ELECTRIC RANGES
Kasap Tip Dik Buzdolapları
CONTENTS
Page
2
Page
3
Page
3
Page
4
Page
4
Page
4
Page
5
Page
6
Page
7
Page
8
Page
9
Page
13
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMP.6KE010 and is the answer not in the manual?

Questions and answers

Related Manuals for EMPERO EMP.6KE010

Summary of Contents for EMPERO EMP.6KE010

  • Page 1: Table Of Contents

    ELECTRIC RANGES Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Ageneral Information

    ELECTRIC RANGES Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Electric Ranges ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.6KE010 400x650x290 470x710x550 EMP.6KE020 600x650x290 680x710x580 TECHNICAL INFORMATION Cable Power...

  • Page 4: A3 Transportation

    ELECTRIC RANGES TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can be moved by hand from area to area.Do not crash and drop the appliance while transporting. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    ELECTRIC RANGES Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ...

  • Page 6: Doperation

    ELECTRIC RANGES OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : Heat setting button B : Indicator lamp *Operating; • Plug in the appliance. • Put the cooker on the range. • Adjust heat setting butttons to desired temperature. • The range reaches the desired temperature and starts to operate.

  • Page 7: Ecleaning & Maintenance

    ELECTRIC RANGES Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Always turn off the appliance and disconnect from the power supply before cleaning. • Clean the outer surface of the appliance with a wet cloth and chrome shiner. •...

  • Page 8: Ftroubleshooting

    ELECTRIC RANGES TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. Check if it is operated at required heat THE APPLIANCE DOESN’T COOK WELL or not. The appliance can stop due to low THE APPLIANCE STOPPED voltage.In this situation check the voltage.

  • Page 9: Gspare Part List-Exploding Drawing

    ELECTRIC RANGES Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.6KE010...
  • Page 10 ELECTRIC RANGES SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.6KE010 PRODUCT NAME P.CODE HOTPLATE (2 KW ø180) Y.EMP.6KE010.001 HOTPLATE (1,5 KW ø180) Y.EMP.6KE010.002 FEET Y.EMP.6KE010.003 BASE FRAME Y.EMP.6KE010.004 SWITCH 0-6 Y.EMP.6KE010.005 BUTTON BUFFER Y.EMP.6KE010.006 WARNING LAMP Y.EMP.6KE010.007 BUTTON...
  • Page 11 ELECTRIC RANGES Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.6KE020...
  • Page 12 ELECTRIC RANGES SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.6KE020 PRODUCT NAME P.CODE HOTPLATE (1,5 KW ø180) Y.EMP.6KE020.001 HOTPLATE (1,5 KW ø145) Y.EMP.6KE020.002 HOTPLATE (2 KW ø180) Y.EMP.6KE020.003 BASE FRAME Y.EMP.6KE020.004 SWITCH 0-6 Y.EMP.6KE020.005 FEET Y.EMP.6KE020.006 WARNING LAMP Y.EMP.6KE020.007 BUTTON Y.EMP.6KE020.008...

  • Page 13: Helectric Circuit Schema

    ELECTRIC RANGES Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.6KE010 SW1.SW2 L1.L2 6 Gradual Plate Resistance 2000 Plate Resistance 1500 Signal lamp Switch W 230V W 230V...
  • Page 14 ELECTRIC RANGES ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.6KE020 SW1.SW2.SW3.SW4 R2.R3 L1.L2.L3.L4 Plate Plate Plate Resistance Resistance Resistance 6 Gradual Switch Signal lamp 1500 W 2000 W 1500 W 230V 230V 230V...

This manual is also suitable for:

Emp.6ke020
