- Page 1 Speed Gate ID GATE 8900 User Manual...
-
Page 2: Table Of Contents
ID GATE 8900 Contents 1. Product Introduction ....................3 1. 1 Note ......................... 3 1. 2 Functional features ....................3 1. 3 Structures and dimensions ..................4 1. 4 Technical parameter ....................4 2. Product Structure and Working Principle ..............5 2. -
Page 3: Product Introduction
ID GATE 8900 1. Product Instruction 1.1 Note Before installation, operation or maintenance, turn off power. Do not change the inside wiring, take a photo before any disconnection. Do not use the turnstile inside power supply to connect other third-party device. -
Page 4: Technical Parameter
ID GATE 8900 Short Glass Arm High Glass Arm Figure 1 1.4 Technical parameter Item Description Cabinet 304 Stainless steel+ P l e x i g l a s g l a s s arm Dimension 1683 *132* 1000mm Weight... -
Page 5: Product Structure And Working Principle
ID GATE 8900 2. Product Structure and Working Principle 2.1. Electronic control system of channel gate The electronic control system consists of c a r d r e a d e r , main control board, infrared sensor, direction indicator board, alarm, transformer, etc. -
Page 6: Operating Principle Of The System
ID GATE 8900 Item NO. NAME FUNCTION IC/ID card access c o n t r o l , fingerprint machine, face Entrance g u a r d system recognition, two-dimensional code device, gate opening signal o n t h e control board of gate machine,... -
Page 7: Install Instruction
ID GATE 8900 If a pedestrian forgets to read his card or reads an invalid card and enters the channel, the system will forbid the pedestrian to pass through and issue a v o i c e a l a r m . The alarm will not be lifted until the pedestrian exits the channel. Rereading a valid card allows passage. -
Page 8: Turnstile Cable Drawing
ID GATE 8900 After the equipment status check is n o r m a l , t h e following functions can be debugged. Figure 2 3.2 Turnstile cable drawing Figure 3... -
Page 9: Turnstile Circuit Board Wiring Diagram
ID GATE 8900 3.3 Turnstile circuit board wiring diagram *Turnstile electrical parts area with power s u p p l y p o r t , please connect to 110V/220V electrical power supply. *Turnstile circuit board with port “NO1”, C O M ” , “ N O 2 ” , it can be connected to any type of the third-party access controller device. -
Page 10: Equipment Function Debugging
ID GATE 8900 4. Equipment Function Debugging 4.1 Gate Position Adjustment 1. Press “Set” (middle button) for 5 times c o n t i n u o u s l y , t h e system will prompt "please adjust gate manually". - Page 11 ID GATE 8900 To control the effect of g a t e p a n e l swing, the higher the value, the Show down r a n g e 1~30 earlier the braking Self-check r u n n i n g...
-
Page 12: Product Maintenance
ID GATE 8900 4: the main machine r e v e r s e s , t h e slave reverses; Clutch c o n t r o l 0: normal lock, 1: normal u n l o c k... -
Page 13: Tips And Troubleshooting
ID GATE 8900 5.2 Tips and troubleshooting 1. After swiping card, if the arm doesn’t open, p l e a s e r e c h e c k whether all the wire well connected. 2. If indicator doesn’t light, or indicate wrong d i r e c t i o n , please exchange the inside wires to test.
