- Page 1 MULTI-CHANNEL LOW NOISE AMPLIFICATION SYSTEM CMP60116-1/2 INSTRUCTION MANUAL...
- Page 2 DA00073361-001 MULTI-CHANNEL LOW NOISE AMPLIFICATION SYSTEM CMP60116-1/2 INSTRUCTION MANUAL...
- Page 3 ――― Preface ――― Thank you for purchasing the “MULTI-CHANNEL LOW NOISE AMPLIFICATION SYSTEM CMP60116-1/2”. For safe and correct use of this product, please read the “Safety Precautions” section that follows before attempting to use the instrument. ●Marks and symbols For safe operation by the use and to prevent damage to the instrument, prelase give attention to the following marks and symbols that are used in this manual.
-
Page 4: Safety Precautions
NF Corporation or one of our representatives. ● If lightning occures, power off and disconnect this product. A lightning may cause an electric shockm a fire and a failure. CMP60116-1/2... - Page 5 ● Disposal of this product a) Use the servies of an industrial waste disposal contractor for disposal of the entire product. b) This product does not include batteries. c) This product does not include mercury. CMP60116-1/2...
-
Page 6: Table Of Contents
Input ....................... 5-2 5.2.2 Output ......................5-3 5.2.3 Amplifier ......................5-3 5.2.4 Low-pass filter ....................5-4 5.2.5 Power supply ....................5-4 CMP60116-2 ......................5-4 5.3.1 Input ....................... 5-4 5.3.2 Output ......................5-5 5.3.3 Amplifier ......................5-5 5.3.4 Low-pass filter ....................5-6 CMP60116-1/2... - Page 7 5.3.5 Power supply ....................5-6 Power Connector Pin Assignment ................ 5-6 General ........................5-7 Notes ........................5-7 External view ......................5-8 CMP60116-1/2...
- Page 8 Figure 4-4 Inverting input / output voltage waveform..........4-5 Figure 5-1 External view....................5-8 Table 2-1 List of contents ..................... 2-2 Table 4-1 Setting when checking current consumption ..........4-3 Table 5-1 Power Connector Pin Assignment ............... 5-6 CMP60116-1/2...
- Page 9 1. Outline Overview ........................ 1-2 Features ......................... 1-2 Applications ......................1-3 Circuit functions ...................... 1-3 CMP60116-1/2...
-
Page 10: Overview
THRU / LPF ( fc = 1 MHz ) Offset adjustment: Adjustable to 0 V Selection of power supply GND potential: FLOAT / EXTERNAL(Connection with the earth of the power supply) (3) Connector with excellent shielding characteristics Input and output connectors: SMA connectors CMP60116-1/2... -
Page 11: Applications
1.3 Applications Applications The CMP60116-1/2 is high gain, wide-bandwidth, and low noise. It is widely used for amplification of small signals. (1) Preamplifier for the magnetic flux measurement by SQUID sensor, etc. (2) Preamplifier for small voltage after voltage conversion of SEM, etc. -
Page 12: Preparation Before Use
2. Preparation before Use Checking before use ....................2-2 Conditions for installation location ................. 2-3 Power supply ......................2-4 2.3.1 Connecting to low noise DC power supply LP5391 ........2-5 2.3.2 Connecting to CMP60116-3 ................2-6 CMP60116-1/2... -
Page 13: Checking Before Use
Table 2-1 List of contents ● Main unit ····························································································· 1 ● Instruction manual ················································································· 1 Optional Item ● Optional items below are separately available. If required, please contact NF or one of our agents. CMP60116-1/2... -
Page 14: Conditions For Installation Location
• Locations where corrosive gases, water vapor dust, or too humid. Malfunction or a failure may occur. • Near an electromagnetic filed source, high-voltage product, or power line. Noise may increase. • Where is a lot of vibration. Noise may increase, or a malfunction may result. CMP60116-1/2... -
Page 15: Power Supply
・Supplying a voltage greater than ± 16.5 V will damage this product. ・This product does not operate by single power supply (+30 V / GND). Be sure to use a dual power supply (+15 V / GND / −15 V). CMP60116-1/2... -
Page 16: Connecting To Low Noise Dc Power Supply Lp5391
・Turn off the output switch of the power supply unit before connecting this product to the power supply unit. ・Do not plug / unplug the DC power cable while the power supply is turned on. This product may be damaged. CMP60116-1/2... -
Page 17: Connecting To Cmp60116-3
・Turn off the output switch of the power supply unit before connecting this product to the power supply unit. ・Do not plug / unplug the DC power cable while the power supply is turned on. This product may be damaged. CMP60116-1/2... -
Page 18: Figure 2-3 Connection When Driving 8 Products With Cmp60116-3
The following figure shows the connection for driving 8 units with CMP60116-3. The output of CMP60116-3 is set as ±15 V. CMP60116-3 attached DC power cable DC cable DC cable DC cable DC cable DC cable DC cable Figure 2-3 Connection when driving 8 products with CMP60116-3. CMP60116-1/2... -
Page 19: Panel Features And Basic Operations
3. Panel Features and Basic Operations Panel component names and functions ..............3-2 Input connection and installation ................3-5 Output connection ....................3-6 Turning on power and warm-up time ..............3-6 CMP60116-1/2... -
Page 20: Panel Component Names And Functions
Using a screwdriver whose tip does not match or applying excessive force may cause damage. The recommended tip size of screwdriver is 1.8 to 2.0 mm of width and 0.4 to 0.5 mm of thickness. The adjustment torque is 15 mN·m maximum. CMP60116-1/2... - Page 21 The D-SUB 9-pin connector (male) is adopted. ⑫ POWER OUTPUT Connector used to drive multiple units of this product. The D-SUB 9-pin connector (female) is adopted. Connect the POWER OUTPUT connector to the POWER INPUT connector of another product using a cable. CMP60116-1/2...
-
Page 22: Figure 3-1 Front And Rear Panel Views
3.1 Panel component names and functions ③ ⑥ ④ ⑤ ① ⑦ ② ⑧ ⑩ ⑨ ⑪ ⑫ Figure 3-1 Front and rear panel views. CMP60116-1/2... -
Page 23: Input Connection And Installation
Do not connect this product to an AC outlet, because doing so is dangerous. Attention ・The signal GND and case have the same electric potential. Caution is required when giving a potential to the case or signal GND because doing so may cause electric shock. CMP60116-1/2... -
Page 24: Output Connection
Turning on power and warm-up time This product exhibits the specified performance immediately after the power is turned on, but if you need highly accurate measurement, allows the device to warm up for at least 20 minutes before use. CMP60116-1/2... -
Page 25: Maintenance
Before maintenance ....................4-2 Dairy maintenance ....................4-2 Storage, repacking and transportation ..............4-2 Function test ......................4-3 4.4.1 Consumption Current (with No Signal) ............4-3 4.4.2 A (Non-inverting) input operation ..............4-4 −B (Inverting) input operation ................4-5 4.4.3 CMP60116-1/2... -
Page 26: Before Maintenance
・ Fill the cardboard box with a cushioning material so that the six sides of the product can be protected. ・ When making a request for transportation, inform the transport operator that the product is a precision instrument. CMP60116-1/2... -
Page 27: Function Test
If nothing is connected to the input with the settings in Table 4-1, it is normal if the current consumption is within the following range. CMP60116-1：±140 within ±20 m CMP60116-2：±180 within ±20 mA Table 4-1 Setting when checking current consumption OUTPUT Switches COUPLING INPUT SEL Position THRU CMP60116-1/2... -
Page 28: A (Non-Inverting) Input Operation
－B Divider SMA to BNC conversion adapter SMA to BNC conversion adapter Oscilloscope Figure 4-1 Connection diagram for checking non-inverting input operation. CH-1: 100mV / DIV CH-2: 10V / DIV 0.5ms/dIV Figure 4-2 Non-inverting input / output voltage waveform. CMP60116-1/2... -
Page 29: B (Inverting) Input Operation
－B SMA to BNC conversion Divider adapter SMA to BNC conversion adapter Oscilloscope Figure 4-3 Connection diagram for checking inverting input operation. CH-1: 100mV / DIV CH-2: 10V / DIV 0.5ms/DIV Figure 4-4 Inverting input / output voltage waveform. CMP60116-1/2... -
Page 30: Specifications
CMP60116-2......................5-4 5.3.1 Input ........................ 5-4 5.3.2 Output ......................5-5 5.3.3 Amplifier ......................5-5 5.3.4 Low-pass filter ....................5-6 5.3.5 Power supply ....................5-6 Power Connector Pin Assignment ................5-6 General ........................5-7 Notes ........................5-7 External view ......................5-8 CMP60116-1/2... -
Page 31: Absolute Maximum Ratings
Input connector SMA connector Input resistance 100 kΩ Input capacitance 75 pF Input coupling capacitance 1 µF When AC is selected Differential signal input voltage range Within ± 0.1 V Common-mode signal input voltage range Within ± 5 V CMP60116-1/2... -
Page 32: Output
Reference frequency is 1 kHz Low cutoff frequency(AC) 2.5 Hz Output level 2 V Reference frequency is 1 kHz Total harmonic distortion(THD) 0.006 % Output level 2 V , f=1 kHz, and sum up 5th harmonic, noise is not included CMP60116-1/2... -
Page 33: Low-Pass Filter
Input mode Differential input(A–B) / Single-ended input(A or –B) / GND Input mode selection method switches INPUT SEL Input connector SMA connector Input resistance 1 MΩ Input capacitance 50 pF Input coupling capacitance 0.1 µF When AC is selected CMP60116-1/2... -
Page 34: Output
Voltage gain frequency characteristic DC to 20 MHz Within +0.5 dB / −3.0 dB, Output level 2 V Reference frequency is 1 kHz Low cutoff frequency(AC) 2.5 Hz Output level 2 V Reference frequency is 1 kHz CMP60116-1/2... -
Page 35: Power Connector Pin Assignment
The GND connection of this product can be switched by the GND switch. 7, 8 EXTERNAL FLOAT : This product's GND and EXTERNAL potentials are isolated by 1 MΩ EXTERNAL : Connect GND and EXTERNAL potential of this product － POWER INPUT POWER OUTPUT CMP60116-1/2... -
Page 36: General
Use beyond the absolute maximum ratings and operating temperature range ∙ may load to characteristic deterioration of damage on the internal circuit. Static electricity may cause characteristic deterioration or damage. ∙ CMP60116-1/2... -
Page 37: External View
5.7 External view External view Figure 5-1 External view. CMP60116-1/2... - Page 38 WARRANTY NF Corporation certifies that this product was thoroughly tested and inspected and found to meet its published specifications when it was shipped from our factory. In the unlikely event that you experience an issue during use, please contact our company or agency of our company from which you purchased the product.
- Page 39 • We assume no responsibility for influences resulting from the operations in this manual. Copyright 2019, NF Corporation CMP60116-1/2 INSTRUCTION MANUAL NF Corporation 6-3-20, Tsunashima Higashi, Kohoku-ku, Yokohama...
