GAS AND POWER SUPPLY INSTALLATION LOCATIONS

OVEN INSTALLATION

NOTE: Prior to performing installation, wear safety gloves and glasses.
Complete the following steps when the cabinet has been prepared according to the dimensions given and the gas line
and electrical connections are in place.
1. OVEN PREPARATION
Take your range oven out of the carton and place
on a flat surface. Remove the packing materials.
Lift up and remove grate from cooktop.
Remove the 4 screws on the cooktop with a
Phillips screwdriver, then lift up on the cooktop to
remove.
Installation Instructions
Power Supply
Connection
Remove Grate
4 Screws
Propane Supply
Line Connection
27°
WARNING
Doing so may result in fire or explosion hazard.
Lift the range oven by the side handles and set
into the cabinet opening. Slide range oven back
until the front cavity flanges contact the cabinet
face.
49-2001047 Rev. 4
