- Page 1 Femtowatt Photoreceiver PDF10A2 Operation Manual 2020...
- Page 2 Version: Date: 10-Mar-2020 Copyright © 2020 Thorlabs...
-
Page 3: Table Of Contents
5.3 Typical Frequency Response 5.4 Typical Spectral Noise 5.5 Typical Output Time Response 5.6 Drawings 5.7 Safety 5.8 Return of Devices 5.9 Manufacturer Address 5.10 Certifications and Compliances 5.11 Warranty 5.12 Exclusion of Reliability and Copyright 5.13 Thorlabs Worldwide Contacts and WEEE poilicy... - Page 4 Paragraphs preceded by this symbol explain hazards that could damage the instrument and the connected equipment or may cause loss of data. Note This manual also contains "NOTES" and "HINTS" written in this form. Please read this advice carefully! © 2020 Thorlabs...
-
Page 5: General Information
· PDA-C-72 DC power supply cable to PDF10A2: This cable has a connector on one end and open wires at the other. The pin-out of the PDF10A2 DC power jack is shown in the pendix Please visit our homepage http://www.thorlabs.com for various accessories like fiber adapters, posts and post holders, data sheets and further information. -
Page 6: Getting Started
If the shipping container seems to be damaged, keep it until you have inspected the contents mechanically and electrically. Verify that you have received the following items within the package: 1. PDF10A2 Amplified Photodetector Plastic Cover Cap (Item # SM1EC2B) on... -
Page 7: Operating Instruction
PDF10A2 3.2 Mounting Housing The PDF10A2 is housed in a rugged, shielded, 70.9 mm x 49.9 mm x 22.5 mm aluminum en- closure. Mounting PDF10A2 on an Optical Table Mount the PDF10A2 on an optical post by using either of the two tapped mounting holes on the side and bottom. -
Page 8: Operation
(Hi-Z) loads. · Switch on the power supply. · Switch on the PDF10A2 by moving the power slider to I while the optical input is protected by the cover cap. · The maximum OUTPUT voltage swing is ±10 V for high impedance loads (>10 kW). The OUTPUT signal should stay below this maximum output voltage to avoid amplifier saturation. -
Page 9: Recommendations
LED far away from the PDF10A2 can affect power measurements at femtowatt levels. o It is not necessary to switch off the PDF10A2 when it is exposed to ambient light. The amp- lifier will saturate but, unlike photomultiplier tubes, it will not be damaged or saturated for a long period of time. -
Page 10: Operating Principle
(1.1 mm x 1.1 mm). Due to this small active area of the PDF10A2 photodiodes, it is recommended to focus the op- tical signal out of the fiber onto the detector. Because the housing is compatible with any number of Thorlabs 1” and ½” threaded accessor- ies, external optics, filters or apertures can be easily attached to the PDF10A2. -
Page 11: Maintenance And Service
Do not open the power supply unit! Cleaning To clean the PDF10A2 housing, use a mild detergent and damp cloth. Do not soak the unit in water or use solvent based cleaners. When cleaning the window of the photodetector, please remember that is a sensitive optical device. -
Page 12: Appendix
70.9 mm x 49.9 mm x 22.5 mm Power Supply ±12V, 250 mA Operating Temperature Range 10°C to 50°C Storage Temperature Range -25°C to 70°C All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity ) non condensing © 2020 Thorlabs... -
Page 13: Typical Responsivity
5.3 Typical Frequency Response For the measurement of the frequency response, a test signal was fed through an optical chop- per and fiber-coupled to the PDF10A2 input. The output voltage amplitude was measured with an oscilloscope. PDF10A2 Typical Frequency Response... -
Page 14: Typical Spectral Noise
PDF10A2 5.4 Typical Spectral Noise Noise is being characterized by different specifications. The spectral noise of PDF10A2 was measured using a 200 kSample/s A/D converter. The power density spectrum was calculated from the sampled values with respect to transimpedance gain and detector responsivity. The optical input of the PDF10A2 was blocked. -
Page 15: Drawings
All statements regarding safety of operation and technical data in this instruction manual will only apply when the unit is operated correctly as it was designed for. The PDF10A2 must not be operated in explosion endangered environments. Do not remove covers. There are no user-serviceable parts inside. -
Page 16: Return Of Devices
Thorlabs. Attention Prior to applying power to the PDF10A2, make sure that the protective conductor of the 3 con- ductor mains power cord is correctly connected to the protective earth ground contact of the socket outlet! Improper grounding can cause electric shock resulting in damage to your health... -
Page 17: Certifications And Compliances
5 Appendix 5.10 Certifications and Compliances © 2020 Thorlabs... -
Page 18: Warranty
Thorlabs warrants material and production of the PDF10A2 for a period of 24 months starting with the date of shipment. During this warranty period Thorlabs will see to defaults by repair or by exchange if these are entitled to warranty. -
Page 19: Thorlabs Worldwide Contacts And Weee Poilicy
Contact Thorlabs for more information. Waste treat- ment is your own responsibility. “End of life” units must be returned to Thorlabs or handed to a company specializing in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site. - Page 20 www.thorlabs.com...
