BOMBARDIER ski-doo All Summit Series Service Bulletin

page of 106

/ 106
Bookmarks

Quick Links

Download this manual

No. 2000-2

Date: September 3, 1999

SUBJECT: Sea Level Specifications

YEAR

MODEL

MODEL NUMBER

SERIAL NUMBER

2000

All Summit* Series

THESE MODIFICATIONS MUST BE PERFORMED ON ABOVE MENTIONED

SNOWMOBILES FOR SEA LEVEL RIDING

The present

supplies all informations pertaining to parts required to modify above mentioned

models for sea level riding.

For 1999 and previous model years, refer to "High Altitude and Sea Level Data" booklet, (P/N 484 300 003).

CAUTION: The following modifications and adjustments apply only for altitudes from and below

1800 m (6000 ft).

Failure to comply with these requirements may cause serious engine damage.

Summit 700

Summit 600

2000-2

Page 1 of 3

Printed in Canada (mbs2000-002a.fmMD)

®*Trademarks of Bombardier Inc.
