Page 13 1 2 3 4 5 6 1 2 3 4 5 6 ** minimum distance to combustible splashback * Distance is the minimum clearance from the top of the benchtop to any overhead surface. 170** ** The height of the top of the pan support with respect to the bench top surface is 48mm Rev.13052022...
  • Page 14: Use Of Electric Elements

    USE OF ELECTRICAL PLATES/VITRO CERAMIC HEATING ELEMENTS COMMUTATOR ENERGY HEAT COOKING METHODS REGULATOR INTENSITY 1 - 2 slight melting of fats etc.; heat small quantities of liquid 3 - 4 mild heating of medium quantities of liquid; puddings, long-cooking sauces 5 - 6 slow defrosting - heat large quantities of liquid;...
  • Page 15: Instructions For The Installer

    INSTRUCTIONS FOR THE INSTALLER This appliance shall be installed only by authorised persons and in accordance with the manufacturers installation instructions, local gas fitting regulations, municipal building codes, electrical wiring regulations, local water supply regulations, AS 5601 - Gas Installations and any other statutory regulations. Not for use in marine craft, caravans or mobile homes unless each burner is fitted with flame failure safeguard.
  • Page 16: Gas Connection

    GAS CONNECTION (Fig. 5) Connect the appliance to the gas cylinder or to the installation according to the prescribed standards in force, and ensure beforehand, that the appliance matches the type of gas available. Otherwise, see “Adaptation to various types of gas”. Furthermore, check that the feed pressure falls within the values described on the table “User characteristics”.
  • Page 17: User Characteristics

    USER CHARACTERISTICS GAS BURNERS GAS TYPE PRESSURE (kPa) BURNER Ø INJECTORS 1/100 mm NOMINAL GAS CONSUMPTION (MJ/h) Natural Gas 1.00 Auxiliary 0.92 Semi-Rapid 1.17 Rapid 1.55 11.7 Mini Wok 1.50 10.7 1.63 12.5 Universal LPG 2.75 Auxiliary 0.56 Semi-Rapid 0.70 Rapid 0.94 0.90...
  • Page 18: Warranty

    A.B.N. 45868077422 2. What is not Covered by the Warranty. Distributed by Eurolinx pty Ltd The Warranty does not apply if an artusi product Office: is defective by a factor other than a defect arising in the manufacture of the artusi product, including 48-50 Moore Street, Leichhardt N.S.W 2040...
  • Page 19 Warranty Registration Card. 8. Defects 7. Statutory Rights Any part of an artusi product deemed to be (a) These terms and conditions do not aff ect your defective and replaced by Worldwide Appliances statutory rights. is the property of Worldwide Appliances.
