Operating & Safety Instructions

GENERAL

The 12V Jump Starter PS750Li is designed to assist with starting 12 Volt vehicles that have

discharged batteries. To ensure safe and trouble-free operation of your PS750LI you must follow the

instructions below.

DO NOT SHORT CIRCUIT OR TAMPER WITH THIS UNIT. ALWAYS OBSERVE

CORRECT POLARITY AND SYSTEM VOLTAGE WHEN CONNECTING.

Failure to do so may lead to a HAZARDOUS situation, Damage the pack or the vehicle and may

invalidate the warranty.

Remove personal items such as rings, bracelets and watches when working with a vehicle

battery.

Use PS750Li for boosting standard 12 Volt vehicle batteries only.

Switch unit off when not in use.

WARNING

Before initial use, the PS750Li must be put on charge overnight (16Hrs). Failure to do so

may reduce the life of the product and invalidate the warranty.

The state of charge is best checked 2 hours after charging. Ensure all cables are disconnected. Push

the "Push to test" button. The LEDs will indicate the approximate state of charge of the unit.

PS750LI

Table of Contents

Do you have a question about the PS750LI and is the answer not in the manual?

Page 1 PS750LI Operating & Safety Instructions GENERAL The 12V Jump Starter PS750Li is designed to assist with starting 12 Volt vehicles that have discharged batteries. To ensure safe and trouble-free operation of your PS750LI you must follow the instructions below. IMPORTANT INFORMATION FOR YOUR SAFETY DO NOT SHORT CIRCUIT OR TAMPER WITH THIS UNIT.
Page 2 Note: It is not recommended that the PS750Li is used to start vehicles without a battery fitted or with a battery that has had the electrolyte dried out. Damage may occur to the PS750Li or the vehicle if the PS750Li is disconnected or switched off while the engine is running.
Page 3 Warranty. VOLTAGE “SPIKE” PROTECTION The PS750LI has a spike protection system. This protection is in operation as long as the clamps are connected to the vehicle, even when the unit key-switch is switched off. NEVER remove one of the clamps before the key-switch is switched off.
Page 4 PS750LI Power Source 12V, 8Ah Cranking Amps 750A Peak Amps 1200A Main Switch Heavy Duty Polarity Alarm Acoustic Cable Size 25mm² Clamps Fully insulated Heavy Duty Housing High Density Polyethylene H x W x D mm 315 x 365 x 120 Weight (approx) 4.75kg...
