  • Page 1 INSTRUCTION AND MAINTENANCE MANUAL WOK CHINESE COOKER (GAS)
  • Page 2: Mounting Instruction

    Indicates that there is a risk of personal injury or property damage. Explosion / fire hazard. TYPES  G7W5G WOOK COOKER (1 BURNER)(WITHOUT DOOR)(GAS) - 500*700*850/1040  G7W10G WOOK COOKER (2 BURNER)(WITHOUT DOOR)(GAS) - 1000*700*850/1040  G7W15G WOOK COOKER(3 BURNER)(WITHOUT DOOR)(GAS) - 1500*700*850/1040...
  • Page 3: Gas Connection

    Şekil 1 Şekil 2 Figure 1 Figure 2  The device should be placed under a filtered hood in order to remove the fumes and odors that may arise during the cooking process.  The device must be used in well-ventilated area. ( Figure 2 ) ...
  • Page 4 START-UP  If the device is connected to the gas system, close the gas main inlet valve.  Replacement of burner injectors (Şekil B), ( Şekil C), ( Şekil D) Take out the wok iron cast (1), burner support part (2), drawer (3) and knob (4) in order, b.
  • Page 5 e. Remove the thermocouple,(10) f. Remove the gas flex pipe and insert the appropriate injector. (11) Şekil D Figure D USER INSTRUCTIONS AND MATTERS  Cooker gas taps are equipped with safety valves and if the main flame goes out for any reason, the gas flow is automatically cut off.
  • Page 6 TURN OFF THE COOKERS (70-90 Serie)  Turn the gas valve to the ignite position “ ” in this case, only the pilot will ignite.  Turn the knob to the "0" position to turn it off completely. RATED HEAT LOAD CONTROL AND PRESSURE MEASUREMENT ...
  • Page 7: Water Connection

    WATER CONNECTION  Assemble the water faucet pipe with appropriate tool(13). Do not work the device without done clean and waste water connection (16) .  Turn the discharge valve to the right (closed) and left (open) to drain the waste water. CLEANING AND MAINTENANCE Cleaning ...
  • Page 8: Maintenance

    Maintenance  Do not use acidic food prodcuts as they may damage like vinegar, salt, lemon, etc.  Check the device regularly for possible malfunctions. Contact to service (at least annually) for assistance with repairs and regular maintenance.  In case of damage or malfunction, contact to the dealer or service department. Before contacting, use the troubleshooting instruction on page 6.
  • Page 9 COUNTRY CATEGORIES GAS TYPE PRESSURE (mbar) Austria II2H3B/P G20 - G30/G31 20-50/50 G20/G25 - 20/25 - 28- Belgium II2E+3+ G30/G31 30/37 Bulgaria II2H3B/P G20 - G30/G31 20-30/30 II2H3+ G20 - G30/G31 20-28-30/37 Switzerland II2H3B/P G20-G30/G31 20-50/50 II2H3+ G20 - G30/G31 20-28-30/37 Cyprus II2H3B/P...
  • Page 12: Diagnostic Table

    DIAGNOSTIC TABLE  Failure Cause Solution 1- blocked gas pipe to the ignition burner 1- check and remove 2- blocked ignition burner 2- check and remove The ignition flame does not 3- blocked ignition head 3- clean with small steel brush start 4- blocked ignition nozzle 4- check and replace...
  • Page 13: Disposal Of Waste Material

     ATTENTION: The cases listed above are for reference and example only. To solve this and similar problems, stop the device and contact the authorized service. Share the information plate and serial number of the device with the manufacturer. Any part replacement that may affect safety must be done by authorized persons.
  • Page 14: Problem Description

    CORRECTIVE\PREVENTIVEACTIVEFORM DETECTION TYPE OPTIMIZATION REQUEST/ CUSTOMER CUSTOMER COMPLAINT DESCRIPTION NAME PRODUCT NAME: DETECTED(Name,Appellation) DATE: SIGN: PROBLEM DESCRIPTION: SOLUTION PROPOSAL: EVALUATION: APPROVERS Note: If required, you can send it to our company by viewing the form above or by post.
