Istruzioni Rivelatore di Fumo RF501
Rivelatore ottico di fumo
RF-501t
Optical smoke detector
+ Le informazioni contenute nel presente foglio d'istruzione
sono soggette a modifiche senza preavviso e non rappresen-
tano un impegno da parte della BENTEL SECURITY s.r.l.
+ BENTEL SECURITY s.r.l. reserves the right to change the
technical specifications of this product without prior notice.
CONFORME ALLA NORMA UNI EN54 parte 7
TESTED AND APPROVED TO EN54 part 7
CARATTERISTICHE GENERALI
L'RF501t è un rivelatore combinato sensibile sia alla presenza di
fumo sia alle alte temperature.
È quindi possibile rivelare tempestivamente il verificarsi nell'am-
biente in cui esso è installato, di incendi caratterizzati dallo svilup-
po di fumo come nella combustione di legno, cellulosa, stoffa e
materiali simili, mentre negli altri casi l'innalzamento della tempe-
ratura provoca ugualmente la segnalazione di allarme.
FUNZIONAMENTO
Sono racchiusi al suo interno, in una apposita camera di raccolta
del fumo, un emettitore ed un ricevitore di luce all'infrarosso.
In condizioni normali, cioè in assenza di fumo, il ricevitore vede
solo una piccola parte della luce proveniente dall'emettitore, even-
tuale fumo nella camera provoca, contrariamente, un considerevo-
le aumento del segnale ottico ricevuto.
Perchè il rivelatore vada in allarme è necessario che il fumo per-
manga nella camera per un tempo di circa 5 secondi.
Il rivelatore durante il suo funzionamento normale provoca, ad intervalli
di circa 25 secondi, una breve accensione del LED di segnalazione al-
larme per indicare che è correttamente alimentato e funzionante.
Per testare il rivelatore tenere una calamita vicino al suo LED di
allarme per almeno 5 secondi (usare, per esempio, il magnete di
un altoparlante).
Nel circuito è anche presente un elemento sensibile alle variazioni
di temperatura che fa scattare l'allarme nel caso in cui la tempera-
tura ambiente superi la temperatura di soglia prefissata di 55 °C.
INTERFACCIAMENTO
Il rivelatore RF-501t funziona con tensioni di linea comprese tra 12 e
30 Volt ed ha un consumo a riposo inferiore a 100 µA (24 Volt).
Tensione di alimentazione
Operating Voltage
Corrente a riposo
ISTRF501
Standby Current
Corrente in allarme
Alarm Current
Corrente di mantenimento
Minimum Alarm Current
Uscita per indicatore remoto
Remote Signalling Output
Temperatura di funzionamento
Temperature Range
Dimensioni base
Detector Base Size of (∅ x H)
Dimensioni unità di rivevazione
Detector Unit Size (∅ x H)
Peso base
Detector Base Weight
Peso unità di rivelazione
Detector Unit Weight
Grado di protezione
IP Code
The RF-501t is a smoke and temperature detector.
The RF-501t can detect a broad range of fires, and allows fast re-
sponse to fire inside the protected environment. The smoke cham-
ber is sensitive to smoke from smouldering fires or from burning
wood, paper, modern fabrics and furnishings etc. The thermal
sensor is sensitive to the rise in temperature.
The smoke chamber contains an infrared emitter and receiver.
During standby status (no smoke in the smoke chamber) the re-
ceiver picks up a low level of I.R. from the emitter. However, when
smoke is present in the sensing chamber a considerable increase
in the optical signal occurs, and the detector will latch in alarm.
Smoke must be present in the chamber for about 5 seconds be-
fore the detector will latch in alarm.
During standby status the alarm LED will blink at intervals of 25
seconds, to show the detector status.
The detectors can be tested by holding a test magnet near to the
detector LED, alarm status will be signalled after approximately 5
seconds.
The thermal sensor will latch in alarm when the temperature inside
the protected environment exceeds the 55 ºC threshold.
The operating voltage of the RF-501t ranges from 12 to 30 Volts,
with a standby current of 100 µA (24 Volts).
CARATTERISTICHE TECNICHE

TECHNICAL FEATURES

GENERAL FEATURES

OPERATING PRINCIPLES

INTERFACING

24V
(12.6 ÷ 28 V
)
80 ÷ 130 µA
5 ÷ 50 mA
5 mA
100 mA max.
0 ÷ 50 °C
104 x 22 mm
100 x 43 mm
40 gr.
104 gr.
IP30
