Specifications

Screen Size
51.9 inches(H) 29.2 inches(V)
1319 mm(H) 742 mm(V)
diagonal 60 inches
Aspect Ratio
16 : 9
Resolution
1365 pixels(H) 768 pixels(V)
Pixel Pitch
0.038 inches(H) 0.038 inches(V)
0.97 mm(H) 0.97 mm(V)
Signals
Synchronization Range
Horizontal : 15.5 kHz to 110.0 kHz
(automatic : step scan)
Vertical : 50.0 Hz to 120.0 Hz
(automatic : step scan)
Input Signals
RGB, NTSC (3.58/4.43), PAL (B,G,M,N),
PAL60, SECAM, HD*
Input Terminals
PC/RGB
Visual 1 (Analog)
mini D-sub 15-pin 1
Video
Visual 1
RCA 1
Visual 2
S-Video: DIN 4-pin 1
DVD/HD
Visual 1
RCA-pin (Y, Cb/Pb, Cr/Pr) 1*
Visual 2
RCA-pin (Y, Cb/Pb, Cr/Pr) 1*
HDMI
HDMI connector 2*
Audio
Stereo RCA 3 (Selectable)
External Control
D-sub 9-pin 1 (RS-232C)
Remote In
Mini jack 1
Remote Out
Mini jack 1
Sound output
9 W+9 W at 6 ohm
Power Supply
AC100 V to 240 V 50 Hz/60 Hz
Current Rating
7.0 A (maximum)
Power Consumption
440 W (typical)
Dimensions
58.1 inches(W) 34.7 inches(H) 5.0 inches(D)
1476 mm(W) 880 mm(H) 126 mm(D)
Weight
135.6 lbs / 61.5 kg (without stand)
Environmental Considerations
Operating Temperature 0 °C to 40 °C / 32 °F to 104 °F
Humidity
20 % to 80 % (no condensation)
Storage Temperature -10 °C to 50 °C / 14 °F to 122 °F
Humidity
10 % to 90 % (no condensation)
Other Features
Motion compensated 3D Scan Converter (NTSC,
PAL, 480I, 576I, 525I, 625I, 1035I, 1080I), 2-3
pull down Converter (NTSC, 480I, 525I, 1035I,
1080I (60 Hz)), 2-2 pull down Converter (PAL,
576I, 625I, NTSC, 480I, 525I), Digital Zooming
(100 % to 900 % Selectable), Self Diagnosis via
RS232C, PDP Saver (PEAK BRIGHT,
ORBITER, INVERSE, WHITE, SCREEN
WIPER, SOFT FOCUS, etc.), Color Temperature
Select (high/middle/middle low/low, user has 4
memories), Auto Picture Adjust, Input Skip, Color
Tune, Gamma Correction (4 modes), Plug and
play (DDC1, DDC2b, HDMI: E-DDC),
Enhanced Split Screen, Protocol Set, etc.
Accessories
Power cord ( 1), Remote control ( 1), AAA
batteries ( 2), Manuals (Model Information
and Operation), Ferrite cores for power cord
( 2), bands for power code ( 2), Cable
clampers ( 3), beads bands ( 3), Ferrite core
for remote cable ( 2).
Regulations
UL 60065, CAN/CSA-C22.2 No.60065-03,
FCC class B, ICES-003 class B
For the operation of your plasma monitor,
refer to "Operation Manual".
1
1
, DVD*
The features and specifications may be subject to change without
notice.
1
*
DVD/HD input signals supported on this system.
480P (60 Hz)
525I (60 Hz)
1
625P (50 Hz)
1
720P (50 Hz)
2
1080I (60 Hz)
2
*
HDMI input signals supported on this system.
Supported Signals
• 640 480P @ 59.94/60 Hz
• 1280 720P @ 59.94/60 Hz
• 1920 1080I @ 59.94/60 Hz
• 720 480P @ 59.94/60 Hz
• 1440 (720) 480I @ 59.94/60 Hz
Note: In some cases a signal on the plasma monitor may not be displayed
properly. The problem may be an inconsistency with standards from
the source equipment (DVD, Set-top box, etc...). If you do experience
such a problem please contact NEC Corporation of America and also
the manufacturer of the source equipment.
En-2
58.1" (1476)
51.9" (1319)
Units are in inch
480I (60 Hz)
525P (60 Hz)
576P (50 Hz)
576I (50 Hz)
625I (50 Hz)
720P (60 Hz)
1035I (60 Hz)
1080I (50 Hz)
1080P (50 Hz)
1080P (60 Hz)
• 1920 1080I @ 50 Hz
• 720 576P @ 50 Hz
• 1440 (720) 576I @ 50 Hz
• 1280 720P @ 50 Hz
1.9"
3.0"
(49)
(77)
5.0"
(126)
(mm)
