- Page 1 User manual HVC-PU 100-150 kW Overnight © Copyright ABB. All rights reserved...
- Page 2 Copyright All rights to copyrights, registered trademarks, and trademarks reside with their respective owners. ® Copyright ABB EV Infrastructure. All rights reserved. 6AGA000007-0604-EN | 001...
-
Page 3: Table Of Contents
Contents Contents About this document................5 Function of this document...................... 5 Target group..........................5 Revision history..........................5 Language.............................5 Illustrations..........................5 Units of measurement......................5 Typographical conventions..................... 5 How to use this document.......................5 General symbols and signal words..................6 1.10 Special symbols for warnings and dangers................7 1.11 Related documents........................7 1.12... - Page 4 Contents Signs on the EVSE........................19 Discard parts or the EVSE......................20 3.10 Cyber security.......................... 20 Operation....................21 Prepare before use........................21 Emergency stop........................21 Reset the EVSE after an emergency stop................21 Charge session......................... 22 4.4.1 Charge an EV......................22 4.4.2 Start a charge session....................22 4.4.3 Stop a charge session....................
-
Page 5: About This Document
About this document About this document Function of this document The document is only applicable for this EVSE (HVC-PU 100-150 kW Overnight), including the variants and options listed in section The document gives the information that is necessary to do these tasks: •... -
Page 6: General Symbols And Signal Words
About this document General symbols and signal words Signal word Description Symbol Danger If you do not obey the instruction, this Refer to section 1.10 can cause injury or death. Warning If you do not obey the instruction, this Refer to section 1.10 can cause injury. -
Page 7: Special Symbols For Warnings And Dangers
Manufacturer and contact data Manufacturer ABB EV Infrastructure Heertjeslaan 6 2629 JG Delft The Netherlands Contact data The local representative of the manufacturer can give you support on the EVSE. You can find the contact data here: https://new.abb.com/ 6AGA000007-0604-EN | 001... -
Page 8: Abbreviations
About this document 1.13 Abbreviations Abbreviation Definition Alternating current Controller area network Central processing unit Direct current Electromagnetic compatibility Electric vehicle EVSE Electric vehicle supply equipment Measuring Instruments Directive Near field communication NoBo Notified body OCPP Open charge point protocol Protective earth Personal protective equipment RFID... -
Page 9: Orientation Agreements
About this document Term Definition Site operator Entity that is responsible for the day-to-day control of the EVSE. The site operator does not have to be the owner. User Owner of an EV, who uses the EVSE to charge the EV Note: It is possible that not all terms are present in this document. -
Page 10: Description
Description Description Type plate XXXXXXXXXXXXXXXXX XXXXXXXXXXXX XXXXXX-XXX-XXXX-XXX XXXXXXXXXX XXKg XA/XXW XXXV XXXXA XX XXXX Manufacturer Address of the manufacturer Full EVSE type CE mark Part number of the EVSE QR code with the global Serial number identification number of the EVSE Global identification number of the QR code with the serial number of EVSE... -
Page 11: Overview
Description Danger: General risk • If you use the EVSE in any other way than described in the related documents, you can cause death, injury and damage. • Use the EVSE only as intended. Overview 2.3.1 Overview of the system AC input cable Auxiliary DC output cables Auxiliary AC input cable... -
Page 12: Power Cabinet, Outside
Description Part Function The EV of which the batteries need to be charged Parking space Parking space 2.3.2 Power cabinet, outside Border cover Antenna Air outlet Air inlet (4x) Type plate Enclosure Door Part Function Border cover To cover the bottom part of the EVSE Air inlet and outlet To let the cooling air in and out. -
Page 13: Power Supply Box, Outside
Description 2.3.3 Power supply box, outside Enclosure Cable glands Door Type plate Part Function Enclosure To reduce the accessibility of unqualified persons to the inside of the EVSE Door To prevent unauthorized access to the inside of the Cable glands Openings for the cables Type plate To show the identification data of the box. -
Page 14: Control Box, Outside
Description 2.3.4 Control box, outside Enclosure Type plate Door Cable glands Beacon Part Function Enclosure To reduce the accessibility of unqualified persons to the inside of the EVSE Door To prevent unauthorized access to the inside of the EVSE Beacon To indicate the state of the EVSE Type plate To show the identification data of the box. -
Page 15: Control Elements
Description Control elements 2.4.1 Beacon Beacon with integrated LED indicator The beacon shows the status of the EVSE. Table 1: Indications of the lights LED color LED status Status of the EVSE Error Idle Preparation phase Charging Charge complete 6AGA000007-0604-EN | 001... -
Page 16: Emergency Stop Button (Emo)
Description 2.4.2 Emergency stop button (EMO) Emergency stop button (EMO) Emergency stop button (EMO) is used to cut off power in case of emergency Note: The placement of this button is customized for every configuration. Options 2.5.1 Stop button Stop button The stop button is used to stop the charge session Note: The placement of this button is customized for every configuration. -
Page 17: Safety
Safety Safety Liability The manufacturer is not liable to the purchaser of the EVSE or to third parties for damages, losses, costs or expenses incurred by the purchaser or third parties if any target group mentioned in the related documents does not obey the rules below: 1.11 •... -
Page 18: Personal Protective Equipment
Safety responsibility for the protection of the user, other employees or third parties. The owner must obey these instructions: • Know and implement the local rules. • Identify the hazards (in terms of a risk assessment), resulting from the working conditions on the site. -
Page 19: Safety Instructions During Cleaning Or Maintenance
Safety Safety instructions during cleaning or maintenance Preliminary requirements • • Keep unauthorized personnel at a safe distance during cleaning or maintenance. • If for cleaning or maintenance it is necessary to remove safety devices, immediately install the safety devices after the work. •... -
Page 20: Discard Parts Or The Evse
ABB Ltd and its affiliates are not liable for damages and/or losses related to such security breaches, any unauthorized access, interference, intrusion, leakage and/or theft of data or information. -
Page 21: Operation
Operation Operation Prepare before use 1. Appoint a site operator and an installation engineer, if these are other persons than you. 2. Make sure that the EVSE is installed according to the instructions in the installation manual. 3. Make an emergency plan that instructs people what to do in case of an emergency. -
Page 22: Charge Session
Operation Charge session 4.4.1 Charge an EV 1. Park the EV in the parking space. Make sure that the contact dome is above the EV within the required space. Refer to section 4.4.2 2. Start the charge session. Refer to section 4.4.3 3. -
Page 23: Clean The Evse
Operation 4.5.2 Clean the EVSE Preliminary requirements • Cleaning agent. Refer to section • Non-abrasive tool. Refer to section Danger: Hazardous voltage • Do not apply high-pressure water jets. Water can leak into the EVSE. Note: When the EVSE is put in a corrosion sensitive environment, superficial rust is possible on welding points. -
Page 24: Do A Check On The Cabinet
Operation 3. Manually remove dirt. Use the non-abrasive tool. Caution: Do not use abrasive tools. 4. Rinse with clean, cold tap water. 5. Clean the contact rails a. Clean the dirty contact rails b. Remove ice crusts from the contact rails, if there are any. c. -
Page 25: Troubleshooting
Troubleshooting Troubleshooting Troubleshooting procedure 1. Try to find a solution for the problem with the aid of the information in this document. 2. If you cannot find a solution for the problem, contact the manufacturer. Refer to 1.12 section 6AGA000007-0604-EN | 001... -
Page 26: Technical Data
Power rating 100 kW 150 kW Type of charging Overnight Overnight charging of up to 5 EVs Example HVC-PU 150 Overnight: • Brand = HVC • Type = PU • Power rating = 150 kW • Type of charging = Overnight... -
Page 27: Compensation Of The Park Tolerances
Technical data Compensation of the park tolerances Compensation angle Contact dome Compensation angle Pantograph on the EV Compensation on the X axis Compensation angle Compensation on the Y axis Compensation angle Maximum height of the EV with the pantograph Parameter Specification 2º... -
Page 28: Dimensions
Technical data Dimensions 6.6.1 Power cabinet Parameter Specification [mm] Width (X-dimension) 1170 Depth (Y-dimension Height (Z-dimension) 2030 6.6.2 Control box Parameter Specification [mm] Width (X-dimension) Depth (Y-dimension Height (Z-dimension) 6.6.3 Power supply box Parameter Specification [mm] Width (X-dimension) Depth (Y-dimension Height (Z-dimension) 6.6.4 Contact dome... -
Page 29: Space Requirements
Technical data Space requirements 6.7.1 Power cabinet Power cabinet Total depth Total width Space to open the power cabinet Space required for air inlet on the door side Space for air outlet Setting with power cabinets side by side Parameter Specification [mm] 1000 + n x 1170, where n is the number of power cabinets... -
Page 30: Control Box
Technical data 6.7.2 Control box Control box Space required over the control box Space required on the sides Space required under the control Space to open the control box door Parameter Specification [mm] 6AGA000007-0604-EN | 001... -
Page 31: Contactor Box
Technical data 6.7.3 Contactor box Power supply box Space required over the power Space required on the sides supply box Space to open the power supply Space required under the power box door supply box Parameter Specification [mm] Ambient conditions 6.8.1 Control box Parameter... -
Page 32: Power Supply Box
Technical data 6.8.2 Power supply box Parameter Value Ingression protection IP65 Operating temperature -35ºC to +45ºC Storage temperature -10°C to +70°C Storage conditions Indoor, dry Relative humidity 5% - 95% (non-condensing) Altitude Max. 2000 m above sea level 6.8.3 Power cabinet Parameter Value Ingression protection... - Page 33 Technical data 6AGA000007-0604-EN | 001...
