optonica 6376 Quick Start Manual

Wall Mounted Touch Panel
SKU: 6376/ 6377
4 Zone/1-4 color/Glass touch panel/Color wheel/AC input/DMX 512 and RF 2.4G signal output
6376
6377

Features

● Touch panel 4 zone 1-4 color DMX512 master, can also be used as 4 zone 1-4 color RF remote.
● DMX signal output, comply to standard DMX512 protocol, compatible with DMX decoder from any supplier.
● When used as RF remote, each zone can remote control multiple RF 2.4G LED controllers.
● Ultra sensitive high strength glass touch panel with touch color wheel in the middle.
● Smooth and accurate color adjustment by touching the color wheel.
● Touch keys with LED indicator.
● White & Black glass panel available.

Technical Parameters

6376/ 6377
Model No.
Light type
Dual color
Output DMX channel number 8
Input and Output Dimming data
Input voltage Input signal
100-240VAC
Input current RF Control distance
Max 0.1A
Dimming level
Output signal DMX512, RF 2.4GHz
Dimming range

Safety and EMC

Environment
ETSI EN 301 489-1 V2.2.3
EMC standard (EMC)
ETSI EN 301 489-17 V3.2.4
Operation temperature
Safety standard(LVD)
EN 62368-1:2020+A11:2020
Case temperature
Radio Equipment(RED) ETSI EN 300 328 V2.2.2
IP rating
CE,EMC,LVD,RED
Certification
Weight
Warranty
Net weight
3 years Gross weight
Warranty

Mechanical Structures and Installations

AC input N
LVD RED
DMX output -
DMX output +
86.00 mm
52.00 mm
Touch key + RF 2.4GHz
10m ( Barrier-free space )
256 levels
0 - 100%

Installation diagram:

O O
Ta: -30 C ~ +55 C
( Max. ) O
T c: +65 C
IP20
0 . 181k g
0 . 234k g
Uninstall
AC input L
N L
INPUT 100-240VAC
6376/ 6377
DMX OUTPUT
DMX output +
D- D+ GND D- D+
DMX output -
DMX signal GND
33.00 mm
Typical base as below:
European style
86 size
59.00 mm 11.50 mm
Touch panel Baseplate Base
Key function
6376/ 6377 Dual color panel
Turn on/off all zone light.
BRIGHT POWER
Brightness,10 levels.
BRIGHT
Color temperature wheel.
ZONE ZONE ZONE ZONE
Short press turn on zone light and select zone simultaneously, long press 2s turn off zone light.
4 zone control seperately or synchronously, each zone could control multiple receivers.
ZONE ZONE ZONE ZONE
Turn on key tone when all zone light is off
: Long press power key for 5s , will turn on or turn off key tone.
