NP40/50/60 Installation Guide
Ceiling Mounted and Desktop
Input Panel
PC Control Codes
Function
POWER ON
POWER OFF
INPUT SELECT COMPUTER
INPUT SELECT VIDEO
INPUT SELECT S-VIDEO
PICTURE MUTE ON
PICTURE MUTE OFF
SOUND MUTE ON
SOUND MUTE OFF
AUTO FUNCTIONS EXECUTE
PROJECTOR INFORMATION REQUEST
INFORMATION REQUEST
Note: Contact your NEC rep for codes not listed.

Cable Connection

Communication Protocol:
Baud Rate: 38400 bps
Data Length: 8 bits
Parity: No Parity
Stop Bit: One Bit
X on/off: None
Communications: Full duplex
NOTE 1 : Pins 2, 3, 5, and 6 are used inside the projector.
NOTE 2: For long cable runs it is recommended to set communication speed within the projector to 9600 bps.
______________________________________________________________________________________________________________________
www.necdisplay.com
8 6
7
5 4 3
2 1
PC CONTROL COMPUTER IN
Code Data
02H 00H
02H 01H
02H 03H
02H 03H
02H 03H
02H 10H
02H 11H
02H 12H
02H 13H
03H B6H
00H BFH
03H 8AH
NEC Display Solutions of America, Inc.
VIDEO IN
00H 00H 00H 02H
00H 00H 00H 03H
00H 00H 02H 01H
00H 00H 02H 01H
00H 00H 02H 01H
00H 00H 00H 12H
00H 00H 00H 13H
00H 00H 00H 14H
00H 00H 00H 15H
00H 00H 01H 01H
00H 00H 01H 02H
00H 00H 00H 8DH
S-VIDEO IN
01H 09H
06H 0EH
0BH 13H
BBH
C2H
NP40/50/60
Rev 1.2
Page 6 of 6
