3 POINT POST HOLE DIGGER
PHD25, PHD25-A6PHD, PHD25-A9PHD, PHD25-A12PHD
PHD50, PHD50-A6PHD, PHD50-A9PHD, PHD50-A12PHD
123202, 123211, 123212, 123213
123203, 123214, 123215, 123216
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Titan Attachments PHD25
Summary of Contents for Titan Attachments PHD25
- Page 1 3 POINT POST HOLE DIGGER PHD25, PHD25-A6PHD, PHD25-A9PHD, PHD25-A12PHD PHD50, PHD50-A6PHD, PHD50-A9PHD, PHD50-A12PHD 123202, 123211, 123212, 123213 123203, 123214, 123215, 123216 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION THESE ARE STANDARD PRACTICES THAT MAY NOT APPLY TO THE PRODUCTS DESCRIBED IN THIS MANUAL. SAFETY AT ALL TIMES Thoroughly read and understand the instructions given in this manual before operation. Refer to the “Safety Label” section, read all instructions noted on them. Do not allow anyone to operate this equipment who has not thoroughly read and comprehended this manual. -
Page 3: For Your Protection
CAUTION: Indicates a potentially hazardous situation that may result in minor or moderate injury if not avoided. It may also be used to alert against unsafe practices. FOR YOUR PROTECTION Thoroughly read and understand the “Safety Label” section, read all instructions noted on them. SHUTDOWN AND STORAGE Lower machine to the ground, put the tractor in park, turn off the engine, and remove the •... -
Page 4: Prepare For Emergencies
PREPARE FOR EMERGENCIES Be prepared if a fire starts. • Keep a first aid kit and fire extinguisher handy • Keep emergency numbers for doctor, ambulance, hospital, and fire department near the • phone. WEAR PROTECTIVE EQUIPMENT Wear protective clothing and equipment appropriate for the job. Avoid loose-fitting •... - Page 5 PHD25 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION DESCRIPTION BOOM COMPLETE BOLT 3/8”X1” ARCH COMPLETE COTTER PIN GEARBOX (10) BOLT M12X90 PTO SHAFT (11) LOCKED NUT M12 OUTPUT SHIELD (12) PTO COVER (13) BOLT M12X70 BOLT 3/8”X5/8” ASSEMBLY INSTRUCTIONS − POST HOLE DIGGER COMES FULLY ASSEMBLED...
- Page 6 DESCRIPTION DESCRIPTION BOLT 3/8”X5/8” BOOM COMPLETE ARCH COMPLETE COTTER PIN GEARBOX (10) BOLT M12X90 PTO SHAFT (11) LOCKED NUT M12 OUTPUT SHIELD (12) PTO COVER (13) BOLT M12X70 BOLT 3/8”X5/8” ASSEMBLY INSTRUCTIONS − POST HOLE DIGGER COMES FULLY ASSEMBLED...
- Page 7 ASSEMBLY INSTRUCTIONS 1. Attach arch to lower hitch points. If tractor has Category 2 hitch, use bushings provided on arch pins 2. Attach arch to boom with pin and cotter pins provided 3. Attach gearbox to boom with pins and cotter pins provided 4.
-
Page 8: Lubrication Schedule
OPERATING INSTRUCTIONS 1. Lower auger point slowly to ground. Auger point should be 4” to the rear of the plumb line of the venter of the top of the auger. 2. Set brake or use park position 3. Engage pto shaft clutch at half throttle and slowly lower auger into the ground. In some types of soil it may be necessary to hold auger back from screwing itself into the ground with the hydraulic control lever. - Page 9 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non- economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,...
- Page 10 NEED HELP? CONTACT US FIRST. 1-800-605-7595 info@palletworks.com www.palletforks.com © 2023 Titan Brands...
