Contents of Aquarius box SKU # 5000
x1
x1
x2 x1
Install the step on a flat surface.
Do not jump or dive from the step.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer's instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
AQUARIUS DECK 5000
x2
x3
x2
x2
x1
WARNING
A
x6 x6 x6
INSERT NUT
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
SCREW BAG 140-0068
x6 x6 x6 x14
x10
1) Insert the two gussets in the slots and slide them
toward the corners.
2) Assemble the two main modules with the six screws,
nuts and washers provided.
3) Snap the door between the top and bottom module
within the slots provided.
GUSSET
2X
MANUFACTURER WARRANTY
REV. 19/01/2016
Sand
(not included)
Required tools
(not included)
1 year on pool step.
1 year on hardware.
PN:
PG:1
Advertisement
Related Manuals for Lumi-O INNOVAPLAS AQUARIUS DECK 5000
Summary of Contents for Lumi-O INNOVAPLAS AQUARIUS DECK 5000
- Page 1 AQUARIUS DECK 5000 Sand Contents of Aquarius box SKU # 5000 (not included) SCREW BAG 140-0068 x6 x6 x6 x14 x2 x1 WARNING Required tools (not included) Install the step on a flat surface. Do not jump or dive from the step. Remove the step from water when temperatures drop below freezing.
- Page 2 AQUARIUS DECK 5000 FILLER 1) Insert the two posts into the post ends and secure them in place with the screws provided. 1) Snap the three post ends into the 2) Insert the deck support over the rear post. step, making sure that the cylindrical part is vertical and that the ends are 3) Insert the handrail on the two posts and snapped properly in their respective...
- Page 3 AQUARIUS DECK 5000 1) Pull the deck supports (already fixed to the deck) upwards to create a spring effect on the step. 2) Fasten the supports to the two rear posts while pushing the entire step downwards. MANUFACTURER WARRANTY 1 year on pool step. 2257 route 139 1 year on hardware.
