Contents of Aquarius box SKU # 5010
x1
x2
x2 x1
Install the step on a flat surface.
Do not jump or dive from the step.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer's instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
AQUARIUS DECK 5010
x2
x3
x2
x2
WARNING
A
A
x6 x6 x6
INSERT NUT
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
SCREW BAG 140-0028
A
B
C
D
E
x1
x6 x6 x6
x17
x2
x12
1) Insert the two gussets in the slots and slide them
toward the corners.
2) Assemble the two main modules with the six screws,
nuts and washers provided.
3) Snap the door between the top and bottom module
within the slots provided.
B
C
GUSSET
2X
Contents riser kit box
F
SCREW BAG 140-0010
x2
Required tools
Phillips #2
Phillips #3
Sand
MANUFACTURER WARRANTY
1 year on pool step.
1 year on hardware.
REV. 02/26/2020
PN:
D
x4
x2
x4
(not included)
Phillips bit
7/16 wrench
(not included)
PG:1
Advertisement
Related Manuals for Lumi-O InnovaPlas Aquarius Deck 5010
Summary of Contents for Lumi-O InnovaPlas Aquarius Deck 5010
- Page 1 AQUARIUS DECK 5010 Contents of Aquarius box SKU # 5010 Contents riser kit box SCREW BAG 140-0028 SCREW BAG 140-0010 x2 x1 x6 x6 x6 Required tools (not included) WARNING Install the step on a flat surface. Do not jump or dive from the step. Remove the step from water when temperatures drop below freezing.
- Page 2 AQUARIUS DECK 5010 FILLER *SAND 1) Snap the three post ends into the step, making sure that the cylindrical 1) Fill the bag provided with sand. part is vertical and that the ends are The approximate weight should snapped properly in their respective be 5 lbs.
- Page 3 AQUARIUS DECK 5010 MEASURE 1) Once the step has been entirely submerged, put it in place, with the deck supports resting on the deck. 2) Once the step is in the pool, CUTTING measure as illustrated. LINE 3) Insert the short post into the MEASURE post end and screw together 3/4”...
