- Page 1 AccuMax Quantum VPC Mattress and AccuMax Quantum VPC Mattress with Airport Instructions for Use Product No. PAC, PAF, PAH, and PAU Hillrom is a part of Baxter 174152 REV 10...
- Page 3 PATENTS / PATENT hillrom.com/patents May be covered by one or more patents. See the above Internet address. The Hill-Rom companies are the proprietors of European, US, and other patents and pending patent applications. Legal Manufacturer: HILL-ROM, INC. 1069 STATE ROUTE 46 E...
- Page 4 Virex is a registered trademark of Diversey, Inc. Wexcide is a trademark of Wexford Labs, Inc. Baxter, AccuMax Quantum, Advanta, Avantguard, CareAssist, Controlled Release, FlexAfoot, Heel Pillow, Hill-Rom, Hillrom, TotalCare, and VersaCare are trademarks of Baxter International Inc, or it’s subsidiaries.
-
Page 5: Table Of Contents
Table of Contents Symbols ............1 Document Symbols . - Page 6 Table of Contents NOTES: AccuMax Quantum VPC Mattress and AccuMax Quantum VPC Mattress with Airport Instructions for Use (174152 REV 10)
-
Page 7: Symbols
Symbols SYMBOLS OCUMENT YMBOLS This document contains different typefaces and symbols to make the content easier to read and understand: • Standard text—used for regular information. • Boldface text—stresses a word, phrase, or trademark. • NOTE:—sets apart special information or important instruction clarification. - Page 8 Symbols Symbol Definition Conforms to European requirements for class I medical devices in accordance with: • Directive 93/42/EEC until May 25, 2021 • Regulation (EU) 2017/745 regulation by May 26, 2021 Hand cleaning instructions. No tumble dry. No dry cleaning. No ironing.
- Page 9 Symbols Symbol Definition Use chlorine concentration less than or equal to 5500 ppm (applies to hand cleaning only). ≤ 5500 ppm Product not made with natural rubber latex. Meets fire code BS 7177. Maximum patient weight 500 lb (227 kg) for the mattress.
-
Page 10: Control Unit Panel
Symbols ONTROL ANEL Item Description Normal pressure indicator Max inflate button and indicator On / Off switch Low pressure alarm Patient comfort control selector AccuMax Quantum VPC Mattress and Accumax Quantum VPC Mattress with Airport Instructions for Use (174152 REV 10) -
Page 11: Accumax Quantum Vpc Mattress With Airport And Optional
Symbols VPC M UANTUM ATTRESS WITH IRPORT AND PTIONAL CU2 C ONTROL AccuMax Quantum VPC Mattress and Connected CU2 Control Unit AccuMax Quantum VPC Mattress and AccuMax Quantum VPC Mattress with Airport Instructions for Use (174152 REV 10) -
Page 12: Intended Use
Intended Use INTENDED USE The AccuMax Quantum VPC Mattress is a therapeutic pressure redistribution system comprised of foam-filled air cylinders that aid in the prevention/treatment of pressure injuries in patients and residents with up to moderate risk and/or Stage I and II pressure injuries when combined with recommended turning protocols. -
Page 13: Introduction
Introduction INTRODUCTION The AccuMax Quantum VPC Mattress is a non-powered surface that uses a system of intake and output valves to provide weight-based pressure redistribution whenever a patient moves or is repositioned. It has a top layer of visco-elastic foam for improved patient comfort. The AccuMax Quantum VPC Mattress with Airport can be operated in a non-powered or powered mode. -
Page 14: How It Works
Introduction • The CU2 unit offers on-demand alternating pressure therapy (optional for AccuMax Quantum VPC Mattress with Airport). • The mattresses accommodate patient weight up to 500 lb (227 kg). OW IT WORKS Through a series of air sectors along with our innovative Controlled Release Technology intake and output valves, the AccuMax Quantum VPC Mattress and the AccuMax Quantum VPC Mattress with Airport automatically begin to create a custom pressure redistribution profile... -
Page 15: Features-Accumax Quantum Vpc Mattress
Features—AccuMax Quantum VPC Mattress FEATURES—ACCUMAX QUANTUM VPC MATTRESS Item Description Top cover (A) friction and low shear material. Very low moisture vapor transmission rates. Water resistant, and stain resistant. Topper (B) A top layer of visco-elastic foam helps to create a custom body conforming surface that increases patient envelopment and comfort, helping to lower interface pressures. -
Page 16: Features-Accumax Quantum Vpc Mattress With Airport
Features—AccuMax Quantum VPC Mattress with Airport FEATURES—ACCUMAX QUANTUM VPC MATTRESS WITH AIRPORT Item Description Topper (A) A top layer of visco-elastic foam helps to create a custom body conforming mattress that increases patient envelopment and comfort, helping to lower interface pressures. Air sectors (B) Horizontally oriented air sectors that evenly... -
Page 17: Install And Use The Mattress
Install and Use the Mattress CU2 Control Unit (Optional) Item Description CU2 Control Unit The optional CU2 Control Unit controls the firmness of the mattress when it is used with the optional Airport connector. INSTALL AND USE THE MATTRESS The internal temperature of the mattress will affect the firmness of the mattress. -
Page 18: Bed Exit System
Bed Exit System If the AccuMax Quantum VPC Mattress with Airport and the optional control unit are used, then do the steps that follow: Pull the hooks outward from the back of the control unit, and suspend the control unit from the footboard of the bed frame. Uncoil the power cord, and plug the cord into the appropriate AC power source. -
Page 19: Cleaning And Disinfecting
Cleaning and Disinfecting CLEANING AND DISINFECTING WARNING: To help prevent injury and/or equipment damage, obey these warnings: • Warning—The mattress must be cleaned and disinfected per the cleaning and disinfecting instructions. • Warning—The potential for electrical shock exists with electrical equipment. -
Page 20: Recommendations
Cleaning and Disinfecting CAUTION: To help prevent equipment damage, obey these cautions: • Caution—Do not steam clean or power wash the mattress or optional control unit. Pressure and excessive moisture can damage the protective surfaces of the bed and its electrical components. - Page 21 Cleaning and Disinfecting LEANING AND ISINFECTION Cleaning and disinfection are distinctly different processes. Cleaning is the physical removal of visible and non-visible soil and contaminants. Disinfection is intended to kill microorganisms. The table of “Approved Cleaners/Disinfectants” on page 16 summarizes the approved cleaners/disinfectants for use with the associated contact time for disinfection.
- Page 22 Cleaning and Disinfecting Approved Cleaners/Disinfectants Recommended Recommended Maintain for Disinfection Cleaner/ for Routine Wetness against Disinfectant Cleaning and (Disinfection Clostridium Disinfection Contact Time) Difficile (C.Diff) Wex-Cide 10 minutes Germicidal Detergent ready-to-use Virex II 256 10 minutes OxyCide Daily 3 minutes Disinfectant Cleaner Clorox...
-
Page 23: Step 1: Cleaning
Cleaning and Disinfecting If applicable, remove the mattress and optional control unit from the bed. STEP 1: Cleaning As necessary, first remove visible soil from the mattress and optional control unit using a wiping cloth soaked with an approved cleaner/disinfectant (see “Approved Cleaners/Disinfectants”... -
Page 24: Step 2: Disinfection
Cleaning and Disinfecting STEP 2: Disinfection With a new or clean wiping cloth soaked in an approved cleaner/disinfectant, use light pressure to wipe all exterior surfaces of the mattress and optional control unit previously cleaned. Make sure all surfaces remain wet with the cleaner/disinfectant for the specified contact time. -
Page 25: Maintenance
Maintenance Machine wash the top cover per your facility protocol. The cover can be washed at a maximum water temperature of 54°C (130°F). • Use a disinfectant as instructed in the manufacturer’s instructions. • To determine the amount of disinfectant to use, determine the amount of water in the washer, and follow the manufacturer’s dilution instructions. -
Page 26: Decommissioning And Disposal Instructions
Decommissioning and Disposal Instructions DECOMMISSIONING AND DISPOSAL INSTRUCTIONS Customers should adhere to all federal, state, regional, and/or local laws and regulations as it pertains to the safe disposal of medical devices and accessories. If in doubt, the user of the device shall first contact Hill-Rom Technical Support for guidance on safe disposal protocols. -
Page 27: Replacement Parts
Replacement Parts REPLACEMENT PARTS Part Number Description 185426 ACCUMAX VPC TOP COVER 35x80, BLUE 185427 ACCUMAX VPC TOP COVER 35x84, BLUE 197413 ACCUMAX VPC BOT COVER 35x80, FLAT DECK, HANDLES, GREY 197414 ACCUMAX VPC BOT COVER 35x84, FLAT DECK, HANDLES, GREY 199126 ACCUMAX VPC BOT COVER 35x80, FLAT DECK WITH... -
Page 28: Service Calls
Service Calls SERVICE CALLS When you call Hill-Rom about your mattress, be prepared to give the serial number or date of manufacture from the product identification label at the foot end of the mattress. TROUBLESHOOTING WARNING: Warning—Only facility-authorized persons should service the AccuMax Quantum VPC Mattress. -
Page 29: Specifications
Specifications SPECIFICATIONS IMENSIONS PAC Model Feature Dimension Length 80" (203 cm) 84" (213 cm) Width 35" (89 cm) Height 7" (18 cm) Weight 33 lb (15 kg) PAH Model Feature Dimension Length 80" (203 cm) 84" (213 cm) Width 35" (89 cm) Height 7"... -
Page 30: Regulations, Standards, And Codes
Specifications Environmental Conditions for Use Feature Dimension Temperature 40°F to 104°F (5°C to 40°C) Relative humidity range 20% to 85% (non-condensing) Environmental Conditions for Transport and Storage Feature Dimension Temperature -40°F to 158°F (-40°C to 70°C) Relative humidity range 10% to 95% (non-condensing) EGULATIONS TANDARDS ODES... -
Page 31: Safety Information
Safety Information SAFETY INFORMATION WARNING: To help prevent injury and/or equipment damage, obey these warnings: • Warning—Some safety features of the bed may not function or may not operate as intended with mattresses that are not designed specifically for this bed. Check with the mattress manufacturer to make sure that the safety features of the bed have been tested and verified to operate correctly with the replacement mattress. - Page 32 Safety Information California Proposition 65 Warning: WARNING: Warning—This product can expose you to chemicals including titanium dioxide, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov CAUTION: Caution—To help prevent equipment damage, obey these cautions: •...
