SAFECONTROL WEBserver 30 Installation Manual

DIN rail mounting

2x
1 2
2
1
2
4
4
5
5

Connection

Connect the power supply to the DC
1
connector using the supplied adapter
(the adapter has a lock against unin-
tentional release – must be turned).
2
Connect the Ethernet cable
to the ETH1 port.
2x
1
3
Screw the parts (1) and (2) together
using the enclosed nuts
and washers.
Screw the screwed parts to the
WEBserver (3) using the enclosed
screws (black).
Mount the WEBserver on the DIN
rail at an angle.
Press the WEBserver against
the DIN rail and release.
ETH 1 ETH 2
1
2
Installation guide
WEBserver 30
SAFECONTROL s. r. o.
Vaníčkova 315/7
169 00 Praha 6
IČO: 02084287
DIČ: CZ02084287
support@safecontrol.cz
www.safecontrol.cz
