61” plasma monitor
Hide thumbs


Advertisement

Comprehensive input panel includes connections for up to 8 different
sources including a 29-pin DVI digital input connector and three
assignable audio inputs. RS232, control lock and remote control jack are
located on a separate connector panel on the bottom of the cabinet.
Ultimate
presentation tools
The PlasmaSync 61MP1 includes unique capabilities that enhance its
effectiveness as tool for professional presentation purposes. With a Split
Screen Display capability, Digital Zoom and generating only 22 decibels of fan
noise for undetectably silent operation, the 61MP1 helps you communicate
your message like no other plasma monitor can.
NEC has unique Split Screen capability which allows simultaneous
display of a computer and video sources. Choose from up to 8
different configurations with a simple touch of a button on the
remote control.
VIDEO
PC
VIDEO
PC
With Digital Zoom you can select a portion of the screen image
and enlarge it up to 9 times with the touch of a button on the
remote control.
Video1, Composite RCA
Video2, Composite BNC
Video3, S-Video
Audio1
DVD/HD1, Component
RCAx3 (Y, Pb, Pr)
Audio2
RGB1, 15-pin
RGB2 & DVD/HD2,
5BNC (RBG/HV)
Audio3
RGB3, 29-pin
DVI Digital
VIDEO
PC
PC
VIDEO
Broad Signal and Source Compatibility
Being optimized for multimedia means that the 61MP1 can connect to
and display signals from virtually any input source – whether it's
computer, conventional video or HDTV. With eight separate inputs it
can accommodate virtually any source equipment that you would want
to connect.
SOURCE
INPUT OPTIONS
RGB
15-pin mini D-Sub
RGB
5 BNC (RGB/HV)
Digital RGB
29-pin DVI-D
Composite Video
RCA BNC
S-Video
4-pin DIN
DTV/HDTV
3X RCA BNC
Audio
3X Stereo RCA
Control
9-pin

Split Screen Display

The PlasmaSync 61MP1 Split Screen allows simultaneous display of
multiple input sources. More than a simple picture-in-picture, split
screen lets you position computer and video images in different
configurations around the screen to support videoconferencing,
workgroup collaboration and host of other multi-tasking uses. Split
Screen also gives you a solution for displaying 1024x768 XGA
computer sources by allowing you to display them in their standard 4:3
aspect ratio.

Digital Zoom

With its Digital Zoom the 61MP1 allows you to select a portion of the
screen and magnify it up to nine times to highlight information or
emphasize a point. This is a presentation tool you won't find on any
other plasma monitor.
SIGNAL STANDARD
VGA – UXGA Computer,
Component Video
VGA-XVGA Computer,
Component Video, HDTV
VGA – UXGA Computer
NTSC (3.58, 4.43), PAL,
PAL60, SECAM
SVHS
480i, 480p, 540p, 625i,
625p, 720p, 1035i, 1080i
Assignable via OSM
RS232C
