- Page 1 User Manual BL-VW22-4K60-A 4K HDMI Video Wall Processor All Rights Reserved Version: VP-VW22_2020V1.0...
- Page 2 4K HDMI Video Wall Processor Statement Thanks for purchasing this product, please read this user manual carefully before using this product. The functions described in this version are updated till October, 2020. In the constant effort to improve our product, we reserve the right to make functions or parameters changes without notice or obligation.
-
Page 3: Product Introduction
4K HDMI Video Wall Processor Product Introduction Thanks for choosing the 4K HDMI Video Wall Processor. The unit supports 1 HDMI input and 4 HDMI outputs. HDMI input supports resolutions up to 4Kx2K@60Hz 4:4:4 and output resolution is fixed to be 1920x1080p@60Hz. It supports 9 video wall modes, which can be selected via front panel button and IR remote. -
Page 4: Specifications
4K HDMI Video Wall Processor Specifications Video Input Input (1) HDMI IN Input Connector (1) 19-pin type-A female HDMI Resolution Up to 4K@60Hz 4:4:4 Video Output Output (4) HDMI OUT Output Connector (1) 19-pin type-A female HDMI Resolution 1920x1080p@60Hz General HDMI input Version Up to HDMI 2.0b HDCP input Version... - Page 5 4K HDMI Video Wall Processor Panel Description Front Panel 1. Power LED: The LED illuminates green when power is applied. 2. IR: Built-in IR sensor to receive IR signal. 3. Audio: Press the button to turn on/off audio output. 4.
- Page 6 4K HDMI Video Wall Processor Video Wall Modes User can press the button on the front panel or IR remote to toggle 9 video wall modes. IR Remote The video wall processor has a built-in IR sensor to receive IR control signal from IR remote.
- Page 7 4K HDMI Video Wall Processor Connection Diagram Normal Usage Cascade Usage...
