Long Cable Compensation Adjustment

To perform the long cable compensation adjustment, use the following steps:
Set the Auto Adjust Level (Auto SW) to "DETAIL" in the Advanced OSM
"Size" "Fine"
"Position"
SIMPLE O
FULL O
DETAIL O
O: Automatic adjustment is performed.
X: Automatic adjustment is not performed.
*1: Black level, RGB sharpness, RGB delay and RGB position are adjusted using Long Cable Software (included).
To enter the Advanced OSM
• Turn off your monitor.
• Turn on your monitor by pressing the "POWER" and "SELECT" buttons
simultaneously to open the Advanced OSM menu.
To exit the Advanced OSM
• Turn off and restart your monitor.
Perform "AUTO ADJUST" by using
OSM AUTO
• Use the Long Cable software
CD-ROM (included) during adjustment.
• Press select to adjust.
LCD2080UXmanual0605.p65
–continued
"Contrast"
Long cable capability *1
X
O
O
7
7
Black Level,
X 1.5 seconds
X 2 seconds
O 10 to 20 seconds
6/5/03, 9:01 AM
Time
