VORAGO ESB-600 PLUS - Sport Bluetooth Earbuds Manual

KNOW YOUR DEVICE

KNOW YOUR DEVICE - Overview

N o Descripcion
1 LED
2 Touch button
3 Microphone
4 Charging connector
5 Case cover
6 LED charge indicator
7 Micro USB charging port

FUNCTION OPERATION-USE ONE EARBUD

Function Status Left Rigth
Play Pause Double-click touch-button Double-click touch-button
Pause Playing music Double-click touch-button Double-click touch-button
Previous song Playing music Press Left touch - button about 2s N/A
Next song Playing music N/A Press Right touch - button about 2s
Volume up Playing music N/A Once-click Right touch-button
Volume down Playing music Once-click Left touch-button N/A
Cancel calling Calling Once click touch button Once click touch button
Answering Incoming call ringing Once click touch button Once click touch button
Reject Incoming call ringing Press touch button about 2 s Press touch button about 2 s
End calling During a call Double click touch button Double click touch button
Voice switch to phone During a call Press touch button about 2 s Press touch button about 2 s
Voice switch to earbuds During a call Press touch button about 2 s Press touch button about 2 s
Active SIRI Connected device N/A Triple click en botón touch
Volumen + During a call N/A Once click touch button
Volumen - During a call Once click touch button N/A

TECHNICAL SPECIFICATIONS

Frequency range: 20 Hz - 20 KHz
Sensitivity: 105 ± 3dB (at 1 KHz)
Sensitivity (dB) (mic): -38dB ± 3dB
Bluetooth version 5.0 QCC3020
Range: 10 meter
Weight: 13 g
Battery: Li-Polymer earbud battery (3.7 V 70 mAh * 2)
Case battery: 740mAh

EARBUDS PAIRING/CONNECTING

Please use this step if two headset can not be connect with each other.

  1. Turn off two earbuds respectively(don't put them into the charging case).
  2. Clear the pairing list: Choose one of the earbuds. Firstly, enter the pairing mode. Then hit the touch button 5 times, while the red LED and the white LED turns on for 1 second. The pairing list will be cleared when emits prompt tone. The other headset cleans the pairing list by doing the same.

The earbuds will enter TWS pairing mode automatically when they are turned on (indicator light status: red and white lights flash slowly).After successful connection, the primary earbud(L) will emits "Pairing" after a "dang" prompt, which indicator light status will be: red LED and white LED flash alternately(it keeps waiting to be paired with your phone), while the secondary earbud(R) will emits 'Dang' and indicator status will be: white LED flash twice time every 5 seconds.

Remarks:
In normally the two earbuds will connect automatically once you have taken out of the charging case, which set in factory. You can connect the two earbuds according above operation if they failed connecting.

  1. Auto power off once put into charging case
  2. Press touch-button about 5s and release it till red LED is on, and earbuds prompt "Power off".

Remark:
When the earbuds are idle and not connected to the Bluetooth device, they will turn off automatically after 5 minutes to save power. The pairing mode will last for 2 minutes. If the earbuds are not paired with any Bluetooth devices after 2 minutes, the earbuds will enter standby mode and turn off automatically after the standby mode lasts for 3 minutes.

  1. Two earbuds connecting with cellphone In this mode use two earbuds at the same time to enjoy stereo sound.

Two earbuds connecting with cellphone

POWER ON

  1. When charging, the earbuds will turn on automatically when they are taken out of the charging case.
  2. If the earbuds are power off, you should press touch-button for about 3s until white LED flashes as the same time the earbuds emits "Power on". Then release. This is now in the "Power on"state.

PAIRING

  1. After the earbud is taken out of the charging case, it will be power on. Then it will connect back to the phone you paired with before. When the earbuds and the cellphone fails to connect back, the earbuds will automatically enter the matching state.
  2. If the earbuds are power off, you should press touch-button for about 8s and release it when the red LED and white LED flash quickly and alternately. You will hear "Pairing". The earbuds are in "Pairing"mode

The earbuds prompts "Phone is connected".
You need to connect one of them to use as primary. However, if you want to use them singly, only connect the desired ear L or R, and turn off another one.

When Left earbud is successfully paired with the phone, the phone will Pop-up a dialog: "Headset would like to pair with your phone". If you click "pair", the secondary earbud will also be paired with the phone. And primary-secondary switching function can be OK. If it is not confirmed at this time, Left earbud and Right earbud cannot switch subsequently.
POWER OFF

USING USB CABLE

  1. Plug the Micro USB charging cable into the case's charging jack.
  2. Plug the USB cable into a USB port of PC or a 5Volt USB charge.

Charging

REMARKS:

  1. Batteries (battery pack or batteries installed) shall not be exposed to excessive heat place, such as sunshine, fire or the like.
  2. Please make sure the charging jack is dry before charge.

USE OF HEADPHONES

  1. Wearing headset
    1. Choose the suitable size ear tips
    2. Ensure each earbuds is worn on the correct ear. "L" should be worn on the left ear and "R"worn on the right ear.

CHARGING FOR HEADSET

When the headset is low on power, it emits "Battery low" once every 2 minutes and the red Led flashes slowly 4 times in a row every 1 minute. Please recharge the battery of the headset.

The way of charging for the earbuds as following:

  1. Put the earbuds into the charging case to ensure that the charging pins connect well, and start charging when you see the red indicator light of the earbuds on. Red light on: Charging Red light off: Finish charging
  2. Charging should be completed in roughly 1.5 hours.

White LED flashes once every 2 seconds = low battery power;
White LED flashes three times every 2 seconds = sufficient battery power;
White LED remains on = full battery power;
After removing the earbuds from the charging case, the indicator LED of the charging case will automatically extinguish after 1 minute.

CHARGING FOR CHARGING CASE

When any of the following situations occurs, it indicates that the charging case will be low power. You need to charge the charging case:

  1. Put the earbuds into the charging case, and find that the white indicator light of the charging case flashes once every 2 seconds. It means that the charge case is low power.
  2. When the indicator light of the charging case doesn't turn on and the earphonecannot be charged, it means that the battery of the charging case has been used up.
