  • Page 1 8600 Relay Expansion Card Installation Guide...
  • Page 2 8600 1. INTRODUCTION The 8600EUR-00 relay expansion card is designed to fit a range of Cooper Security Ltd equipment, and provides a means of converting open collector transistor outputs to NO/NC voltage free relay contacts. This card contains eight relays, each with its own dedicated input.
  • Page 3 8600 Figure 2. Interface Cable 485123 Figure 3. Interface Cable 485354 Figure 4. Interface Cable 485345 To remove the factory fitted interface cable you may need to ease the polarising clips on the input connector with a small screwdriver. CONNECTORS Figure 5 shows the input connector for the 8600.
  • Page 4 8600 Function 0 V Power Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 +12V Power Figure 5. 8600 Input Pins Figure 6 shows the relay output connectors available on the 8600. Figure 6. Relay Output Connectors. SPECIFICATION Outputs Relay contacts, no/nc, 1A at...
  • Page 5 To fit the relay card within a 4618/9 or 768/9r please read the Installation Guide supplied with those products. When fitting a 8600 within a 95EN Cooper Security recommend two alternative positions for the unit, see Figure 7. Page 5...
  • Page 6 8600 Figure 7. Mounting Positions with 95EN case To fit the relay card : 1. Remove all power from the control unit, both mains and battery. 2. Connect any required wiring to the 8600 relay outputs and route the cable through the back of the case.
  • Page 7 8600 Programming the Control Unit To program the 4618/9 and 768/9r please read the Installation Guide supplied with those units. To program the 95EN or any of the M-Series control units, please read the Engineering manual supplied with those control units. Note that for the 95EN and M-Series control units, the hardwired digi outputs are defaulted to +12V inactive 0V active (+ve removed).
  • Page 8 Every effort has been made to ensure that the contents of this book are correct. However, neither the authors nor Cooper Security Limited accept any liability for loss or damage caused or alleged to be caused directly or indirectly by this book. The contents of this book are subject to change without notice.
